- Page 1 LOBBE COMPACT INSTALLATION EN...
- Page 2 Socket spanner 17mm • hammer or frozen pear The Lobbe Compact can only be mounted to a solid and robust wall. The rear wall must not be combustible. The Lobbe Compact is not suitable for a rear flue. Transport Move the Lobbe Compact with a hand truck supported against the back.
- Page 3 Fresh air supply (optional) Centre of fresh air opening in rear wall 490mm, diameter minimum Ø110mm. Connect the flexible pipe to the fresh air supply in the back of the Lobbe Compact. Adjust the length of the flexible pipe if necessary.
- Page 4 LOBBE COMPACT LEENDERS Mounting the Lobbe Compact Lift the Lobbe Compact with no fewer than two people. Insert locking wedges (2x). Secure the locking wedges (2x) with a tap only after levelling. Adjusting for level (if required) Tighten the 2x M10 adjustment bolts at the bottom of the wall bracket to level.
- Page 5 LOBBE COMPACT LEENDERS Knob air valve 2x M4 Allen keys at the rear of the air valve. Interior Position the air pipes 2 sets. Check that the air pipes are properly connected at the bottom. Position the heat shield. Check that the heat shield is properly seated at the bottom.
- Page 6 Lobbe Compact. • Check, if the flue allows for this, the operation of the flue and the air supply to the Lobbe Compact with a fire. Follow the instructions in the manual for this. 201847.001.I.EN...
- Page 7 General instructions and regulations Installation To qualify for the guarantee, the Lobbe Compact must be installed by a qualified fitter employed by a Leenders approved dealer. See leenders.nl for a current list of addresses of approved dealers or con- tact the factory.
