  • Page 1 DS-OLS7-FRS4 Technical Manual Technical Manual VER 1.0 DS-OLS7-FRS4 page│1...
  • Page 2 Contents Table of Contents Click to return to table of contents 1. Features…………………………………………………………………………...………………3 2. Technical Parameters…………………………………………………………...……………...3 3. Schematic and Interface Definition..................4. Power Supply…………………………..…………………………………………………………….. Voltage…………………………………………………………………………….……………….8 Current…………………………………………………………………………………………….. 8 Regeneration of Discharge……………………………………………………………………...8 5. Motor Connection……………………………………………………………………………..……….9 6. Signal Input………………………………………………………………………………………...…10 Pulse Signal :STEP…………………………….…………………………..……………………10 Direction Signal : DIR……………………………………………………………………………10 Pulse / Direction Input Timing diagram…………………………………………..……………...
  • Page 3 Adapted to two-phase hybrid stepping motor, DS-OLS7 FRS4 Adapter motor Maximum fit 3.2A Power supply 24 - 48V DC Output current DS-OLS7-FRS4：0.1A-3.2A/ phase Drive mode Full-bridge bipolar PWM driver IN1（DIR）signal Optocoupler input voltage H = 3.5 - 26.0V , L = 0 - 0.8V Input signal On current 6-15mA IN2（STEP）signal...
  • Page 4 Schematic and Interface Definition 3. Schematic and Interface Definition 1) Signal input (as shown from left to right) Operation mode selection 0: external pulse 1 pin --- pulse STEP +, 2 pin --- pulse STEP-, 3 pin --- direction DIR +, 4 pin --- direction DIR- 5 feet --- output OUT +, 6 feet --- output OUT- Operation mode selection 1: internal pulse Pin 1 --- Input port IN1 +, Pin 2 --- Input port IN1-, Pin 3 --- Input port IN2 +, Pin 4 --- Input port IN2-...
  • Page 5 Schematic and Interface Definition 4) mailing address Users can control up to 30 DS-OLS7-FRS4 drives simultaneously using the RS-485 bus. The drive communication address setting uses a 5-digit DIP switch. The address setting range is 1-32, where address 32 is reserved for the system. When the drive address setting is greater than 31, it needs to be set and saved using the upper debugging software.
  • Page 6 Schematic and Interface Definition 5) Communication baud rate DIP switch Baud rate (bps) 4800 9600 19200 38400 6) Test run The commissioning function is used to verify the performance of the drive. Turn the SW8 switch to ON when the power is off. Then, after power-on, without pulse input, the SW8 gear dial switch is turned from the ON position to the OFF position.
  • Page 7 Schematic and Interface Definition 8) Idle current After 500 milliseconds of no pulse input, the current will automatically enter the idle current to reduce motor heating. The current is restored to the set value during pulse input. 9) Indicator function This product has 2 LEDs indicating that the light shows the working status: 1.
  • Page 8 Power Supply 4. Power Supply 4.1 Voltage The chopper driver continuously changes the size and direction of the motor winding voltage and detects the current to obtain accurate phase current. If both high efficiency and low noise are to be ensured, the driver supply voltage shall be at least 5 times the motor rated phase voltage (that is, the motor rated phase current ×...
  • Page 9 Power Supply / Motor Connection regenerative discharge device. Please note that the positive and negative terminals of the power supply should not be inversely connected when there is no anti-inversely connected function. The driver damage caused by inversely connected power supply cannot be guaranteed. 5.
  • Page 10 Motor Connection / Signal Input 1) The corresponding colors of different motors are different. When using the motors, the specifications of the motors shall prevail. For example, the colors of 57 and 86 motor wires are different. 2) The phases are relative, but the windings of different phases cannot be connected to the terminals of the same phase of the driver (A +, A- is one phase, B +, B- is the other phase).
  • Page 11 Signal Input frequency. The commutation signal must be changed after the last STEP pulse of the previous direction signal and before the first STEP pulse of the next direction. When no commutation is required, the direction signal terminal can be left floating. 6.3 Pulse / Direction Input Timing Diagram Input signal waveform and timing (single pulse method) STEP Input...
  • Page 12 Typical Signal Connection 7. Typical Signal Connection 7.1 Common Positive Connection The pulse and direction terminals have a constant current input function, which Notes can be directly connected to the input signal without external series resistor step- down current limiting protection. The VCC value is 3.5-26V. page│12...
  • Page 13 Typical Connection of Signal Output 8. Typical Connection of Signal Output 8.1 Relay Connection When the relay is connected, it is required to connect diodes at both ends of the Notes relay (such as IN4000 series) 8.2 Optocoupler Connection The alarm output is optically isolated, with a maximum voltage of 30VDC and a maximum saturation current of 50mA.
  • Page 14 Typical Connection of Signal Output / Wiring Requirements example Connecting with Keyence products 9. Wiring Requirements 1) In order to prevent the driver from being disturbed, it is recommended to use shielded cable for the control signal, and the shield layer should be shorted to the ground. Except for special requirements, the shielded wire of the control signal cable is grounded at one end: the upper end of the shielded cable is grounded The driver end of the wire is left floating.
  • Page 15 Installation Dimensions 10. Installation Dimensions (unit : mm) [ Drive installation ] Install with narrow sides, and install with M3 / M4 screws through the holes on both sides. The power device of the driver will generate heat. If it works continuously under high input voltage and high power conditions, it should expand the effective heat dissipation area or force cooling.
