FREEZER – 243
INFORMATION
1. Ice tray
2. Freezer control panel
3. No Frost air circulation system
4. Freezer upper room cover
5. Freezer bottom room cover
6. Freezer compartment drawers
7. Adjusable Foot
JANUARY 2017
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 243 and is the answer not in the manual?

Questions and answers

Related Manuals for SOGEDIS 243

Summary of Contents for SOGEDIS 243

  • Page 1 FREEZER – 243 INFORMATION 1. Ice tray 2. Freezer control panel 3. No Frost air circulation system 4. Freezer upper room cover 5. Freezer bottom room cover 6. Freezer compartment drawers 7. Adjusable Foot JANUARY 2017...

  • Page 2: Display And Control Panel

    FREEZER – 243 DISPLAY and CONTROL PANEL 1. It enables the setting value of fridge to be modified and super cool mode to be activated if desired. Freezer may be set to -16,-18,-20,-22,-24 °C, SF. 2. It is the Super Freeze mode symbol.

  • Page 3: Freezer Temperature Settings

    FREEZER – 243 DISPLAY and CONTROL PANEL Freezer Temperature Settings • The initial temperature of the Setting Display is -18°C. • Press freezer setting button once. • Every time you press the button, the setting temperature will decrease. (-16°C, -18°C, - 20°C,..

  • Page 4: Fault Codes

    FREEZER – 243 FAULT CODES Sensor short open circuit defect on display USER MODE SERVICE MODE SENSOR TEMPERATURE REACTION REACTION >+50°C or <-50°C (1) Freezer -16 Set Symbol blinks (sensor is short or open) (2) Refrigerator (3) Defrost Short (< 100W) or <-50°C...

  • Page 5: Entering Service Mode

    FREEZER – 243 SERVICE MODE Entering service mode: Push SET button continuously for 10 seconds when -24 set symbol active. Appliance will enter service mode 10 sec. later. Canceling service mode: Push SET button continuously for 10 seconds when -24 set symbol active. Appliance will enter service mode 10 sec.
  • Page 6 FREEZER – 243 CHANGING THE DOORWAY DIRECTION 2. Unscrew the screws fixing the upper hinge and 1. Remove the hinge cover. (Pic-1) remove it. (Pic-2) Picture-2 Picture-1 3. Replace the door top bushing (Pic-3.1) and top bushing cap. (Pic-3.2) Picture-3.1 Picture-3.2...
  • Page 7 FREEZER – 243 CHANGING THE DOORWAY DIRECTION 5 . Unscrew the bottom hinge fixing screws and insert them the left side. (Pic-5.1 / Pic-5.2) Picture-5.1 Picture-5.2 6. Remove the door bottom bushing and insert it into left hole. (Pic-6) Picture-6 8.

  • Page 8: Assemble & Disassemble

    FREEZER – 243 ASSEMBLE & DISASSEMBLE Replacement Main Board Warning: Make sure the unit is unplugged. 1. Unscrew the head panel caps and screws. (Pic-1.1 / Pic-1.2) Picture-1.1 Picture-1.2 3. Unplug socket on the board assembled 2- Remove the head panel. (Pic-2) head panel.
  • Page 9 FREEZER – 243 ASSEMBLE & DISASSEMBLE Replacement Fin Evap Group Warning: Make sure the unit is unplugged. 1. Unscrew the condanser screws. (Pic-1) 2. Push the condanser up side and remove.(Pic-2) Picture-1 Picture-2 3. Remove the sealing material at the 4.
  • Page 10 FREEZER – 243 ASSEMBLE & DISASSEMBLE 5. Unscrew the 2 screws shown at the picture. (Pic-5.1 / Pic-5.2) Picture-5.2 Picture-5.1 6. Remove the flap cover supports left and right. (Pic-6.1 / Pic-6.2) Picture-6.1 Picture-6.2 7. Take out the fin evap group. (Pic-7) 8.
  • Page 11 FREEZER – 243 ASSEMBLE & DISASSEMBLE 9. Remove the fin evap box. (Pic-9.1 / Pic-9.2) Picture-9.1 Picture-9.2 10. Remove the black metal clippers. 11. Detach the evaporator from the defrost (Pic-10) heater. (Pic-11) Picture-10 Picture-11 12. Take out the fin evap heater connector.
