Bixpy J-2 User's Manual And Safety Manual page 5

MOUNTING YOUR BIXPY J-2 MOTOR
Your Bixpy J-2 motor has a four hole attachment point that is used to attached it to a variety of
adapters available at www.bixpy.com/adapters. The same attachment can be used to allow you to
mount the motor to your own (DIY) adapter. To secure your Bixpy motor to your adapter, open the
provided M4 screws and bolts, slide your adapter into the opening, making sure the outlet of the
motor is pointing to the rear of your adapter. Using a Phillips screw driver to secure the four screws
and bolts (DO NOT over tighten).
Use zip-ties and provided Bixpy Pipe Clips to secure the power cable to your adapter (not
necessary for all adapters) - see below.
Make sure there are no sharp kinks or bends in your wire on its way to your Bixpy Power Pack.
1
Use the provided M4 screws and bolts (1) to secure your
Bixpy motor to your Bixpy Adapter (2).
2
If you are making your own adapter for your application,
1
visit www.bixpy.info for instructions and to download a
template to make your own hole patterns on your adapter.
DO NOT over tighten your screws and bolts as it
may cause damage to the adapter or standard
attachment.
If you're using your own hardware, be sure to use
high grade stainless steel fasteners to avoid
corrosion.
E
4
