- Page 1 T e k D o c i LY N X T R A I L U S E R M A N U A L C A R B O N 2 0 2 2 M O D E L V 0 .
-
Page 2: Table Of Contents
BATTERY AND CHARGER .................................13 BATTERY CHARGE LEVEL ...............................13 LIFETIME FRAME WARRANTY ..............................4 XPRO BATTERY ..................................15 EXTENDED WARRANTY OF UP TO 5 YEARS ON BH MOTORS ....................5 CHARGING AND DISCHARGING THE XPRO BATTERY ......................15 EXTENDED WARRANTY FOR BH BATTERIES ...........................5 XPRO BOTTLE HOLDER ................................15 REGISTERING EXTENDED WARRANTIES ..........................6... -
Page 3: Introduction
TORX KEY Keep in mind that the manuals on the BH BIKES website are updated on a regular basis. Make sure you have downloaded the latest version from the website. You can check the version on the front page. -
Page 4: Bh Warranty
L I F E T I M E F R A M E W A R R A N T Y Through its authorised stores, BH Bikes provides the original buyer with a commercial policy to cover any manufacturing defects in frames for a period beyond that specified in the product's statutory warranty, pursuant to the following BH BIKES undertakes to offer long-lasting bicycles, in compliance with the highest standards of quality. -
Page 5: Extended Warranty Of Up To 5 Years On Bh Motors
Activating the LIFETIME FRAME extended warranty will automatically activate a 5-year extended warranty for all In a constant effort to improve our customer services on a daily basis, BH offers the best warranty conditions and BH motors. Through its authorised stores, BH Bikes provides the original buyer with a commercial policy to cover the possibility of acquiring an extended warranty for its e-Bike range (an additional one or two years). -
Page 6: Registering Extended Warranties
You must register the bicycle within 30 days after purchase to enjoy the BH BIKES additional warranties. The process As in the case of BH BIKES frames and parts, all electrical components made exclusively for BH will be covered by the to activate the extended warranties is described below: statutory warranty (BH motors feature an extended 5-year warranty after the LIFETIME FRAME warranty is activated). -
Page 7: Maintenance
Failure to observe these recommendations may result in accidents and even death. read the entire manual carefully. The user manuals of all BH models can be consulted on the website at the following The effect of the ground and the forces exerted on the wheel subject the bicycle to a lot of stress. The different address: parts will be subject to fatigue and wear because of these dynamic loads. -
Page 8: Spare Parts
You do not need to take the bicycle to an expert if you are skilled, experienced and have the appropriate tools. Immediately implement the corrective measures if you detect problems. If you are unsure or have queries, please contact BH. -
Page 9: After A Fall, Blow Or Impact
Once home, you should inspect the bicycle carefully again. If you are still unsure or have any queries, requirements associated with their intended use: please contact your nearest BH workshop! Each bicycle has been designed according to a specific intended use. The models described in this manual meet the Bent aluminium parts must not be straightened, i.e., they must not be repaired. -
Page 10: Warnings On Use Of The Electrical Assistance System
Only clean the battery with a dry or damp cloth. • All BH products and parts have been designed to withstand splashed liquids and rain. However, some practices may cause damage to the parts and short circuits. Do not do the following: U N S U I TA B L E C H A R G I N G A N D D I S C H A R G I N G E N V I R O N M E N T S Wash the bicycle with pressure devices. -
Page 11: Pedal Assistance System Operation
C O M P O N E N T S O F T H E P E D A L A S S I S TA N C E S Y S T E M P O W E R B U T T O N The BH Bikes pedal assistance system is made up of the following components: L E D S A. -
Page 12: Start Of Pedalling
The walk assist mode helps the user to transport the bike by foot. To activate this mode, press and hold the + button activated from the BH iConnect app, adding an assistance percentage value other than 0. As in this mode, if on the control panel (it doesn't matter which assistance mode is selected when the + button is pressed). -
Page 13: Displaying The Battery Charge Level
B AT T E R Y A N D C H A R G E R The battery that your BH bike is equipped with contains lithium-ion cells and is the most advanced technology available in terms of energy density (energy stored per kilogram of weight and per cm of volume). - Page 14 0 6 P E D A L A S S I S T A N C E S Y S T E M O P E R A T I O N I L Y N X T R A I L C A R B O N 2 0 2 2 BH 14...
