  • Page 1 ® Heat Link PEX-a Potable Water Press System Installation Guide...

  • Page 2: Table Of Contents

    Table of Contents About Us Introduction HeatLink® Potable Water System Advantages PEX Tubing Ratings Plastic Pipe Institute (PPI) PEX Tubing Ratings Plenum Rating Product Listings Limitations Limitations on PureLink® PEX Tubing Limitations on HPP Fittings & Multiport Tees Limitations on NL Brass Fittings and SS Sleeves Important Notice! General Repair and Testing Kinked Tubing Repair...

  • Page 3: About Us

    HeatLink has developed and manufactured many industry firsts, such as the “TwistSeal“ tool-less manifold in 1996. The company began manufacturing PEX-a tubing in 1998, and now supplies the highest quality PEX-a systems to customers throughout North America, and parts of Europe and Asia.

  • Page 4: Introduction

    Installations must follow all applicable local building and plumbing codes and regulations. The HeatLink® Potable Water Press System features PureLink® Plus PEX-a tubing, high performance polymer (HPP) fittings and multiport tees, no lead fittings, and stainless steel press sleeve connection technology.

  • Page 5: Pex Tubing Ratings

    PureLink® Plus PEX-a tubing is listed with a standard grade rating in PPI TR-4 as tested in accordance with PPI TR-3. PureLink Plus tubing carries the temperature and pressure ratings shown in the table below.

  • Page 6: Plenum Rating

    Plenum Rating PureLink Plus PEX-a tubing has been tested in accordance with CAN/ULC S102.2-2007/2010, Standard for Surface Burning Characteristics of Flooring, Floor Covering and Miscellaneous Materials and Assemblies and ASTM E84, Standard Test Method for Surface Burning Characteristics of Building Materials.

  • Page 7: Product Listings

    It is the sole responsibility of the installer to verify that the product and installation meets local standards. PureLink® Plus PEX-a tubing is approved for use with fittings that are compliant with ASTM F1807/F1960/F2080/F2098/F2159 standards. When using HeatLink tubing with fittings from other manufacturers, ensure to follow all applicable installation requirements and instructions, as well as local building codes to ensure proper connections are made.

  • Page 8: Limitations

    Limitations Limitations on PureLink® PEX Tubing Do Not expose to open flame. Do Not permanently expose to UV light. Do Not use glue, or any material that affects the basic properties of crosslinked polyethylene. Do Not use above ratings. Do Not install within 6" (15 cm) of any gas appliance vent piping, or within 12" (30 cm) of any recessed light fixtures.

  • Page 9: General Repair And Testing

    General Repair and Testing Kinked Tubing Repair One of the most important features of PureLink® PEX-a crosslinked tubing is its shape memory. As such, a kinked area can be repaired using the following procedure: Release system pressure. Straighten portion of tubing being repaired (do not squeeze with pliers).

  • Page 10: Purelink® Installation Guidelines

    PureLink® Installation Guidelines General Practices Install PureLink® PEX at least 12" vertically, or 6" 12" Minimum horizontally away from heat sources such as recessed light Vertical fixtures, or gas appliance vent piping. Distance For UL1598 approved Type IC thermally protected luminaires, clearance can be reduced to 1".

  • Page 11: Expansion And Contraction

    If PureLink® PEX is notched or cut, the damaged section must be cut out. HeatLink approves the burial of PureLink® Plus PEX-a tubing in concrete. HeatLink recommends continuous length tubing (no fittings) when installing PureLink® PEX tubing in or under a slab.

  • Page 12: Pex Tubing Supports

    PEX Tubing Supports HeatLink PEX-a tubing can be supported using the same methods as metallic pipe. HeatLink recommends using copper tube size (CTS) hangers and supports designed for use with plastic pipe, e.g., plastic, coated, rubber, or foam lined, etc. Supports shall not compress, cut or abrade the tubing.
  • Page 13 To minimize stress on fittings, manifolds, and multiport tees, PEX should be supported as shown in the diagrams below. ® Heat Link...

  • Page 14: Expansion & Contraction

    Expansion & Contraction PEX has a high rate of thermal expansion. The design and installation of every piping system shall include means to accommodate its expansion and contraction caused by temperature changes, movement of the soil, building shrinkage or structural settlement. For systems using PEX 1"...

  • Page 15: Corner Offset

    Corner Offset Example 1: A 50ft straight run of 1¼" PEX is anchored at one end, and an elbow is installed at the other end. It is a DHW supply pipe with an operating temperature of 150°F, but was originally installed at 70°F, giving us a difference of 80°F, which equals 4.4" of expansion. In this case a corner offset is the best solution.

