- Page 1 OWNERS MANUAL M I X O L O G I Q C O C K T A I L M A C H I N E @GrandCruWineFridges NEED HELP? CALL 1300 935 683 www.grandcruwinefridges.com.au GRCU4718-Mixo Two User Guide.indd 1 GRCU4718-Mixo Two User Guide.indd 1 20/9/22 4:28 pm 20/9/22 4:28 pm...
- Page 2 GRCU4718-Mixo Two User Guide.indd 2 GRCU4718-Mixo Two User Guide.indd 2 20/9/22 4:28 pm 20/9/22 4:28 pm...
-
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ....................4 SHIPPING BOX CONTENTS ..................... 6 INSTALLATION ....................... 7 START MIXOTWO ......................8 SETTINGS - MENU DESCRIPTION ................... 9 LANGUAGE SELECTION ....................9 INTERNET CONNECTION ....................10 BOTTLE POSITIONING ....................12 CLEANING PROCESS .....................14 CALIBRATION PROCESS ....................16 FRIDGE TEMPERATURE ....................17 PREPARING A COCKTAIL ....................18... -
Page 4: Safety Precautions
Thank you for choosing MixoTwo Cocktail Machine, we want you to make the most of your new machine. Please read carefully this Owners Manual before using MixoTwo, in doing so you will avoid putting yourself at risk or damage the machine. - Page 5 Fluctuations in the power supply can Type Cocktail Machine cause damage, which causes the machine Model to switch off. Supplier cannot be held MixoTwo responsible for any consequential damage. Serial YYMM-SERIAL number Refr. R R 600a...
-
Page 6: Shipping Box Contents
SHIPPING BOX CONTENTS MixoTwo cocktail Mobile Caps with aerator Inside cleaning machine (x1) for bottles (x10) container (x1) Top Middle cleaning Top Left cleaning Top Right cleaning container (x1) container (x1) container (x1) Calibration USB Wireless Power supply Power glass (x1) -
Page 7: Installation
− Fridge connection: Plug a Power LOCATION Cable on the outlet − Electronic System connection: • MixoTwo must be installed on a flat Plug the Power Supply with a horizontal smooth surface to work properly. Power Cable on the outlet Legs are used for adjustment and levelling. -
Page 8: Start Mixotwo
START MIXOTWO Once the Installation is complete, to start MixoTwo switch (D) to position 1. The screen after few seconds will show the following message: Click on and the Main screen will appear: Preloaded Cocktails Families List of cocktails in progress Alerts (Empty Bottles, New software update …... -
Page 9: Settings - Menu Description
SETTINGS - MENU DESCRIPTION Click on the setting menu to open the screen below: Launch cleaning Menu Calibrate bottles Connect to Internet Change language Use for maintenance Restart machine Back to main screen LANGUAGE SELECTION In the setting menu click on “Language” Then click on the selected language and wait for few seconds for screen to restart. -
Page 10: Internet Connection
Active Not active Connection Connection RJ45 CONNECTION When MixoTwo is plugged with a RJ45 wire on a standard configuration the connection must be automatic If after 1 minute, the connected status is not active Type the Wifi password then click •... - Page 11 Note: Keyboard can be scrolled from top to bottom to get lowercase letters and special characters. • If password is correct the internet connection status will become active • If internet connection is after 2 minutes, check your password. ADVANCED CONFIGURATION For specific configuration when DHCP is not active (usually in large companies).
-
Page 12: Bottle Positioning
BOTTLE POSITIONING Important: Making good cocktails depends on the quality of the ingredients and good use of MixoTwo operation depends on adapting ingredients viscosity to its pumping system for syrups, juices or thick alcohols. An ingredient with a thick viscosity will lead to non-detection of empty bottle or pumps and pipes obstruction due to inappropriate product viscosity. - Page 13 To remove a bottle, pull the bottle gently upwards. BOTTLES INSTALLATION ON INSIDE SECTION (10 BOTTLES) The 10 bottles for the Inside section are placed by putting tubes inside each allocated bottle, then tap bottles using black caps as shown. Important: Make sure that the rigid tube is correctly fixed to its connection to avoid an air intake which...
