CAB INSTALLATION INSTRUCTIONS
(1700, 2100, 2400, 2410, 7300, 7500, 7410, 7510, and 7610)
HARD SIDED CAB ENCLOSURE (p/n 1KB17AS1)
SOFT SIDED CAB ENCLOSURE (p/n 1KB17SS1)
The contents of this envelope are the property of the owner.
Be sure to leave with the owner when installation is complete.
This Curtis Cab is designed and
manufactured for use only as reasonable
weather protection. This cab is not appli-
cable, Nor should the cab be considered as protection against
roll over, collision or other accidents that may result. This cab is
NOT a R.O.P.S. cab. Extreme care should be taken when operat-
ing and by qualified, experienced operators only
CABS/BLADES/ SPREADERS/ACCESSORIES
KUBOTA B SERIES PHASE II
(also 2710, 2910, and 7800)

Exposure to Carbon Monoxide can Cause
illness, serious injury or death. Never
operate vehicle if suspicious of Carbon
Monoxide. Inspect exhaust system for leaks monthly. Leaks can
result from loose connections, corrosion, cracks or other damage
to the exhaust manifold. If leaks are found, repair or replace
.
exhaust system. Do not use vehicle until repair or replacement is
complete.
Soft Sided cab shown with the follow-
ing optional accessories: work lights,
strobe light, hard rear panel, and a 65
degree rear wiper motor.
ADDED
WEIGHT
Curtis Cabs, blades and general accessories
add additional weight to the base vehicle. All
Curtis accessory weights are listed in product
brochures. Deduct the accessories total weight
from the vehicles rated capacity and never
exceed the vehicles rated capacity including
driver and passenger.
p/n: IM-1KB17AS1
Rev. D, p. 1 of 10
