DISK
INSTALLATION EN
Handle with care
The material, the painted steel and the
Pergamon cladding are vulnerable.

Advertisement

loading
Need help?

Need help?

Do you have a question about the DISK and is the answer not in the manual?

Questions and answers

Related Manuals for Leenders DISK

Summary of Contents for Leenders DISK

  • Page 1 DISK INSTALLATION EN Handle with care The material, the painted steel and the Pergamon cladding are vulnerable.
  • Page 2 Open-ended spanner 17 mm • Allen key 2.5 mm (door), 3, 4 & 6 mm (swivelling base) Installation sequence Remove stone cladding > Position the Disk > Refit stone cladding > Connect the Disk. Note: • Never move the Disk with the stone cladding fitted.
  • Page 3 DISK LEENDERS Lift and remove the rear stone. Loosen the upper bolts (2 x) slightly first. Lift and remove the side stones. Loosen the top bolt slightly first. The side stones are marked Right and Left. Slide the top base stone out. Leave the Lift and slide the bottom base stone out.
  • Page 4 DISK LEENDERS Remove from the pallet Remove the poker and special tools from the base. Unscrew the Disk from the pallet (2 x screws). Use protective padding when moving the stove with a hand truck. 201848.001.I.EN...
  • Page 5 DISK LEENDERS Position the Disk Mark the hole centre on the floor. Lines should be no more than 20 cm long. The minimum distance between the hole centre and wall is 33.5 cm. Use the special tools to determine the exact position.
  • Page 6 Swivelling base 360° Swivelling base 2 x 60° For 360°; remove the swivel limiter and Remove the transport restraint. The Disk incorporate it in an item of jewellery. can now swivel through 2 x 60°. Level the swivelling base (if required) Loosen the 4 mm socket head screws slightly (2 x).
  • Page 7 DISK LEENDERS Fresh air feed (option) Swivelling base: Mount the stainless steel stub to the air box. Mount the stainless steel stub to the cover plate. Connect the hose. Secure it to the stainless steel stub if required. Non-swivelling base: Mount the stainless steel stub to the air box.
  • Page 8 DISK LEENDERS Fit both side stones and tighten the top bolt Fit the rear stone and tighten the top two in each case. bolts. Place protective cardboard on the top faces. Fit the air box closing stone. Lift the top stone into position. Lugs determine the exact position.

  • Page 9: General Instructions And Regulations

    Installation • To secure the warranty, the Disk must be installed by a properly qualified person employed by a dealer recognized by Harrie Leenders Haardkachels. See leenders.nl for a current list of addresses of recognized dealers or contact the manufacturer.
