- Page 1 OPERATION AND INSTALLATION PROFI SELECT apartment module for DHW and heating with integral instantaneous water heater » WSP-2-DUO » WSG-2-DUO...
-
Page 2: Table Of Contents
Failure to observe this information may result in serious 16.1 Dimensions and connections ������������������ 15 injury or death. 16.2 Wiring diagrams ���������������������������� 18 CaUTiON Failure to observe this information may result in non-se- rious or minor injury. 16.3 Data tables �������������������������������� 22 GUARANTEE ENVIRONMENT AND RECYCLING WSP-2-DUO, WSG-2-DUO... -
Page 3: Other Symbols In This Documentation
The heat exchanger requires regular cleaning, depending on water quality. Have the appliance cleaned by a qualified con- tractor after no more than 2 years. The qualified contractor will then determine the intervals at which it should be cleaned thereafter. WSP-2-DUO, WSG-2-DUO... -
Page 4: Troubleshooting
The order code consists of the base station designation, fol- lowed by an "E" and the internal code for the installation op- tions. Example: Order code "WSP2DUOE-7.1" WSP2DUO E 7.1 Base station Installation options E7-WDR1 WSP-2-DUO, WSG-2-DUO... -
Page 5: Base Station
The base units are equipped with appropriate fittings (110 mm, DN 25 ¾” 1.5 m³/h) for the heat meters. DN 32 Sensor retainer: DN 40 DN 50 - Directly immersed - Sensor length: 28 mm - Diameter: Max. 5.4 mm; at the sealing point min. 5.2 mm WSP-2-DUO, WSG-2-DUO... -
Page 6: Installation Options
Do not draw off any DHW while testing the heating water flow rate. Make sure that all thermostatic valves and un- derfloor heating control valves are fully open. f after balancing is complete, check the set flow tempera- ture again. WSP-2-DUO, WSG-2-DUO... - Page 7 Do not draw off any DHW while testing the heating water flow rate. Make sure that all thermostatic valves and un- derfloor heating control valves are fully open. f after balancing is complete, check the set flow tempera- ture again. WSP-2-DUO, WSG-2-DUO...
-
Page 8: Accessories
Casing for unfinished walls, short | Z3-GUK-DUO [3.12] Casing for unfinished walls, long | Z3-GUL-DUO [5.2] Mounting rail | Z5-MS-7 [5.4] Mounting rail | Z5-MS-9 Fully wired mounting rail with shut-off valve for connecting the apartment module f Observe the enclosed instructions. WSP-2-DUO, WSG-2-DUO... - Page 9 The actuator fitted on the valve for room heating and the tem- perature controller can be used to set a seven-day program for heating use, for example. Designation Part number Actuator 237740 Room temperature controller WS-rT 2.0 233757 rTa-S UP 223344 rTa-S2 231061 WSP-2-DUO, WSG-2-DUO...
-
Page 10: Preparation
9.3 Transport f if possible, transport the appliance in its original packaging. 10 | WSP-2-DUO, WSG-2-DUO... -
Page 11: Installation
Guide the recesses in the casing for finished walls – availa- ble as an installation option or accessory – into the hooks at the side of the mounting plate for the appliance from above. The installation dimension "373 mm" refers to the clearance from the floor covering. WSP-2-DUO, WSG-2-DUO | 11... -
Page 12: Water Connection
Observe the operating and installation instructions for the integral instantaneous water heater. f route the electrical connections into the appliance. f incorporate the appliance in the equipotential bonding. Use the connection at the bottom left-hand section of the mounting plate (min. 6 mm² CU). 12 | WSP-2-DUO, WSG-2-DUO... -
Page 13: Completing The Installation
Make sure that all thermostatic valves and un- derfloor heating control valves are fully open. f after balancing is complete, check the set flow tempera- ture again. Checking the appliance f Check the appliance function. WSP-2-DUO, WSG-2-DUO | 13... -
Page 14: Settings
Check the condition of the appliance and clean off any external dirt. f if necessary, vent the heating system. f Check the appliance function. f Check the appliance for leaks. f refit the casing door. f log the inspection/maintenance work performed. 14 | WSP-2-DUO, WSG-2-DUO... -
Page 15: Specification
Specification 16. Specification WSP-2-DUO for DHW and heating circuit with mixer [1.1] Heating circuit with mixer, thermostatically controlled | 16.1 Dimensions and connections E1-HKT Note Depending on the range of functions, a mounting rail or heating circuit distributor will be required to con- nect the base station. - Page 16 Specification WSP-2-DUO for DHW with heating circuit with mixer and WSP-2-DUO for DHW with heating circuit with mixer and heating circuit distributor heating circuit without mixer [1.1] Heating circuit with mixer, thermostatically [1.1] Heating circuit with mixer, thermostatically controlled | controlled |...
