Summary of Contents for Acer EI342CKR
- Page 1 ACER_LCD_EI342CKR_SM20220108V1 Acer Monitor EI342CKR LIFECYCLE EXTENSION GUIDE...
-
Page 3: Table Of Contents
ACER_LCD_EI342CKR_SM20220108V1 Contents Table of Contents Important Safety Notice ................. 3 1. Exploded Diagram ..................4 2. Wiring connectivity diagram ..............6 3. Mechanical Instruction ................7 4. Assembly and Disassembly SOP ............8 5. Troubleshooting ..................14 6. FRU List ..................... 16 Safety Notice Any person attempting to service this chassis must familiarize with the chassis and be aware of the necessary safety precautions to be used when serving electronic equipment containing... -
Page 4: Important Safety Notice
Acer EI342CKR Important Safety Notice Product Announcement: This product is certificated to meet RoHS Directive and Lead-Free produced definition. Using approved critical components only is recommended when the situation to replace defective parts. Vender assumes no liability express or implied, arising out of any unauthorized modification of design or replacing non-RoHS parts. -
Page 5: Exploded Diagram
Acer EI342CKR Exploded Diagram Product Exploded Diagram... -
Page 6: Wiring Connectivity Diagram
Acer EI342CKR 1. Wiring connectivity diagram... -
Page 7: Mechanical Instruction
Acer EI342CKR 2. Mechanical Instruction Tools Required List the type and size of the tools that would typically can be used to disassemble the product to a point where components and materials requiring selective treatment can be removed. Tool Description:... -
Page 8: Assembly And Disassembly Sop
Acer EI342CKR 3. Assembly and Disassembly SOP EI342CKR 4.1 Disassembly Procedures Preparation before disassemble 1.Clean the room for disassemble 2.Identify the area for monitor 3.Check the position that the monitors be placed and the quantity of the monitor ;prepare the area for material flow;... - Page 9 Acer EI342CKR Remove the tape and loosen the cable. Disassemble the LVDS cable, , Key BD cable , speaker cable and lamp Disassemble the cable from the MB power cable etc from the MB Unlock the screw and remove the power BD shield over .
- Page 10 Acer EI342CKR Remove the hinge base from the BKT after screw dismantle, then pull off the AC socket from BKT. Disassemble the hinge base & AC socket from the BKT...
- Page 11 Acer EI342CKR 4.2 Assembly Procedures Preparation before assemble: 1.Clean the room for work 2.Identify the area for material 3.Prepare the implement, equipment, materials as bellow： 1) working table 2) Screw-driver 3) Knife 4) glove 5) cleaning cloth ESD protection Take a LCM module, then insert the LVDS cable and adhesive the...
- Page 12 Acer EI342CKR Assemble the power BD shielding cover with screwing, need take Assemble the Power BD shielding cover, hinge base care of the cable to avoid interference. and the AC socket Fix the hinge base and insert the AC socket into bracket, the tied the...
- Page 13 Acer EI342CKR 1. Assemble the Key BD and project lamp power BD on the RC Cable assemble and rear cover assembled with the 2. Assemble the light bar & bracket on the RC light bar, speaker..etc. 3. Assemble the left & right speaker on the RC with screw.
- Page 14 Acer EI342CKR Assemble the hinge bracket with screw, then insert Assemble the hinge bracket and the cover, insert the projection the hinge plate.. lamp into the RC.
-
Page 15: Troubleshooting
Acer EI342CKR 4. Troubleshooting... -
Page 16: Fru List
5. FRU List This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of ACER B277. Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization). Please note that WHEN ORDERING FRU PARTS, you should c heck the most up-to-date information available on your regional web or channel. - Page 17 Acer EI342CKR ASSEMBLY CASE/COVER/BRACKET MAIN BOARD SHIELDING ASSY 33.TLPMC.002 ASSEMBLY SPEAKER 23.TLPMC.001 SINK/SPEAK/EARPHONE/RTC SPEAKER 23.TLPMC.001 SINK/SPEAK/EARPHONE/RTC SPEAKER 23.TLPMC.001 SINK/SPEAK/EARPHONE/RTC LED LCD Panel HUBEI CENTURY 34' WQHD None Glare 810.001.00131 LF 400nit KL.3400N.003 14ms 4000:1 AUO OC (AUO OC )
