resideo PROSIXLCDKP-EU Series Installation And Setup Manual

The PROSIXLCDKP-EU is a wireless keypad for use with Control Panels that support SiX™ series devices. Up to eight (8)
Keypads per partition can be used on the system.
Note: Installation shall be done in accordance with local regulations.
Item/Key
Display Window
AWAY
HOME
NIGHT
OFF
SELECT
SCROLL
MAX
TEST
BYPASS
INSTANT
CODE
CHIME
READY
Keys 0 - 9
KEYPAD OPERATION
For operating instructions, refer to the Control Panel instructions.
LEDs
POWER
STATUS
TROUBLE
Note: When the system is in Programming Mode, the Trouble and Status LEDs alternately flash Red and Green.
Installation and Setup Guide
Function
Liquid Crystal Display (LCD) displays
protection point identification, system status,
and messages.
Power LED
System Status LED
System Trouble LED
Arm Away key
Arm Home (Stay) key
Arm Night (Stay) key
Off key
Select key
• Scroll key
•
Local Programming key (2-second hold)
Arm (Away) Maximum key (no entry delay)
System Test key
Bypass Zone key
Arm (Home) Instant key (no entry delay)
Add Security Codes key
Chime Mode key
Check Zones key
Disarm/Cancel Key
Prox Tag reader (RFID)
Panic Alarm key
Panic key + Fire Panic key
Panic key + Police Panic key
Panic key + Medical Panic key
Numeric keys used to enter security code(s).
Off
Not Ready to Arm
No Trouble Present
Red - Steady
Armed
System Trouble Present
PROSIXLCDKP-EU SERIES
Wireless Keypad
Green - Steady
Battery - OK
Ready to Arm
--
Red - Flashing
Battery - Low
Alarm Detected
Device Trouble Present
