Autostar Menus - Meade ETX Premier Instruction Manual

e
Want to learn more
about using the GO TO
function? See page 19.
Want to learn how to
perform a spiral
search? See page 19.
10
B
2-Line LCD Display: This screen displays AutoStar's menus and information
about the telescope.
• Top line: Lists the primary menu.
• Bottom line: Displays other menus that may be chosen, menu options,
telescope status or information about a function that is being per-
formed.
c
ENTER Key: Press to go to the next menu level or to choose an option in a menu.
The ENTER key is similar to the RETURN or ENTER key on a computer. See
ING THROUGH AUTOSTAR'S MENUS
d
MODE Key: Press to return to the previous menu or data level. The top menu level
is "Select Item." The MODE key is similar to the ESCAPE key on a computer.
Note: Pressing MODE repeatedly while in the "Select Item" level moves
AutoStar to the topmost screen: "Select Item: Object."
If MODE is pressed and held for two seconds or more, information about the
telescope's status displays. When the status displays, press one of the Scroll
keys (7, Fig. 2) to display the following information:
• Right Ascension and Declination (astronomical) coordinates
• Altitude (vertical) and Azimuth (horizontal) coordinates
• Local Time and Local Sidereal Time (LST)
• Timer and Alarm Status
• Date
• Site coordinates
• Battery status
• SmartFinder Finder Set menu (see below)
Press MODE again to return to the previous menu.
Finder Set menu: Select the Finder Set menu to access options that will allow you to
set the intensity and blink rate of the SmartFinder red dot.
To set the blink rate of SmartFinder's red dot
1. Press and hold MODE
2. Keep pressing the Scroll Down key
b
3. Press ENTER . "Finder Set: Intensity" displays.
4. Press the Scroll Down key
b
5. Press ENTER . A time value, in seconds, displays. For example, "00.5" may
display. "00.5" (one-half second) is the amount of time, in seconds, that the red
dot will blink "on."
6. Use the Number keys
example, you may wish to change the amount of time the red dot stays on to 10.2
seconds: Press "1," press the Right Arrow key
f
key , press "2." An alternate method is to use the Scroll keys
through the time values. Once the time value is entered, press ENTER
7. Press the Scroll Down key
time value, "00.1" (one-tenth second), may display. For example, you may wish to
change the amount of time the red dot stays off to 00.7 seconds: Press the Right
f
Arrow key twice (as the first two values are already zero), then press "7." Or
you may use the Scroll keys
8. The SmartFinder's red dot will now blink on for 10.2 seconds and turn off for 0.7
seconds, and then repeat the cycle until you change the values again. Press and
c
hold MODE to exit this function.
Similarly, you can set the Intensity value by scrolling through the intensity values with
h
then Scroll keys . The option lets you select a value of intensity for the red dot from
0 (Off) to 14 (Full Intensity).
e
GO TO Key: After the telescope is aligned, press to slew (move) the telescope to
the coordinates of the currently selected object. While the telescope is
slewing, the operation may be aborted at any time by pressing any key except
GO TO. Pressing GO TO again resumes the slew to the object. Also, press
during the alignment or GO TO procedures to activate a "spiral search."
, page 21 and
(circled numbers refer to Fig. 4)
c
for two seconds. R.A and Dec. coordinates display.
h
until "Finder Set: Set" displays.
h
. "Finder: Blink On" displays.
g f
and the Arrow keys
f
, press "0," press the Right Arrow
h
. "Finder: Blink Off" displays. Press ENTER
h
to scroll through the time values.
, page 22.

AUTOSTAR MENUS

:
to change the time value. For
h
to scroll
b
.
MOV-
b
. A