  • Page 16 Control Parameter 11. Control Parameter Informal version of communication parameters, some parameters are fixed Notes and not open. 11.1 Controller Basic Status (Class 01) word content Elaborate Range / unit 0100 Motor current Motor real-time current value 0.1%A 0101 Input voltage Current input voltage 0104 Set up segmentation...
  • Page 17 Control Parameter frequency response. 0241 Input Current Set current 100~3200 0.1A~-3.2A 0242 Set up segmentation Pulses per revolution 200~102400 0244 Pulse mode 1: Pulse + direction mode 2: double pulse mode 0245 Half-flow time Delay time when the motor stops 1~32767 running and enters half flow state (open loop mode is valid)
  • Page 18 Control Parameter 0309 Home speed Default: 1000 1~5000 0.01~50rps 0310 Creeping speed Running speed after hitting the origin 1~5000 Default: 1000 0.01~50rps 0311 Home offset Default: 0 -2000000000~ 2000000000 pulse 0313 Output pulse Running stroke -2000000000~ Absolute position mode: run to the 2000000000 specified position pulse...
  • Page 19 Control Parameter be set when the motor is stopped 12. Back to origin 13. Alarm clear 14. Multi-segment data verification 15. Multi-segment data storage 16. Multi-segment data starts 17. Multiple data pauses 18. End of multiple segments of data Default: 0 0324 Internal control switch 0-65535...
  • Page 20 Control Parameter 4. Jog forward 5. Reverse jog 6. deceleration and stop 7. Emergency stop 8. Set the current position, which can only be set when the motor is stopped 9. positive limit 10. Negative limit 11. Origin signal 12. Back to origin 13.
  • Page 21 Control Parameter 11.5 Output Block Specification (Class 07) word content Elaborate Range / unit 0420 OUT1 function selection 100: universal port 100~104 101: Alarm output function: There is an output signal when there is no alarm, and there is no output signal when there is an alarm.
  • Page 22 Modbus-RTU Protocol Example 12. Modbus-RTU Example 12.1 Running Motor 12.1.1 Absolute Position Mode Step Add. Word Content Range Unit START 0306 Running Speed 1 ~ 5000 0.01 rps -2,000,000,000 0313 Target Position pulse ~ 2,000,000,000 Step 1 : Set Speed 0323 Control Command 0 ~ 18...
  • Page 23 Modbus-RTU Protocol Example  Example. 2 Step 2 : Set Position Slave ID 1 (0x01) Driver ID Function 16 (0x10) Write Multi Register Address 313 (0x0139) Target Position Quantity 2 (0x02) Quantity of Registers 5000 (0x00001388) 5000 pulse Data -5000 (0xFFFFEC78) -5000 pulse Request Starting...
  • Page 24 Modbus-RTU Protocol Example 12.1.2 Relative Position Mode Step Add. Word Content Range Unit START 0306 Running Speed 1 ~ 5000 0.01 rps -2,000,000,000 0313 Running Stroke pulse ~ 2,000,000,000 Step 1 : Set Speed 0323 Control Command 0 ~ 18 Step 2 : Set Stroke Step 3 : Command Run ...
  • Page 25 Modbus-RTU Protocol Example  Example. 2 Step 2 : Set Stroke Slave ID 1 (0x01) Driver ID Function 16 (0x10) Write Multi Register Address 313 (0x0139) Running Stroke Quantity 2 (0x02) Quantity of Registers 5000 (0x00001388) 5000 pulse Data -5000 (0xFFFFEC78) -5000 pulse Request Starting...
  • Page 26 Modbus-RTU Protocol Example 12.2 Read Motor Status 12.2.1 Read Current Position Step Add. Word Content Range Unit START -2,000,000,000 0117 Current Position pulse ~ 2,000,000,000 Step 1 : Read Position  Example Slave ID 1 (0x01) Driver ID Step 1 : Read Current Position Function 3 (0x03) Read Register...
  • Page 27 Modbus-RTU Protocol Example 12.2.2 Read Current Speed Step Add. Word Content Range Unit START 0.01 0119 Current Speed 1 ~ 5000 Step 1 : Read Speed  Example Slave ID 1 (0x01) Driver ID Step 1 : Read Current Speed Function 3 (0x03) Read Register...
  • Page 28 Modbus-RTU Protocol Example 12.3 Read Alarm Status 12.3.1 Alarm Status Step Add. Word Content Range Unit START 0108 Alarm Status Step 1 : Read Alarm  Example Slave ID 1 (0x01) Driver ID Step 1 : Read Alarm Status Function 3 (0x03) Read Register Address...
  • Page 29 Parts 13. Parts 1. RS485 Communication line ① ( Driver to RS485) Order Model L (mm) Material No. REC-1.0-14.414 1000 09-516 Connector model：XHP-3 Terminal model： SXH-001T-P0.6 Supplier：JST Wiring Harness：UL 2464 28AWG*3C Interface Definition Describe Color RS485 A RS485 B Yellow RS485 GND Black 2.
  • Page 30 International Customer Person in Charge : Daniel Jang daniel@dingsmotion.com Building 1#, 355 Longjin Road, Changzhou Economic Development Zone, Jiangsu, China +86-519-85177826, 85177827 North America Customer Person in Charge : Nicolas Ha sales@dingsmotionusa.com 335 Cochrane Circle Morgan Hill, CA 95037 +1-408-612-4970 China Customer +86-0519-8517 7825...