-
Page 15: Xpro Battery
0 6 P E D A L A S S I S T A N C E S Y S T E M O P E R A T I O N I L Y N X T R A I L C A R B O N 2 0 2 2 BH 15... -
Page 16: App Bh Bikes Iconnect
A N D A C C E L E R A T I O N O F E A C H M O D E . D A T A T O T H E B I C Y C L E . The BH Bikes iConnect app can be used to customise the configuration of the pedal assistance system: Change the assistance level colours. -
Page 17: Software Update Of The I-Remote
The BH control panel and display software must be up-to-date at all times. Updates optimise the safety, energy efficiency, reliability and overall operation of the electrical system. Updates are published on a regular basis on the BH Bikes website. You can find them at the path About / Downloads and manuals / Display updates or at the following link: https://www.bhbikes.com/es_INT/quienes-somos/manuales-descargas... -
Page 18: Error Codes
0 6 P E D A L A S S I S T A N C E S Y S T E M O P E R A T I O N I L Y N X T R A I L C A R B O N 2 0 2 2 BH 18... -
Page 19: Sizes And Dimensions
0 7 S I Z E S A N D D I M E N S I O N S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 19... - Page 20 0 8 T E C H N I C A L S P E C I F I C A T I O N S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 20...
- Page 21 0 8 T E C H N I C A L S P E C I F I C A T I O N S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 21...
-
Page 22: Assembly And Spare Parts
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 22... -
Page 23: Fit Stem Assembly
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 23... -
Page 24: Mounting The Built-In Lock On The Saddle's Seat Post
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 24... -
Page 25: Main Pivot Axle
Bolt Bolt 35.2 Plug Nº Item Quantity 10.7 Washer 10.1 BH Post Mount 10.8 Washer 0 9 M A I N P I VOT B E A R I N G 381521000 ref.: 10.2 Swingarm bolt M6xP1.0x18 mm 10.9 Washer Nº... -
Page 26: Exploded View Of The Rocker
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 26... -
Page 27: Shock Absorber Assembly
Quantity 1 6 SHOCK UPPER FIXING AXLE AND BOLT 381524800 1 8 A X L E A N D S P A C E R S 10.10 Mudguard bolt ref.: 10.1 BH Post Mount Nº Item Quantity Nº Item Quantity 10.11 Cable duct cover... -
Page 28: Guards
381528200 ref.: Nº Item Quantity Nº Item Quantity 10.1 BH Post Mount 10.10 Mudguard bolt 1 0 . 3 10.2 Swingarm bolt 10.11 Cable duct cover 1 0 . 3 10.3 Cable duct cover 2 4 X P R O B A T T E R Y B O T T L E 387331000 ref.:... -
Page 29: Chain Guide
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 29... -
Page 30: Speed Sensor, Cable Guides And Stay Bolts Used To Couple The Brakes
3 0 . 1 ref.: Nº Item Quantity Nº Item Quantity 10.1 BH Post Mount 2 9 . 1 10.10 Mudguard bolt 10.2 Swingarm bolt 3 0 . 1 10.11 Cable duct cover 10.3 Cable duct cover 3 1 C A B L E G U I D E S A N D B O LT S... -
Page 31: Cabling Of The Mechanical Parts
0 9 A S S E M B L Y A N D S P A R E P A R T S I L Y N X T R A I L C A R B O N 2 0 2 2 BH 31... -
Page 32: Cabling Of The Electrical System's Parts
Such damage may cause serious injuries or even death. BH recommends going to an official dealer when a diagnosis, repair or installation of electrical components is required. These tasks require advanced technical knowledge. -
Page 33: Wiring Diagram Of The Electrical System's Parts
Such damage may cause serious injuries or even death. BH recommends going to an official dealer when a diagnosis, repair or installation of electrical components is required. These tasks require advanced technical knowledge. -
Page 34: Declaration Of Conformity
Race Carbon 8.0 LT, iLynx Race Carbon 8.2 LT, iLynx Race Carbon 8.4 LT Pro, iLynx Race Carbon 8.6 Pro, iLynx Trail 8.0, iLynx Trail 8.1, iLynx Trail 8.2, iLynx Trail Carbon 8.6, iLynx Trail Carbon 8.7, iLynx Trail Carbon 8.8 Pro, iLynx Trail https://www.bhbikes.com/es_INT/tiendas/buscador-de-tiendas... - Page 35 w w w . b h b i k e s . c o m...
