Fidelix FX-WMBUS-O-T Quick Start Manual

FX-WMBUS-O-T
Wireless M-Bus
Temperature Outdoor sensor
Battery powered for wireless installation
AES128 Encrypted Wireless M-Bus
communication
Continuous battery level monitoring
Measure to manage
The Fidelix FX-WMBUS-O-T outdoor temperature
sensor is a plug-and-play outdoor temperature
transmitter. The device is made from higly
durable PC plastic.
The internal radio antenna is optimized for
866MHz and is tuned for mounting on concrete,
wood or plaster. The device has two antennas;
one in each direction to maximise the range
between the sensor and the receiver.
The battery level is continuously monitored and
a low level warning is issued when battery is
nearing depletion. The sensor is not designed for
operationg in constant freezing temperature.

Technical features

Temperature range:
(recommended -20..+50°C)
Dimensions:
3.6V Li-SOIC2 A battery
Power supply:
Communication:
AES128 encryption
OMS standard wireless M-Bus
wireless
-30..+85°C
95 x 65 x 55 mm
90 sec interval
