Summary of Contents for Keller smart slider LD350
- Page 1 smart slider LD350 / LD700 Operating instructions 997-00220-EN 05/2022...
-
Page 2: Table Of Contents
- Operating instructions Keller minimal windows ® Contents Index Title page General Electric operation Maintenance and care Maintenance intervals Faults Decommissioning / Disassembly / Disposal Maintenance report Commissioning declaration Legal notice | 997-00220 | 05-2022 Keller minimal windows ®... -
Page 3: General
- Operating instructions Keller minimal windows ® 01. General General • Completely observe this user manual. • The automatic sliding section should only be operated by instructed adult persons. • No people, animals or other objects may be in the moving zone when the automation is being operated. -
Page 4: Electric Operation
- Operating instructions Keller minimal windows ® 02. Electric operation Principle The horizontally sliding unit is driven by an electric motor that is linked to your sliding mechanism via a toothed belt entirely via the flight bar. If mode: DEAD MAN'S operation The whole movement is controlled via a “dead man's control”, that is, the user must press down the control button... - Page 5 - Operating instructions Keller minimal windows ® 02. Electric operation If mode: SEMI AUTOMATIC operation This means that when the user presses the control button, the automation will open/close the sliding unit almost completely automatically, up to approximately 25 cm from the end (or the danger zone for pinching). To open/close the sliding assembly completely (the last 25cm), keep the command button pressed until the sliding assembly is fully open/closed.
- Page 6 - Operating instructions Keller minimal windows ® 02. Electric operation If mode: AUTOMATIC operation The whole movement is controlled via an “automatic control”, which means that when the user presses the operating button, the automation will fully open or close the sliding assembly automatically. The user remains responsible for the sliding whole in it keep an eye out, make sure that no one is in the danger zone.
-
Page 7: Maintenance And Care
- Operating instructions Keller minimal windows ® 03. Maintenance and care Care of your smart slider system ® Do not treat with caustic or aggressive products. Use water and mild polish to clean the motor u-housing. General safety regulations for maintenance and service •... -
Page 8: Maintenance Intervals
- Operating instructions Keller minimal windows ® 04. Maintenance intervals General The maintenance intervals must be checked according to the service interval specified by the distributor. This service inspection must be recorded in writing. This service inspection must be inspected by a recognized installer or company. - Page 9 - Operating instructions Keller minimal windows ® 04. Maintenance intervals User level maintenance This monthly service can be performed by yourself without the intervention of a qualified technician. • Only use suitable tools. • Subject to technical changes without written notice.
- Page 10 This annual service can only be performed by a qualified technician from your distributor. If anything is not clear about the maintenance or service instruction please contact Keller Minimal Windows SA. To avoid serious personal injury, all directions and instructions in this one should be taken service manual must be carefully read and followed.
-
Page 11: Faults
- Operating instructions Keller minimal windows ® 05. Faults General possible faults Malfunction Possible cause Solution Sliding part does not open/close Obstacle detected See if running way is completely properly free of obstacles and dirt No power Call an qualified technician... -
Page 12: Decommissioning / Disassembly / Disposal
- Operating instructions Keller minimal windows ® 06. Decommissioning / Disassembly / Disposal Take out of operation • Disconnect the installation from the electrical mains and ensure that it remains disconnected during maintenance work! Disassembly General Only qualified assembly / disassembly personnel may be entrusted with the disassembly. -
Page 13: Maintenance Report
- Operating instructions Keller minimal windows ® 07. Maintenance report Report 1. Description : sliding automation unit Type : smart slider ® Performance : Serial Number : Year of construction.: Commissioning on : Manufacturer : AB-Matic nv, Duifhuisstraat 37, 3800 Sint-Truiden, Belgium 2. - Page 14 - Operating instructions Keller minimal windows ® 07. MAINTENANCE REPORT List of inspections • Always note works that have been carried out in writing! • Fill in the maintenance sheet and work order for each inspection / maintenance / repair and have them signed.
-
Page 15: Commissioning Declaration
- Operating instructions Keller minimal windows ® 08. Commissioning declaration Commissioning declaration (file this in the dealer's file) 1. Description : sliding automation unit Type : smart slider ® Performance : Serial Number : Year of construction.: Commissioning on : Manufacturer : AB-Matic nv, Duifhuisstraat 37, 3800 Sint-Truiden, Belgium 2. -
Page 16: Legal Notice
Any transfer to third parties and any further use or exploitation of the contents outside the legal limits - in particular those of the copyright law - is not permitted without the prior written consent of Keller Minimal Windows S.A.. - Page 17 Keller Minimal Windows S.A. 38-40, Route de Wilwerdange L-9911 Troisvierges www.minimal-windows.com 05/2022...
