Preparing to take the measurement
Creating a new patient record
1.
Click on the New Patient icon
2. Recommended: Activate the Consistency Checker
in the App settings
3. Enter the patients:
a. Name
b. Postcode
c. Frame B size
d. Frame fitting heights
4. Click measure at the bottom of the screen
Preparing the frame and clip
1.
Remove the lenses from the frame (if a rimless
frame, ensure the lenses are clean to reduce reflections)
2. Adjust the frame as required for the patient's fitting
3. Fix the clip to the patient's frames
4. Align the clip with the centre of the frame bridge
2
