AUDAC ARU2 Series Command Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ARU2xx commands manual
Index
Introduction
Using the commands
Configuration and settings commands
GIP
SIP
SEVNT
SGEVNT
SXEVNT
SAS
ASF
SDPUD
SDPU
SGTYPE
SGCFG
Relay commands
SRON
SROFF
SRBUT
SPULS
SDELON
SDELOFF
Paging commands
PGRQ
PG
Misc commands
WOS
GTIME
GDATE
SGREV
SGHW
SGSV
FLCLR
EECLR
1
Get IP
Set IP
Set event
Get event
Execute event
Set address Switch Unit
End set address Switch Unit
Set delayed power up Delay
Set delayed power up
Get the type of switch unit
Get config
Switch on relay
Switch off relay
Switch on 1 relay, rest is switched off
Puls relay
Switch delay on
Switch delay off
Paging request
Start/Stop paging
Who is online switch unit
Get time
Get date
Get hardware revision
Get hardware type
Get software revision
Erase flash
Erase EEPROM
2
3
4
4
4
4
5
5
5
5
6
6
6
6
7
7
7
8
8
9
10
10
10
10
11
11
11
11
11
12

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARU2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AUDAC ARU2 Series

Summary of Contents for AUDAC ARU2 Series

  • Page 1 ARU2xx commands manual Index Introduction Using the commands Configuration and settings commands Get IP Set IP SEVNT Set event SGEVNT Get event SXEVNT Execute event Set address Switch Unit End set address Switch Unit SDPUD Set delayed power up Delay SDPU Set delayed power up SGTYPE...
  • Page 2 Welcome to the commands user manual of the Audac ARU2xx series. This manual describes the commands whereby the range of relay units can be controlled using their remote control ports. The ARU2xx series can be controlled using the web interface, audac touch 2 or by RS485 and TCP/IP commands which are listed further in this document.
  • Page 3 Using the commands Depending of the type of device the different kinds of communication ports are: - RS-485 port - TCP/IP port RS485 Configuration details RJ45 (RS485, Digital audio, +24V DC): For connection to Wall Panels & Paging Consoles Pin 1 White-Orange AUDIO TX A Pin 2 Orange AUDIO TX B Pin 3 White-Green...
  • Page 4 CONFIGURATION AND SETTING COMMANDS Get info about the ip address, subnet mask and gateway the relay unit is using: Command: Arguments: None (0) Feedback: dhcp^ip4.ip3.ip2.ip1^mask4.mask3.mask2.mask1^gw4.gw3.gw2.gw1^ DHCP: dhcp ON(1) or OFF(0) IP: IP4 address of unit MASK: subnet mask GW: IP4 address of gateway Example: Get info about the IP address #|S001|F001|GIP||crc|<CR><LF>...
  • Page 5 SGEVNT Set event: Command: SGEVNT Arguments: xx: event nr Feedback: ^xx^cc^hhmmss^yymmdd^ww^dest^cmd^param^U xx: event nr cc: header, must be 55 for valid event hhmmss: time for event to execute yymmdd: date for event to execute ww: weekday for event to execute dest: Address of ARU cmd: cmd to execute can be SRON, SROFF, SRPULS, SRBUT...
  • Page 6 SDPUD Set delayed power up Delay Command: SDPUD Arguments: x: 1 to 9999 ms power up sequence at startup 0 Use potentiometer for timing Feedback: +: Acknowledge Example: set delay to 99ms #|S001|web|SDPUD|99|crc|<CR><LF> ARU replies: #|web|S001|SDPUD|+|crc|<CR><LF> SDPU Set delayed power up Command: SDPU Arguments:...

  • Page 7: Relay Commands

    RELAY COMMANDS In paging mode (set by jumper B in top position) The relays are by default powered ( relay is in NO position ) The relay switches off when bit is set( relay is in NC position ) In normal mode (set by jumper B in bottom position) The relays are by default not powered ( relay is in NC position ) The relay switches on when a bit is set( relay is in NO position ) SRON...
  • Page 8 SPULS Puls relay Command: SPULS Arguments: tttt^00rr tttt: time to pulse relay in 1/10s rr: 8 bit hex value, bit0 = relay 1 bit7 = relay 8 if bit = 1 then relay is active Feedback: +: Acknowledge Example: Relay 1 of S001 is pulsed for 0.5 seconds #|S001|web|SPULS|0005^0001|crc|<CR><LF>...
  • Page 9 SDELOFF Switches all relays off with a delay. Command: SDELOFF Arguments: dddd dddd: 0 to 9999ms delay between each relay Feedback: +: Acknowledge Example: swith all relays off with 100ms delay time #|S001|web|SDELOFF|0100|crc|<CR><LF> ARU replies: #|web|S001|SDELOFF|+|crc|<CR><LF> and status from all relays #|ALL|S001|SZSET|007F|crc|<CR><LF>...

  • Page 10: Paging Commands

    PAGING COMMANDS PGRQ Paging request Command: Arguments: pppp^ww^0000rrrr^l pppp: priority level 0000 to 9999 ww: wallpanel port (must be 00 for ARU) rrrr: zones to page : 32 bit bit0=zone 1 bit31=zone 32 l: local=0 or global=1 (must be 1 for ARU) Feedback: +: Acknowledge Example: A001 send request to S001 for zone4...
  • Page 11 GDATE Get date Command: GDATE Arguments: Feedback: dd/mm/yyyy Example: get date from relay unit #|SOO1|web|GDATE||U|<CR><LF> ARU replies: #|web|S001|DATE|24/10/2019|crc|<CR><LF> SGREV Get hardware Revision Command: SGREV Arguments: Feedback: Vxxx Example: get hardware Revision #|S001|web|SGREV||U|<CR><LF> ARU replies: #|web|S001|SREV|V1.0|crc|<CR><LF> SGHW Get hardware type Command: SGHW Arguments: Feedback:...
  • Page 12 EECLR Erase EEPROM Command: EECLR Arguments: Feedback: +: Acknowledge Example: erase EEPROM #|S001|web|EECLR||U|<CR><LF> ARU replies: #|web|S001|EECLR|+|crc|<CR><LF>...
