  • Page 1 LD350 / LD700 Field assembly & commissioning 997-00210-EN 07/2022...
  • Page 2 YOUR PROJECT DATA...
  • Page 3: Table Of Contents

    - Field assembly & commissioning Keller minimal windows ® Contents Index Title page Data sheet Selection criterion table Safety guidelines & procedure Electrical connections Explanation LCD info screen Left or Right opening? Important dimensions Safety sensors and positions...
  • Page 4: Data Sheet

    - Field assembly & commissioning Keller minimal windows ® 01. Data sheet Technical data Drive system electromechanical linear sliding door drive (mounted laterally) Dimensions 100 x 80 mm (w x h) Number of leaves max. 3 (more only on special request)
  • Page 5: Selection Criterion Table

    - Field assembly & commissioning Keller minimal windows ® 02. Selection criterion table LD350 LD700 Note 1 leaf 2 leaf 2400 2400 2000 2000 2000 1600 1600 1500 1250 1200 1200 1000 1000 1000 1000 2000 3000 4000...
  • Page 6: Safety Guidelines & Procedure

    - Field assembly & commissioning Keller minimal windows ® 03. Safety guidelines & procedure Installation manual To avoid serious personal injury, all instructions in this manual must be read carefully and followed up. For questions or topics that are not or not sufficiently described in this manual, please contact the manufacturer or...
  • Page 7: Electrical Connections

    - Field assembly & commissioning Keller minimal windows ® 04. Electrical connections Circuit board 2.00A A-L c < > reset button < operation / scroll program > operation / scroll adjustement contrast LCD Not for customers use, connectors only for manufacturer limitswitch gnd →...
  • Page 8 - Field assembly & commissioning Keller minimal windows ® 04. Electrical connections Factory setting | connectors on side command ← com common input comm. stop (n.c.) ← stop ← close input comm. close (n.o.) input comm. open (n.o.) ←...
  • Page 9: Explanation Lcd Info Screen

    - Field assembly & commissioning Keller minimal windows ® 05. Explanation LCD info screen Description display ‘cockpit’ motor 2.00A consumption in Amp. A-L c < > speed (cm/sec) position in cm (closed position = 0) = open position ...
  • Page 10: Left Or Right Opening

    - Field assembly & commissioning Keller minimal windows ® 06. Left or Right opening Linear drive position v.s. sliding direction 2.00A A-L c < > = direction sliding leaf = to LEFT = linear drive position = on RIGHT sliding direction 2.00A...
  • Page 11: Important Dimensions

    Keller minimal windows ® 07. Important dimensions LD350 - Linear drive & housing dimensions 1200 mm available course 100 mm LD350 - Opening width of the drive way (*) Without linear drive 60 mm 20 mm 75 mm With LD350 130 mm...
  • Page 12 - Field assembly & commissioning Keller minimal windows ® 07. Important dimensions LD700 - Linear drive & housing dimensions 1200 mm Available course 350 mm LD700 - Opening width of the drive way (*) Without linear drive 60 mm...
  • Page 13: Safety Sensors And Positions

    - Field assembly & commissioning Keller minimal windows ® 08. Safety sensors and positions Only for automatic mode CLOSE OPEN moving leaf safety detection zone Look at manual 997-00200 : Planning document These zone must be sufficiently protected against any risk of crushing, both on the inside and the outside.
  • Page 14: General Mounting Instructions

    - Field assembly & commissioning Keller minimal windows ® 09. General mounting instructions Mounting the linear drive u-housing • The drive is already configured according to the ordered situation. • The mounting rail is already provided with screwholes.
  • Page 15 - Field assembly & commissioning Keller minimal windows ® 09. General mounting instructions Connecting the flight bar Please follow the procedure for connecting the linear drive to the sliding leaf according to the production drawings below. It is important to know the type of junction profile is being used.
  • Page 16 - Field assembly & commissioning Keller minimal windows ® 09. General mounting instructions Connecting the flight bar Please follow the procedure for connecting the linear drive to the sliding leaf according to the production drawings below. It is important to know the type of junction profile is being used.
  • Page 17 - Field assembly & commissioning Keller minimal windows ® 09. General mounting instructions Connecting the flight bar Please follow the procedure for connecting the linear drive to the sliding leaf according to the production drawings below. It is important to know the type of junction profile is being used.
  • Page 18 - Field assembly & commissioning Keller minimal windows ® 09. General mounting instructions Adjusting limit switches 9.2.1 UNLOCK SYSTEM First unlock the system with the supplied M5 hexagonal key, turn the hexagonal key clockwise until you feel resistance.
  • Page 19: Master/Slave Setup Procedure

