- Page 1 2019+ dodge ram 1500 running board inst alla tion guide Excalibur research development and manufacturing tech support text or call 1 512 870 7828 excaliburrdm@gmail.com If you ha ve any questions please give us a call. excaliburtruckusa.com...
-
Page 2: Tools Required
TOOLS REQUIRED 1. ASSEMBLE THE RUNNING BOARDS. 10mm Socket or Combination Wrench Install the mud guards on the running boards prior to installation. 18mm Socket with 24’’ extension. Locate and identify the left and Breaker bar. right mud guard. Box cutter or sharp knife OPTIONAL: Wax based under coating to cover brackets and hardware at the end of the install. - Page 3 1. LOCATE CAB BRACKET MOUNTING LOCATIONS. 2. PREPARE HARDWARE. Located on the sill of the vehicle there will be three factory The factory hardware is heavily coated mounting locations. There are two different stud positions. in paint. There is a good chance that The same bracket will fit both configurations.
-
Page 4: Base Bracket
5. (A) ADD THE BASE BRACKETS. 4. TIGHTEN THE CAB MOUNTED BRACKETS. With the cab bracket supports mounted, add the base With all the cab brackets mounted in the correct orientation, brackets using the supplied M8X20 bolts and supplied tighten the M8 flanged nuts. flanged nuts. - Page 5 6.6’ & 8’ box ONL Y. NOTE: 5.8’ BOXES DO REAR BRACKET NOT REQUIRE REAR BRACKETS AS THERE INST ALLA TION. ARE ONLY 2 STEPS AND NO BOX MOUNTED STEP. 1. LOCATE AND REMOVE THE DRIVER AND PASSENGER BOX MOUNT BOLTS. On both driver and passenger remove the factory box mounting bolts, located inside of the boxed in bracket welded to...
- Page 6 7. PLACE THE RUNNING BOARD ON THE 8. SNUG THE BOLTS ATTACHING THE RUNNING BRACKETS. BOARDS TO THE BRACKETS. With the rear bracket install complete, place the With the running board placed on all the cab brackets running boards on the base brackets, aligning the T- secure the running boards to the brackets.
- Page 7 SS self drilling screws. the inst all should now be complete. please pass this booklet on to the end user as it has informa tion on maintenance and warranty. for ANY technical difficulties please phone excalibur truck accessories 1 512 870 7828...
-
Page 8: Warranty
The following terms and conditions apply to this warranty; This warranty is only in effect to the original purchaser and shall not apply if the Excalibur Running Boards have been removed from the original vehicle which they were installed on.
