- Page 1 Quick Installa�on Guide PLEASE READ THIS BEFORE INSTALLING YOUR AVIOR ANTENNA mart Enabling Cities...
-
Page 2: Table Of Contents
Quick Installa�on Guide Contents 1. Introduc�on 2. U-Bolt Installa�on 3. Safety Wire Installa�on 4. Weatherproof Outdoor Installa�on a. Cable Drip Loop b. Cold Shrink Tube c. Tape and Butyl Rubber Copyright©2022 Star Systems International Ltd. -
Page 3: Introduc�On
Quick Installa�on Guide Please read carefully prior to installa�on 1. Introduc�on Antenna: AVIOR Item No.: HAN25010-1-M Front Back 60.00 15.00 R5.50 200.00 30.00 Unit: mm The Avior antenna is designed to operate in rugged and harsh roadside environments including severe weather condi�ons and extreme temperatures. -
Page 4: U-Bolt Installa�On
Quick Installa�on Guide 2. U-Bolt Installa�on Figure 1 below describes the U-Bolt installa�on. Recommended pole dimensions : - Minimum width : 25mm - Maximum width : 50mm U-Bolt U-Bolt Bracket Figure 1 Unit: mm Figure 2 Copyright©2022 Star Systems International Ltd. -
Page 5: Safety Wire Installa�On
Quick Installa�on Guide 3. Safety Wire Installa�on Star Systems Interna�onal recommends that a steel safety wire is installed using the pre-drilled holes illustrated in Figure 3 below. A�ached to gantry securely Gantry Steel Wires Antenna Figure 3 Copyright©2022 Star Systems International Ltd. -
Page 6: Weatherproof Outdoor Installa�On
Quick Installa�on Guide 4. Weatherproof Outdoor Installa�on If the installa�on of equipment is outdoors, it is important that users to pay a�en�on to and take all necessary measures to weatherproof the antennas and their cables connec�ons. Per the Certified Wireless Network Administrator (CWNA) Study Guide, it is stated that “Water damage is often a serious problem with cabling and connectors.”... -
Page 7: Cable Drip Loop
Quick Installa�on Guide a. Cable Drip Loop By adding a small drip loop or “U” shape before the cable connects to the antenna or reader, the water will flow along the cable and away from the connector, preven�ng the water from ingressing into the connector. -
Page 8: Cold Shrink Tube
Quick Installa�on Guide b. Cold Shrink Tube A Cold Shrink Tube, such as that shown in the photo below, provides a fast and easy way to weatherproof cable connec�ons in the field. In addi�on, it can help to stabilize and secure the cable connec�on from wind and vibra�on. - Page 9 Quick Installa�on Guide ii. Procedures Run the coax cable through the cold shrink tube Connect the cable connector with the antenna. Tighten connec�on properly with a torque wrench to ensure the correct internal seals and surface contacts are made. Align the cold shrink tube such that it seals the base of the antenna’s connector.
-
Page 10: Tape And Butyl Rubber
Quick Installa�on Guide c. Tape and Butyl Rubber Using electric, vinyl or plas�c tape in combina�on of butyl rubber or mas�c wrap is a widely adopted prac�ce for outdoor cable connec�on weatherproofing procedures. These materials o�en come bundled as weatherproofing kits which are widely available in the market. - Page 11 Quick Installa�on Guide Using 3/4” (19mm) electric, vinyl or plas�c tape to wrap the connec�on, star�ng at the cable side at about 1” (25mm) from the connector. Overlap the tape to a half-width. Extend the wrapping to the antenna connector base. Cut a piece of butyl rubber large enough to wrap around the connector and extended past the first layer of...
- Page 12 About Us Founded in 2013, SSI is a world leader in Automa�c Vehicle Iden�fica�on Technologies. SSI focuses on providing best-in-class transponders, readers and professional consul�ng services for Smart City Ini�a�ves, including Electronic Tolling (ETC), Electronic Vehicle Registra�on (EVR), Fleet Management, Parking and Secure Access Control applica�ons.
