C O
Drawell International Technology Limited
Chongqing Drawell Instrument Co., Ltd.
Shanghai Drawell Scientific Instrument Co.,Ltd.
Chongqing Center : Suite 2705,Building No.12,Shiyou Road No.1, Yuzhong District,
Chongqing, China.
Shanghai Office : Suite 1117,Lane561 XiuChuan Rd.,PuDong New Area,Shanghai,
China
Homepage : www.drawell.com.cn
Tel : 0086-023-63268643
Email : sales05@drawell.com.cn
Drawell International Technology Limited
Web : www.drawell.com.cn
C e l l I n c u b a t o r
2
（Water Jacket）
U s e r M a n u a l
Tel: +86-023-63268643
Email : sales05@drawell.com.cn
Advertisement
Related Manuals for Drawell Water Jacket
Summary of Contents for Drawell Water Jacket
- Page 1 C e l l I n c u b a t o r （Water Jacket） U s e r M a n u a l Drawell International Technology Limited Chongqing Drawell Instrument Co., Ltd. Shanghai Drawell Scientific Instrument Co.,Ltd. Chongqing Center : Suite 2705,Building No.12,Shiyou Road No.1, Yuzhong District, Chongqing, China.
- Page 2 Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn I. Application range The CO incubator is used for incubation of biology cells, tissues, bacteria in modern medicine, pharmacy, biochemist try, agricultural science research and industry. II. Features 1.
-
Page 3: Installation
Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn Power consumption(W) Chamber size 41×40.3×51 50.5×45.3×70 （cm ） Outer size 57×65.5×88.5 68.5×69.5×107.5 （cm ） N.W./G.W. (kg) 60/90 80/115 IV. Installation. 1. The equipment should be placed in a dry, even environment without toxic gas. Direct sunshine should be avoided. - Page 4 Drawell International Technology Limited 高 水 位 缺 水 超 温 气 泵 1 气 泵 2 照 明 门 加 热 灭 菌 Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn 2.Panel has a set of buttons on the right，functions as follows: ℃...
- Page 5 Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn character scope instructions factory setting over temperature alarm 1.0℃ 0～10.0℃ Measurement error correcting random -10.0～10.0℃ Temperature difference of the oven and random -10.0～10.0℃ door The difference temperature of water random 0～10.0℃...
- Page 6 (may be water shortage alarm at that time ) until the high water level indicator light green to stop water, close the inlet-outlet valves. 2.In order to prevent the water jacket in scale, please use pure or distilled water when filled. 3. The configuration of the PH liquid and washing liquid According to the following mixing PH liquid and washing liquid, and inject in PH and washing bottles respectively.
- Page 7 Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn 6. At constant temperature, open the door and put the culture in. 7. Press “pump1”or “pump2”button to open the pump1 (or2), adjust air flow valve slowly (counterclockwise), the ratio of CO2 concentration usually 5%, air flow can be adjusted to 760 ml/min.
- Page 8 Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn Ⅸ. Malfunction handling. Malfunction Cause Handling Sensor error. Refer to malfunction 2 1.Alarm when turning on. Not filled with water Continue inject water to WH light Chamber sensor error or Check the wire or change the sensor.
- Page 9 Drawell International Technology Limited Web : www.drawell.com.cn Tel: +86-023-63268643 Email : sales05@drawell.com.cn Packing list Item Description Category Quantity Notes Main Incubator equipment Humidifying plate Part Shelves Part 160L:3 Silicon soft tube for CO Part Fuse Spare part This manual Document...
- Page 10 Tel: +86-023-63268643 Email : sales05@drawell.com.cn Drawell International Technology Limited Chongqing Drawell Instrument CO,.Ltd Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District, Chongqing,China Tel: 0086-023-63268643 Shanghai Drawell Scientific Instrument Co.,Ltd Add : Suite 1117,Lane561 XiuChuan Rd.,PuDong New Area,Shanghai,China Web : www.drawell.com.cn Email : sales05@drawell.com.cn...
