- Page 1 Quick Installation Guide PLEASE READ THIS BEFORE CONNECTING AVIOR ANTENNA Copyright©2022 Star Systems International Ltd.
- Page 2 Quick Installation Guide Please read carefully prior to installation 1. Introduction Antenna: AVIOR Item No.: HAN25010-1-M Front Back 60.00 15.00 R5.50 200.00 30.00 Unit: mm The Avior antenna is designed to operate in rugged and harsh roadside environments including severe weather conditions and extreme temperatures.
- Page 3 Quick Installation Guide 2. U-Bolt Installation Figure 1 below describes the U-Bolt installation. Recommended pole dimensions : - Minimum width : 25mm - Maximum width : 50mm U-Bolt U-Bolt Bracket Figure 1 Unit: mm Figure 2...
-
Page 4: Safety Wire Installation
Quick Installation Guide 3. Safety Wire Installation Star Systems International recommends that a steel safety wire is installed using the pre-drilled holes illustrated in Figure 3 below. Attached to gantry securely Gantry Steel Wires Antenna Figure 3... - Page 5 Quick Installation Guide 4. Weatherproof Outdoor Installation If the installation of equipment is outdoors, it is important that users to pay attention to and take all necessary measures to weatherproof the antennas and their cables connections. Per the Certified Wireless Network Administrator (CWNA) Study Guide, it is stated that “Water damage is often a serious problem with cabling and connectors.”...
- Page 6 Quick Installation Guide a. Cable Drip Loop By adding a small drip loop or “U” shape before the cable connects to the antenna or reader, the water will flow along the cable and away from the connector, preventing the water from ingressing into the connector. The drip loop should be positioned lower than the antenna/reader connector to effectively draw dripping water away.
-
Page 7: Tools And Equipment
Quick Installation Guide b. Cold Shrink Tube A Cold Shrink Tube, such as that shown in the photo below, provides a fast and easy way to weatherproof cable connections in the field. In addition, it can help to stabilize and secure the cable connection from wind and vibration. - Page 8 Quick Installation Guide ii. Procedures Run the coax cable through the cold shrink tube Connect the cable connector with the antenna. Tighten connection properly with a torque wrench to ensure the correct internal seals and surface contacts are made. Align the cold shrink tube such that it seals the base of the antenna’s connector.
- Page 9 Quick Installation Guide c. Tape and Butyl Rubber Using electric, vinyl or plastic tape in combination of butyl rubber or mastic wrap is a widely adopted practice for outdoor cable connection weatherproofing procedures. These materials often come bundled as weatherproofing kits which are widely available in the market.
- Page 10 Quick Installation Guide Using 3/4” (19mm) electric, vinyl or plastic tape to wrap the connection, starting at the cable side at about 1” (25mm) from the connector. Overlap the tape to a half-width. Extend the wrapping to the antenna connector base.
-
Page 11: Technical Support
“YOUR SUCCESS IS OUR VISION”. For more information, please visit www.star-int.net Technical Support Visit the SSI’s Website at www.star-int.net and select Smart Cities Solutions > Technical Support to request technical support for your RFID product. Avior Quick Installation Guide version 1.0...
