Agio BPS03723 Assembly Instructions

IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD AND RECEIPT
Remove all protective materials and set parts on a flat, non-abrasive surface. Identify parts packed in carton against the

Step 1:

parts list. If you are missing any parts or are unsure how to proceed with assembly, please call our Product Specialists
immediately at 1- 800 416 3511. - -
Insert connector bar into left arm as shown in

Step 2:

Step 3:

Attach seat frame to base using bolts and washers as shown in
drilled hole in the left arm. Hand tighten three to four turns only.
Attach back frame to base using bolts and washers as shown in
drilled hole in the left arm. Hand tighten three to four turns only.
be necessary to ensure proper alignment of the table legs. Repeat for opposite side.

Step 4:

Tighten all bolts. Each bolt must be tightened a 3-4 revolutions only at a time. Begin with top left bolts. Move to
bottom right bolts then to top right bolts, followed by bottom left bolts. Repeat this "X" pattern until all bolts are tight.
DO NOT OVER TIGHTEN BOLTS

Step 5:

Examine the chair from the front. If the sling seat does not appear tight or straight in the seat base, repeat steps 3 & 4.
If you do not feel your chair is assembled properly, or you have any questions,
1- 800 416 3511. - -
IMPORTANT NOTE: Damage to welds or frames resulting from over tightened bolts or improper assembly is not covered
under our warranty.Please read all instructions carefully before assembly. If you have any questions regarding your
assembly, call our Product Specialists at
* NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE

PARTS LIST

DESCRIPTION
A
LEFT ARM
B RIGHT ARM
C
CONNECTOR BAR
D
SEAT FRAME
E
BACK FRAME
F
1/4" X 30 MM BOLT
Do not attempt to assemble the chair if any parts are damaged or missing.
. Repeat for other side for right arm.
Fig. 1
Fig.2
. Guide bolt through hole in seat frame, into pre-
Do not tighten completely
Fig.2
. Guide bolt through hole in back frame, into pre-
Do not tighten completely
. Over tightening may strip bolts, damaging the entire chair.
1-800-491-4958 .
ORDER PART # QTY PARTS LIST
1 G
1 H
1 I
1
1
8
HW0038
. Repeat for opposite side.
. Some adjustments may
call our Product Specialists at
DESCRIPTION ORDER PART # QTY
Ø6.5 X 1.0 MM
HW0004 8
WASHER
BOLT COVER HW0105 8
1
HEX BOLT DRIVER HW0006
FRONT FOOT CAP
FC0307
FACTORY ASSEMBLY
BACK FOOT CAP
HW0078
FACTORY ASSEMBLY
BCS01819
Page 2
A
FRONT B
FOOT CAP
Fig. 1
E
G
D
G
F
H
G
F
H
Fig. 2
C
BACK
FOOT CAP
F
H