  • Page 16: Expansion U Offset

    Expansion U Offset Example 2: There is a 100ft straight run of 2" PEX tubing on a tray in a ceiling space for DHW. Again we need to allow for 100°F of temperature difference. In this case a U offset will work best.

  • Page 17: Pressing Instructions

    Pressing Instructions 1. Inspect all components for debris, obstructions, and/or damage prior to installation. 2. Cut the PEX tubing to length, ensuring a square cut - an irregular cut may ® Pure Link Link Plus result in a failed connection. For larger diameter PEX an ABS cutter is recommended.

  • Page 18: Press Tool Reference Guide

    Press Tool Reference Guide HeatLink has a variety of press tools designed for different situations, and requiring slightly different operation. Refer to the chart below, and to individual tool instructions on the following pages. Tool Part Press Calibration Description Number Description Check 1⁄2"...

  • Page 19: 1⁄2" & 3⁄4" Standard Press Tool Instructions

    1⁄2" & 3⁄4" Standard Press Tool Instructions Single Stage Press; 11305 & 11322. The stainless steel press sleeve must Regularly check tool jaws and sleeve be completely pressed only one time. If for any abnormalities that could be an pressed more than once it is necessary to indication of a damaged tool.

  • Page 20: 1⁄2" & 3⁄4" Standard Press Tool Calibration

    1⁄2" & 3⁄4" Standard Press Tool Calibration All HeatLink Press Tools are precalibrated by the manufacturer, and do not normally require an initial calibration. However, all press tools wear with use, and it is recommended that press tools be recalibrated as necessary. A calibration demonstration video is available for metal handle tools or for...

  • Page 21: 1" Standard Press Tool Instructions

    1" Standard Press Tool Instructions Single Stage Press; 11328. The stainless steel press sleeve must Regularly check tool jaws and sleeve be completely pressed only one time. If for any abnormalities that could be an pressed more than once it is necessary to indication of a damaged tool.

  • Page 22: 11⁄4" & 11⁄2" Standard Press Tool Instructions

    11⁄4" & 11⁄2" Standard Press Tool Instructions 2 Position Press; 11335 & 11341. The stainless steel press sleeve must Regularly check tool jaws and sleeve be completely pressed only one time. If for any abnormalities that could be an pressed more than once it is necessary to indication of a damaged tool.

  • Page 23: 1", 11⁄4", & 11⁄2" Standard Press Tool Calibration

    Example Presses 11⁄4" 11⁄2" 1", 11⁄4", & 11⁄2" Standard Press Tool Calibration All HeatLink Press Tools are precalibrated by the manufacturer, and do not normally require an initial calibration. However, all press tools wear with use, and it is recommended that every press tool be recalibrated as necessary.

  • Page 24: Using The Go/No-Go Gauge For Standard Press Tools

    1" 3/4" 1/2" Using the Go/No-Go Gauge for Standard Press Tools The Go/No-Go Gauge (#11328.1) should be used on a regular basis to help determine if presses made with any of the standard press tools are within HeatLink specifications. Use GO/NO-GO gauge here ®...

  • Page 25: 1⁄2" & 3⁄4" Confined Space Press Tool Instructions

    1⁄2" & 3⁄4" Confined Space Press Tool Instructions Single Stage Press; 11433 & 11434. The stainless steel press sleeve must Regularly check tool jaws and sleeve be completely pressed only one time. If for any abnormalities that could be an pressed more than once it is necessary to indication of a damaged tool.

  • Page 26: Confined Space Press Tool Calibration

    Example Presses Pinched sleeve; tool may be out 1⁄2" 3⁄4" of calibration or damaged. Confined Space Press Tool Calibration All HeatLink Press Tools are precalibrated by the manufacturer, and do not normally require an initial calibration. However, all press tools wear with use, increasing the press diameter. Use the Go Gauge (#11433.1) to determine if presses are within HeatLink specification.

  • Page 27: 3-In-1 Confined Space Press Tool Instructions

    3-in-1 Confined Space Press Tool Instructions Multi Stage Press; 11435. The stainless steel press sleeve must Regularly check tool jaws and sleeve be completely pressed only one time. If for any abnormalities that could be an pressed more than once it is necessary to indication of a damaged tool.
  • Page 28 Start 3. Move the cam lever to the Start and squeeze the handles together. 4. Relax your grip on the handles to allow the Lever to be moved to the next position - Large Diameter PEX may take 2-4 press stages to complete Finish 5.

  • Page 29: Replacement Collars For 11435 3-In-1 Press Tool

    8. Because this is a multi stage tool, every press must be inspected using the Go Gauge (#11433.1). The Gauge should freely rotate around the press sleeve at least 90°, catching only on the high spot where the jaws met during pressing. If a press does not pass, the sleeve and the fitting must be removed and replaced with new.

