Page 1
WVC Series micro inverter WVC-1200 micro inverter User manual WiFi/433MHz Version INMETOR Intertek 5016924 www.inverter.com sales@inverter.com Globle Shipping +1 800-585-1519...
Page 2
WVC Series micro inverter Parameter WVC1200-433/WiFi Micro inverter model WVC1200-R3-433/WiFi Maximum input power 1400Watt Output voltage mode 120/230V Auto switch PV Open circuit voltage 30-60VOC Operating voltage range 22-60V Starting voltage range 22-60V short-circuit current Maximum working current Output parameters...
Page 3
Normal working indicator flashing process: Connect the micro-inverter to the AC and DC terminals, and then turn on the power → the red light will be on for 3 seconds → the red light will flash for 30 seconds → the green light will flash quickly (MPPT maxim um power point search)→...
Page 4
The communication method of 433MHz is a short connection method, that is, the signal is disconne -cted after sending / receiving. The device for data collection with the inverter is WiFi-MODEM. The communication channel is civilian channel. Long-distance wireless transmission (open area up to 1800 meters, good wall penetration capability, air baud rate 500bps) Operating frequency range (433.4-473.0MHz, up to 100 communication channels) Maximum 100mW (20dBm) transmit power...
Page 5
WVC Series micro inverter 2、Immediately monitor your power plant and keep track of your power plant data: www.inverter.com sales@inverter.com Globle Shipping +1 800-585-1519...
Page 6
WVC series micro-inverter installation guide To properly install and use WVC series micro inverters, please read and follow this guide and all warnings and ins -tructions in WVC micro inverters. The “Installation and Operation Manual” can be downloaded from the official website of inverter Energy: www.inverter.com.Safety warnings are listed on the back of this guide.
Page 7
Step 6 Connect the AC main cable to the utility grid to start your green energy journey. Note: Before installing WVC series micro inverter products, please read this manual and pay attention to the installation details. This manual contains important instructions that should be followed when installing...
