Summary of Contents for ECP VARILUX X Series
- Page 1 Varilux X series measuring kit – User guide V A R I L U X X S E R I E S M E A S U R I N G K I T U S E R G U I D E For more information visit ecp.essilor.co.uk...
- Page 2 Thank you for purchasing your new Varilux X series measuring kit.
- Page 3 Contents Getting started Preparing to take the measurement Far Vision reference Near Vision Behaviour Varilux X series demonstration screens Exporting to your ordering system ...
- Page 4 Search and download the Varilux X series App from the App store. Please note only compatible with iPad Air & iPad Air 2 2. Open the Varilux X series App and enter your activation code from your pack Connecting to Essilorder...
- Page 5 Preparing to take the measurement Creating a new patient record Click on the New Patient icon 2. Recommended: Activate the Consistency Checker in the App settings 3. Enter the patients: a. Name b. Postcode c. Frame B size d. Frame fitting heights 4.
- Page 6 Patient guidelines Go through the patient guidelines with your patient so they understand what to expect and what to do during the New Vision Behaviour measurement 2. The images demonstrate the patient following the blue dot on the screen with their eyes Practice session Ask your patient: a.
- Page 7 Far Vision reference Getting started Both you and your patient must be stood facing each 75cm (+/-10cm) apart 2. Hold the iPad vertically with the camera at the patient’s eye level and ask them to look at the camera on the back of the iPad 3.
- Page 8 Three-quarter view picture As in the previous front view picture steps, position the iPad vertically until the green dot appears. 2. Ask your patient to slowly turn their head to their left 3. Once the iPad indicates that they have turned their head (+/-5 ) the camera icon(s) will become clickable 4.
- Page 9 Near Vision Behaviour code Click on the patient’s unique Near Vision Behaviour code 2. Explain to your patient their unique combination of posture and visual behaviour and how it will be used to design their personalised Varilux X series lenses...
- Page 10 2. Your patient can experience how standard progressive lenses require them to move their head to see sharp in these near vision activities 3. Ask your patient to click on the screen to experience Varilux X series lenses...
- Page 11 Note: If your ordering system log in details are incorrect, a pop-up message may appear asking you to re-enter your username and/or password For further support on your Varilux X series measuring kit please contact your Essilor Account Manager...
- Page 12 ecp.essilor.co.uk...