- Page 17 Specification [3.9] Casing for finished walls, short | Z3-GAK-DUO [3.11] Casing for finished walls, long | Z3-GAL-DUO [3.10] Casing for unfinished walls, short | Z3-GUK-DUO [3.12] Casing for unfinished walls, long | Z3-GUL-DUO WSP-2-DUO, WSG-2-DUO | 17...
-
Page 18: Wiring Diagrams
STA 9 STA 10 STA 11 STA 12 STA 13 STA 14 STA 15 STA 16 STA 17 STA 18 STA 19 STA 20 STA 21 Detail A Detail B Detail D Detail A Detail D Detail C 18 | WSP-2-DUO, WSG-2-DUO... - Page 19 8 10 N N N SEHCM VBus Anbindung IP20 zur Weitergabe 100-240 V des Außenfühlers 50-60 Hz R4 R4 VBus 8 10 9 N N N max. 20 Teilnehmer . . . VBus ® AF FAP13 WSP-2-DUO, WSG-2-DUO | 19...
- Page 20 STA 9 STA 10 STA 11 STA 12 STA 13 STA 14 STA 15 STA 16 STA 17 STA 18 STA 19 STA 20 STA 21 Detail A Detail B Detail D Detail E Detail A Detail D Detail C 20 | WSP-2-DUO, WSG-2-DUO...
- Page 21 Specification Contact thermostat (E9-ATR) 230 V / 16A N PE + – E9 - Anlegetemperaturregler WSP-2-DUO, WSG-2-DUO | 21...
-
Page 22: Data Tables
Specification 16.3 Data tables WSP-2-DUO | WSG-2-DUO WSP-2-DUO WSG-2-DUO 238133 238134 Hydraulic data Output on the primary side Max. flow rate on primary side, incl. differential pressure controller 1300 1300 and heat meter at dp = 600 hPa Output on the secondary side (at 10 K) Draw-off rate at secondary 10/48 °C... - Page 23 Specification Application limits WSP-2-DUO | WSG-2-DUO Flow temperature °C DHW temperature °C Cold water temp. °C DHW l/min l/min 7 return temperature °C 21.35 22.78 23.42 21.66 23.03 23.65 21.97 23.29 23.89 Spread 18.65 17.22 16.58 18.34 19.97 16.35 18.03 16.71 16.11...
- Page 24 WSP- | WSG-DUO WSP- | WSG-DUO Casing height, unfinished walls 1400 Casing width, unfinished walls Casing depth, unfinished walls 180...205 180...205 Frame width Frame height 1440 Weight 12.5 20.5 Colour White, ral 9010 White (similar to ral 9010) 24 | WSP-2-DUO, WSG-2-DUO...
-
Page 25: Guarantee
This will not affect warranties issued by any importers. Environment and recycling We would ask you to help protect the environment. After use, dispose of the various materials in accordance with national regulations. WSP-2-DUO, WSG-2-DUO | 25... - Page 26 NOTES 26 | WSP-2-DUO, WSG-2-DUO...
- Page 27 NOTES WSP-2-DUO, WSG-2-DUO | 27...
- Page 28 STIEBEL ELTRON GmbH & Co. KG tecalor GmbH Dr.-Stiebel-Str. 33 | 37603 Holzminden Lüchtringer Weg 3 | 37603 Holzminden Tel. 05531 702-0 | Fax 05531 702-480 Tel. 05531 99068-95700 | Fax 05531 99068-95712 info@stiebel-eltron.de info@tecalor.de www.stiebel-eltron.de www.tecalor.de 4 < A M H C M O = d a j c j b >...
