- Page 1 ARU20x User Manual www.audac.eu...
- Page 2 However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest instruction manual or obtain additional product information, please visit the product page on www.audac.eu. For information about software version updates, please visit www.audac.eu/software.
-
Page 3: Table Of Contents
Index Introduction Precautions Safety requirements Caution servicing EC Declaration of Conformity Waste of Electrical and Electronic Equipment (WEEE) Caution Chapter 1: Pin connections and connectors Connection standards Chapter 2: ARU20x Overview Connection description Contact description Internal settings Connections overview Chapter 3: Wiring up the system Chapter 4: Application examples Chapter 5: User interface &... -
Page 5: Introduction
Various ways of switching the relays are provided, including an integrated web interface, optional paging consoles and analog contact triggering making the ARU20x AUDAC’s smartest and most innovative relay modules. With this ingenious device, switching between audio sources, signal routing, and even customized automation setups are obtainable. -
Page 6: Precautions
Precautions READ FOLLOWING INSTRUCTIONS FOR YOUR OWN SAFETY ALWAYS KEEP THESE INSTRUCTIONS. NEVER THROW THEM AWAY ALWAYS HANDLE THIS UNIT WITH CARE HEED ALL WARNINGS FOLLOW ALL INSTRUCTIONS NEVER EXPOSE THIS EQUIPMENT TO RAIN, MOISTURE, ANY DRIPPING OR SPLASHING LIQUID. AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS DEVICE. DO NOT INSTALL THIS UNIT NEAR ANY HEAT SOURCES SUCH AS RADIATORS OR OTHER APPARATUS THAT PRODUCE HEAT DO NOT PLACE THIS UNIT IN ENVIRONMENTS WHICH CONTAIN HIGH LEVELS OF DUST,... -
Page 7: Waste Of Electrical And Electronic Equipment (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE) The WEEE marking indicates that this product should not be disposed with regular household waste at the end of its life cycle. This regulation is created to prevent any possible harm to the environment or human health. -
Page 9: Chapter 1: Pin Connections And Connectors
Chapter 1 Pin connections and connectors CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed corresponding to international wiring standards for professional audio equipment. RJ45 (RS485, Audio, +24V DC): For connection to paging consoles and/or other RS485 peripheral equipment... -
Page 10: Chapter 2 Aru20X Overview
The control of the system is possible through the integrated HTML5 web-page which runs on the integrated web server, while control through commands or the Audac Touch™ application is also possible. To ensure a reliable connection, always use CAT5E (or better) cabling and 10 Mbit compatible network infrastructure. -
Page 11: Contact Description
NOTE The use of the dry contact inputs will priority over the digital control functions. There won’t be any direct feedback or monitoring possible through to the digitally controlling devices. All connects must be “dry” contacts (voltage free) Relay input contacts: The relay input connections are available on the upper side of the ARU20x and are marked with the x2 (x2’) and x4 (x4’) indicators. -
Page 12: Internal Settings
Internal settings The following settings are configurations which might be required to get configured one single time when setting up / configuring the system. They are configured through jumpers which are located on the PCB of the ARU20x housing, requiring the top cover from being removed before making any adjustment. - Page 13 Normal mode / paging mode: These jumpers (JP2) allow selection of the operation mode between normal and paging mode. The unit is default configured to be used in paging mode. Paging mode (default) Normal mode Paging mode: At power-on, all relays will be activated and will be switched to background music mode.
-
Page 14: Connections Overview
Connections overview 1) 24 V DC mains voltage input connection 2) Ethernet RJ45 connection 3) RS485 databus connection (RJ45) with linkthrough for daisy chaining (only ARU208) 4) Contact trigger inputs 5) Relay contact outputs 6) Analogue audio line out connection (balanced) 7) Normal open (NO) relay contact inputs 8) Normal closed (NC) relay contact inputs... -
Page 15: Chapter 3 Wiring Up The System
Chapter 3 Wiring up the system NOTE Make sure the power of the system is switched off, when any changes to the connections are being made. RS485: In case your system is using the RS485 bus protocol, avoid making any star structured constructions in your cabling. -
Page 16: Chapter 4 Application Examples
Chapter 4 Application examples Example 1: The above diagram shows an example of a simple and basic setup with an APM1xx paging console in an analogue paging setup, combined with an ARU20x relay unit. Besides the APM1xx paging console, a background music source (ISP40 in this typical setup) is con- nected. -
Page 17: Chapter 5: User Interface & Configuration
When application specific or total system control is required, the ARU20x can be controlled using the Audac Touch™ application. This application allows to custom configure your control panel (Dashboard) according to project or user specific requirements. -
Page 18: Dashboard
NOTE If application specific limitations or restrictions for certain functions are required, the system control can be done through the Audac Touch™ freely available application, which allows you to create customized control dashboards. Dashboard The dashboard (main) screen gives an overview of all the buttons, which are required for triggering and activating the relays. -
Page 19: Events
Events The events screen gives an overview and provides the possibility for programming up to 50 timer scheduled actions. Various actions such as switch on, switch off, pulse and radio can be programmed. They can be programmed on single occasions (date) or recurring times (repeat). NOTE When using the timer scheduled events functions for the ARU20x, it shall be connected to a network with access to a time server. -
Page 20: Settings
For single recurring events the option ‘Date’ should be selected and the date shall be entered in the format DD/MM/YY, where DD stands for day, MM stands for month and YY stands for year. The time when the event should take place shall be entered in the format HH:MM:SS, where HH stands for hour, MM stands for minutes and SS stands for seconds. - Page 21 The DCHP function is standard switched off and can be turned one by clicking and enabling the corresponding indicator. The factory default network settings are as follows: DEFAULT NETWORK SETTINGS DHCP: OFF IP Address: 192.168.0.197 Subnet mask: 255.255.255.0 Gateway: 192.168.0.253 DNS1: 8.8.4.4 DNS2: 8.8.8.8 DHCP:...
- Page 22 The delayed startup can be activated through enabling the indicated button, and the delay time (the delay between each two relays triggering) can be configured analogue (through a potentiometer located on the ARU20x PCB) or digitally through entering a milliseconds value inside the corresponding text field.
- Page 23 Security: The password settings for both user and administrator level access can be changed in this screen. The administrator level has access to all functions (including events and settings) while the user level only has access to the dashboard functions. To change the passwords, click ‘change’...
-
Page 24: Chapter 6: Ip Basics
IP range, the AUDAC products will not be accessible from your network. You can change the IP address of the AUDAC products to make them work properly in your network. This can be done in the settings menu, and is described extensively in the “Settings” chapter of this user manual. - Page 25 E ach ARU208/4 device is shipped from the factory with a default IP address of 192.168.0.197 in order to connect to the embedded web interface your PC must be within the same range as the device.
-
Page 26: Chapter 7: Technical Specifications
250 V AC / 2A - Max 62.5 VA 24 V DC / 2A - Max 30 W Control RS485 Communication bus (RJ45) Manual (contact) relay activation (terminal block) TCP/IP - Ethernet - 10 Mbit (RJ45) Audac Touch™ HTML5 Embedded web-page Max cable length RS485 300 meter Ethernet... - Page 27 Notes...
- Page 28 Notes...