-
Page 14: Cleaning Process
CLEANING PROCESS Important: Regular cleaning is essential to make MixoTwo operates at its best, this operation must be done with hot water with an appropriate descaling agent. INSIDE SECTION CLEANING PROCESS THE CLEANING PROCESS Follow the steps on the screen: The cleaning process consists in two separate operations. - Page 15 • Put the Middle container under distribution head. • Follow cleaning steps from screen Click on • MixoTwo is pumping the hot water from the Cleaning containers and put it in the Middle container. • Once the containers and the tubes are empty the cleaning process is completed.
-
Page 16: Calibration Process
CALIBRATION PROCESS Important: Making good cocktails depends on a good calibration of MixoTwo as well as good quality ingredients. Good operation of MixoTwo depends on ingredient viscosity adapted to its pumping system for syrups, juices and thick alcohols. A very thick ingredient will lead to pump and pipes obstructions. -
Page 17: Fridge Temperature
• MixoTwo may ask to clean it if dirty by showing you this image. In this case clean sensor using a dry tissue to remove traces of liquid. -
Page 18: Preparing A Cocktail
• Insert the glass or shaker in the MixoTwo • Change the number of cocktails to prepare. Click on the icon The process is as follows: •... - Page 19 Important: Grey cocktail. Sometimes in MixoTwo, there are grey cocktails shown, and if you click on the cocktail, the cocktail cannot be made, as shown in the two images above.
-
Page 20: End Of Bottles
ALERT MESSAGES A message while the cocktail is processing Alert message will disappear when MixoTwo manages to get the liquid • If the empty detection concerns the fridge area, check that the rigid dip tube is properly engaged in its connector VIEWING THE QUEUE/ so that there is no air intake. -
Page 21: Software Version And Update
Access to the Backoffice at the URL: https://my.mixologiq.com Ask for your access codes from your Distributor. MixoTwo must be connected on Internet to synchronize the recipes with the Backoffice. For more information about the Backoffice refer to its own documentation. -
Page 22: Maintenance
Full Pipe: Full circle bottle you should contact your Distributor means full pipe. for maintenance. In the meantime and continue using MixoTwo without the Empty Pipe: Incomplete bottle that has a problem, you can disable circle means empty pipe. the bottle in the maintenance menu. - Page 23 MANUAL CALIBRATION In this menu, we find all information concerning how to calibrate the bottle manually. • Start Pump: Find out more about the pump status − Pump Status: Gives information on the pump and the current consumed in percentage. −...
- Page 24 Important: If you change the speed config, you need to recalibrate the bottle. • Fill the box using the numeric keypad. • Pump “1, 6, 11, 16: 43” < speed Config < 100. • Others: 70 < speed Config < 100 •...
-
Page 25: Troubleshooting
TROUBLESHOOTING Before contacting your Distributor, please try and solve your problems using the table below: Problem Probable cause(s) Solution Recipe does not • Ice is missing in the glass. • Check if recipe requires fill the glass • Size of the glass is ice inside the glass. -
Page 26: Warranty, Service And Support
WARRANTY, SERVICE AND SUPPORT Thank you for purchasing a Mixologiq Cocktail Machine from Home Icon International Pty Ltd. Home Icon provides a 1-year warranty on the Mixologiq Cocktail Machine. WARRANTY REGISTRATION Register your MixoTwo now for warranty, and allow us to provide you with the best possible after sales service: 1. - Page 27 GRCU4718-Mixo Two User Guide.indd 27 GRCU4718-Mixo Two User Guide.indd 27 20/9/22 4:28 pm 20/9/22 4:28 pm...
- Page 28 EVERYONE IS THE BEST BARTENDER WITH MIXOLOGIQ @GrandCruWineFridges NEED HELP? CALL 1300 935 683 www.grandcruwinefridges.com.au GRCU4718-Mixo Two User Guide.indd 28 GRCU4718-Mixo Two User Guide.indd 28 20/9/22 4:28 pm 20/9/22 4:28 pm...
