iTrans DB-TR-22
Dante Bluetooth
Transceiver
All Rights Reserved
Version: V1.1

Product Introduction

Thanks for choosing the iTrans DB-
TR-22. It connects to your Dante
network and supports 2X1 channels
of wireless audio, allowing PC and
mobile device to playout and receive
audio with your Dante devices using
a Bluetooth connection.

Features

⚫ Plug and Play
⚫ 24-bit audio support
⚫ 2X1 audio channels
⚫ Supports 802.3af PoE
⚫ Bluetooth 5.0
⚫ Maximum transmission
distance 20m

Packing List

⚫ 1 x iTrans DB-TR-22
⚫ 1 x User Manual
Note: Please contact your distributor
immediately if any damage or defect in the
components is found.

Panel Description

① RJ45: Dante network
communication port. Green
steady light indicates system
ready; yellow flashing light
indicates link/data traffic. The
green light will flash to identify
the device when clicking the
Dante Controller "Identify" button
(an eye-shaped symbol) on the
host computer.
② Bluetooth: 1 x backlit key, blue
backlight, for Bluetooth pairing.