    - Field assembly & commissioning Keller minimal windows ® 10. Master / Slave 10.1 Master / Slave setup procedure What means master & slave • Master = window OPENS first • Slave window wich opens AFTER master is NOT closed Setup procedure •...
  • Page 20: System Setup Procedure

    - Field assembly & commissioning Keller minimal windows ® 11. System setup procedure 11.1 Autoprogram procedure • When starting up and connecting the power supply, a welcome screen will appear followed by the Smart Slider’s display cockpit appears on the screen. (see page 26-27) •...
  • Page 21: Additional Instructions For Double Or Multi Leafs

    - Field assembly & commissioning Keller minimal windows ® 12. Additional instructions 12.1 Multi leaf windows • For multi leaf window parts it is extremely important to program an additional zone at that position where that the main sliding leaf takes the second leaf (or further leafs) to ensure a soft 'take away' action. (Soft Touch) •...
  • Page 22: Operating Mode Explanation

    - Field assembly & commissioning Keller minimal windows ® 13. Operation mode explanation 13.1 PULSE mode • Deadman operation, the user presses a control button near the system with full view of the operation, as long as the user presses the control button it moves the leaf in open or close direction.
  • Page 23: Menu Modus

    AUTO PROG. SS Plus + (page 27-28) Learning mode obstacle detection Top Slider = not in use TS Plus = topslider LD350 MULTI WINDOWS (telescopic systems) (page 29) TS Plus+ = topslider LD700 Soft Run distance 5 - 40 cm...
  • Page 24: Menu Parameters

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.2 MENU PARAMETERS MENU : PARAMETERS factory Parameter explanation LCD screen Additional information Min. Max settings Power during opening (*) At normal speed 0 - 99 %...
  • Page 25 - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.2 MENU PARAMETERS MENU : PARAMETERS factory Parameter explanation LCD screen Additional information Min. Max settings Automatic closing 0=OFF only in AUTO modus 0-99 sec Auto Cl.time: 0s for pedestrian opening (*) P=Prog.
  • Page 26: Menu Logics

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.3 MENU LOGICS MENU : LOGICS factory Parameter explanation LCD screen Additional information Min. Max settings Work mode DEAD MAN, Modus: Puls (see also page 14) AUTO (auto) P=Prog.
  • Page 27 - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.4 MENU AUTO PROGRAM MENU : AUTO Prog. NOTE: Always ensure that this action is performed under safe conditions by a specialized technician. During this operation, there is no obstacle detection as automatic motor actions take place.
  • Page 28: Menu Auto Program

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.4 MENU AUTO PROGRAM MENU : AUTO Prog. Parameter explanation LCD screen Additional information All data will be saved Saving values ... (power graph) Closed at 0 zero 3/4 Last closing &...
  • Page 29: Menu Multi Leafs

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.5 Menu MULTI LEAFS MENU : MULTI-WINDOWS factory Parameter explanation LCD screen Additional information Min. Max settings Soft run area Soft run period 0-40 cm (10)
  • Page 30: Menu Data

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.6 Menu DATA MENU : DATA factory Parameter explanation LCD screen Additional information Min. Max settings Number of OPEN cycles < > to continue Open Cycles: Number of CLOSE cycles <...
  • Page 31: Menu Only Expert

    - Field assembly & commissioning Keller minimal windows ® 14. Menu modus 14.9 Menu ONLY EXPERT (use only by professionals) MENU : ONLY EXPERT factory Parameter explanation LCD screen Additional information Min. Max settings Lock test menu LockTest: P=Next <>=DN/UP...
  • Page 32 NOTES...
  • Page 33 NOTES...
  • Page 34 NOTES...
  • Page 35: Legal Notice

    Any transfer to third parties and any further use or exploitation of the contents outside the legal limits - in particular those of the copyright law - is not permitted without the prior written consent of Keller Minimal Windows S.A..
  • Page 36 KELLER Minimal Windows S.A. 38-40, Route de Wilwerdange L-9911 Troisvierges www.minimal-windows.com 07/2022...
