SOGEDIS 371E Manual

1. It enables the setting value of fridge to be modified and super cool mode to be activated
if desired. Freezer may be set to -16,-18,-20,-22,-24 °C, SF.
2. It is the Super Freeze mode symbol.
3. It is the alarm symbol.
4. It is the freezer set value screen.
Super Freezing Mode :
• To freeze plenty of food
How to use;
• Press set button until 'SUPER' led blink.
During this mode:
• Super freeze mode can be cancelled by the same
operation of selecting.
Demo mode :
This mode will be use for only sales points by salesman to show functions & modes to
customer without operating components as a compressor, fan, motor..Etc
Entering Demo mode:
•Firstly the power is on , with in 1 minute set the temperature to ''SUPER'' and user will push
''SET'' button for 10 seconds , Then appliance will go on "demo function" and Super LED
symbol will blink during the mode.
•All functions can be adjusted to show how they are adjusted to the customer.
Canceling Demo mode:
•For cancelling; Same operation will be used. If user will push SET button for 10 seconds,
demo function will be cancelled.
•When appliance is Demo mode; if plug is removed or there is an electricty breakdown;
demo mode will continue with current settings after user plug into or electricity breakdown
finish.
371E PUSH BUTTON DISPLAY
Display and Control Panel
1
NOVEMBER 2017