  • Page 30: Slim-Line Power Press Tool Instructions

    Slim-line Power Press Tool Instructions Auto Press; 11500. For complete power tool instructions, refer to the instruction booklet (L611500) that comes with the tool. Never press with empty jaws as this will damage the jaws. Regularly check tool jaws and sleeve for any abnormalities that could be an indication of a damaged tool.
  • Page 31 Example Presses 1⁄2" 3⁄4" Pinched sleeve; tool jaws must be replaced. 1" 11⁄4" 11⁄2" 11500 Series Jaws HeatLink 11500 Series Jaws are compatible with the following third-party tools: Nibco PC-20M Mini Rothenberger Compact Nibco PC-10M Mini #11505 - 1⁄2" #11522 - 3⁄4" #11528 - 1"...

  • Page 32: Power Press Tool With Pistol Grip Instructions

    Power Press Tool with Pistol Grip Instructions For complete power tool instructions, refer to the instruction booklet (L611600) that comes with the tool. 1⁄2" to 1 1⁄2" Press Instructions; Auto Press Never press with empty jaws as this will damage the jaws. Regularly check tool jaws and sleeve for any abnormalities that could be an indication of a damaged tool.
  • Page 33 2" Press Instructions; 2 Position Auto Press Never press with empty jaws as this will damage the jaws. Regularly check tool jaws and sleeve for any abnormalities that could be an indication of a damaged tool. If the Stainless Steel Sleeve is damaged or pressed incorrectly, both the fitting and the sleeve must be replaced.
  • Page 34 4. Squeeze the trigger until the second press is complete. 5. Open the jaws and remove the tool from the sleeve. 6. Inspect the connection to ensure the tubing is still properly seated (only PEX is visible in sleeve sight hole), and the press has been properly formed onto the sleeve (see diagram for guideline).
  • Page 35 11600 Series Jaws HeatLink 11600 Series Jaws are compatible with the following third-party tools: Nibco PC-280 Victaulic Vic-Press™ Tool - Style PFT510 Nibco PC-100 Ridgid 320-E Ridgid RP330-B Ridgid CT-400 Ridgid RP330-C Ridgid RP340 Milwaukee 2673-20L Move the red-ring forward by pressing the small button REMS 571011 on top.

  • Page 36: Common Installation Issues

    Common Installation Issues Issue Resolution Stainless Steel Press Sleeves Tubing not seated all the way Cut out fitting, and replace with new sleeves and fitting. onto fitting Does not pass Go/No-Go Cut out fitting, and replace with new sleeves and fitting. Tubing not cut straight Cut out fitting, and replace with new sleeves and fitting.

  • Page 37: Pex Tubing Pressure Drop Graph

    PEX Tubing Pressure Drop Graph 0.05 0.01 0.01 0.05 Water Flow Rate in US gpm Chart settings at 120°F ® Heat Link...

  • Page 38: Piping Methods

    Piping Methods Modified Home Run Piping Method (Recommended) 1. Remote headers require less than half of the connections of the branch method. 2. Less PEX tubing compared to home run method. ® Heat Link...
  • Page 39 Home Run Piping Method Branch and Tee Piping Method ® Heat Link...

  • Page 40: Demand Load Of Fixtures

    Demand Load of Fixtures Demand load of fixtures Fixture Units Type of Supply Fixture Occupancy Control Cold Total Public Flush valve 10.00 10.00 Public Flush tank 5.00 5.00 Urinal Public 1" flush valve 10.00 10.00 Urinal Public 3⁄4" flush valve 5.00 5.00 Urinal...

  • Page 41: Friction Losses

    Friction Losses Type of Fitting Equivalent Length of PEX 1⁄2" 3⁄4" 1" Coupling Elbow 90° 13.5 15.5 17.4 Tee-Branch 15.3 17.0 17.0 Tee - Run BRASS 1⁄2" 3⁄4" 1" 11⁄4" 11⁄2" 2" Coupling Elbow 90° 10.0 Tee - Branch 10.4 11.0 Tee - Run PEX Tubing Water Volume...

  • Page 42: Recirculation

    Recirculation PureLink® Plus PEX-a tubing is approved for continuous DHW recirculation. HeatLink recommends recirculation systems that utilize the minimum duty cycle to meet the demand requirements of the system. The use of PEX tubing in a potable hot-water plumbing system with an operating temperature above 140°F (60°C) or system pressure above 80 psig (550 kPaG) or highly aggressive water...

  • Page 43: Press Tool Calibration Tracking Sheet

    Press Tool Calibration Tracking Sheet Date Tool Part # Tool Description Tool # Calibrated By Calibrated ® Heat Link...
