T o c h a n g e t h e t a r g e t d e p t h
s h o w n , u s e t h e k e y p a d .
H A G i s n o t f a c t o r e d i n t o t h e t a r g e t d e p t h s e t t i n g . E l e v a t e t h e
l o c a t o r a n d a d d t h a t h e i g h t t o t h e t a r g e t d e p t h i f d r i l l i n g
s h a l l o w e r t h a n 1 . 5 f t ( 0 . 5 m ) o r i f e l e v a t i n g t h e l o c a t o r t o
d i s t a n c e i t f r o m r e b a r .
S T E P 4 O F 6
P l a c e t h e l o c a t o r o n t h e d r i l l p a t h w i t h i t s b a t t e r y c o m p a r t m e n t f a c i n g t h e
d r i l l h e a d . T a r g e t S t e e r i n g g u i d e s t h e t r a n s m i t t e r t o b e i n l i n e w i t h t h e
l o c a t o r ' s h a n d l e w h e n i t r e a c h e s t h e t a r g e t b e n e a t h t h e l o c a t o r . F o r
a c c u r a t e d e p t h i n f o r m a t i o n , u s e t h e h o r i z o n t a l d i s t a n c e r e a d i n g o n t h e
T a r g e t S t e e r i n g d i s p l a y t o e n s u r e t h e l o c a t o r i s n o m o r e t h a n 3 5 f t ( 1 0 . 7 m ) i n
f r o n t o f t h e t r a n s m i t t e r .
1 . H o r i z o n t a l d i s t a n c e f r o m t r a n s m i t t e r t o l o c a t o r
2 . C u r r e n t t r a n s m i t t e r d e p t h b e l o w t h e p l a n e o f t h e l o c a t o r
A t t h i s p o i n t , t h e d r i l l r i g o p e r a t o r u s e s t h e r e m o t e d i s p l a y t o
d r i l l t o t h e t a r g e t .
D I G I T A L C O N T R O L , I N C
F A L C O N F S U B - K R E B A R
D C I D i g i G u i d e
U S E R M A N U A L
0 7 . 0 8 . 2 0 2 2
