Dynojet AUTOTUNE AT-132 Installation Manual

For use with harley-davidson power vision 3

AUTOTUNE

INSTALLATION GUIDE

For Use With Harley-Davidson Power Vision 3

PARTS LIST

AUTOTUNE

DIAGNOSTIC TO CAN CABLE

CAN TO POWER VISION 3 CABLE

PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION

2191 MENDENHALL DRIVE, NORTH LAS VEGAS, NV 89081

800-992-4993

O2 SENSOR

VELCRO

ZIP TIE

WWW.DYNOJET.COM

IAT-132.01

Table of Contents

Do you have a question about the AUTOTUNE AT-132 and is the answer not in the manual?

Page 1 For Use With Harley-Davidson Power Vision 3 PARTS LIST AUTOTUNE O2 SENSOR DIAGNOSTIC TO CAN CABLE VELCRO CAN TO POWER VISION 3 CABLE ZIP TIE PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 2191 MENDENHALL DRIVE, NORTH LAS VEGAS, NV 89081 800-992-4993 WWW.DYNOJET.COM IAT-132.01...
Page 2 INTRODUCTION Thank you for purchasing the Autotune Kit from Dynojet AUTOTUNE CAN PORT CONNECT TO Research. This kit is designed to be used exclusively POWER VISION 3 with the Dynojet Power Vision 3. The Autotune module by itself does not tune your vehicle; rather it transmits wideband Air-Fuel Ratio (AFR), or more precisely, Lambda values to the Power Vision 3.
Page 3 Note: The location of the diagnostic port varies depending on the model, so please refer to a service manual or contact Dynojet for the exact location. Caution: Many models use the same style connector for accessories. Your Power Vision 3 MUST be connected to the diagnostic port.
Page 4 CONNECTING TO THE POWER VISION 3 Following the instructions included with your Power Vision 3, secure the Power Vision 3 to the vehicle using the supplied Velcro. Make sure the Power Vision 3 will not interfere with the operation and steering of the vehicle. Attach the CAN to Power Vision 3 cable from the Autotune module to the port on the Power Vision.
