Page 1 Bi-spectrum Network Camera User Manual Issue V 1.0 Data 2021-10-25...
Page 3: Precautions
Bi-spectrum network camera User Manual Precautions Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye-catching place. Failure to correctly use electrical products may cause fire and severe injuries.
Page 4 Bi-spectrum network camera Precautions User Manual ⚫ Strictly conform to local electrical safety standards and use power adapters which are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged. ⚫ Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
Page 5 Bi-spectrum network camera User Manual Precautions front window needs further cleaning, use a soft cloth dampened with isopropyl alcohol or detergent. Improper cleaning can cause damage to the device. ⚫ The lens window of the thermal imaging camera is designed to be applicable to an outdoor environment.
Page 6: Table Of Contents
Bi-spectrum network camera Contents User Manual Contents Precautions ........................I Contents ........................IV 1 Product Overview ....................1 1.1 About Product ......................... 1 1.2 Features .......................... 1 1.3 Device Dimension ......................2 1.4 Installation ........................4 1.5 Cable Connection ......................6 2 Quick Configuration ....................
Page 7 Bi-spectrum network camera User Manual Contents 4.3 Image Adjust ........................ 43 4.4 Scene ..........................45 4.5 Exposure ........................46 4.6 WB ..........................48 4.7 DayNight ........................50 4.8 Noise Reduction ......................52 4.9 Enhance Image ......................54 5 Thermal Sensor Configuration................56 5.1 Accessing the Sensor Interface ..................
Page 8 Bi-spectrum network camera Contents User Manual 10.2 Stream ........................102 10.2.1 Base Stream ....................102 10.2.2 SVC Stream ....................103 10.2.3 ROI ....................... 104 10.2.4 Snapshot ....................... 105 10.3 Device ........................106 10.4 External Device ......................106 10.5 Privacy Masking ....................... 107 10.6 Network Service .......................
Page 9: Product Overview
Bi-spectrum network camera User Manual Product Overview Product Overview 1.1 About Product ⚫ The Bi-spectrum network camera is integrated with the thermal imaging and temperature measuring, visible fusion, core image intelligent analysis, etc. ⚫ Unique double registration mechanism, visible light and thermal imaging is reflecting the same scene.
Page 10: Device Dimension
Bi-spectrum network camera Product Overview User Manual ⚫ Providing software and hardware watchdogs and automatic fault recovery. ⚫ Linked heat dissipation structure of the metal enclosure. ⚫ DC 12 V /POE. 1.3 Device Dimension Figure 1-1 shows the dimensions of device. Issue V1.0（2021-10-25）...
Page 11 Bi-spectrum network camera User Manual Product Overview Figure 1-1 Dimensions (unit: mm) Issue V1.0（2021-10-25）...
Page 12: Installation
Bi-spectrum network camera Product Overview User Manual 1.4 Installation Step 1 Stick the installation location sticker on ceiling or wall, drill four holes based on the marks on the sticker. Drive the plastic anchors into holes. Step 2 Loosen screw 1 to free the body to easy to install the fixed screws of camera. This step before mount is highly suggested to make it convenient to use electric screwdriver, as shown in Figure 1-2.
Page 13 Bi-spectrum network camera User Manual Product Overview Figure 1-2 Adjust direction Screw 1 Step 3 Install the camera on the ceiling or wall and fixe the screws as shown in Figure 1-3. Figure 1-3 Fix camera Step 4 Connect the multi-connector cable and monitor, loosen the screw 2 to adjust the position so that the camera face the monitored area, as shown in Figure 1-4.
Page 14: Cable Connection
Bi-spectrum network camera Product Overview User Manual Figure 1-4 Adjust image 1.5 Cable Connection Figure 1-5 the multi-connector combination cable of the thermal imaging integrated network camera. For details about the multi-connector combination cable, please refer to Table 1-1. Figure 1-5 Multi-connector combination cable Issue V1.0（2021-10-25）...
Page 15 Bi-spectrum network camera User Manual Product Overview Table 1-1 Multi-connector combination cable Core of Cable Functions Connect to the standard Ethernet cable. Support Network interface PoE power supply. ALARM1 Alarm in/ alarm out 1 Brown: alarm OUT COM 1 Blue: alarm OUT 1 White: alarm IN COM 1 Green: alarm IN 1 ALARM 2...
Page 16: Quick Configuration
Bi-spectrum network camera Quick Configuration User Manual Quick Configuration 2.1 Login and Logout You must use Internet Explorer 8 or a later version to access the web management system; otherwise, some functions may be unavailable. Login system Step 1 Open the Internet Explorer, enter the IP address of camera (default value is 192.168.0.121) in the address box, and press Enter.
Page 17: Homepage Layout
Bi-spectrum network camera User Manual Quick Configuration ⚫ The default name and password both are admin. Modify the password when you log in the system for first time to ensure system security. After modifying password, you need to wait at least three minutes then power off to make sure modifying successfully . Or login the Web again to check the new password.
Page 18 Bi-spectrum network camera Quick Configuration User Manual Element Description Personnel Set the query condition to query the personnel count, the count statistical can be shown in different types, such as line chart, histogram, list, the detail information please refer to chapter 2.5 Configuration You can choose a menu to set device parameters,...
Page 19: Changing The Password
Bi-spectrum network camera User Manual Quick Configuration 2.3 Changing the Password Description User can click to change the password for logging in to the system. Procedure Step 1 Click in the upper right corner of the main page. The Change Password dialog box is displayed, as shown in Figure 2-3. Figure 2-3 Change password dialog box ⚫...
Page 20: Browse Video
Bi-spectrum network camera Quick Configuration User Manual If the message "Change password success" is displayed, the password is successfully changed. If the password fails to be changed, the cause is displayed. (For example, the new password length couldn’t be less than eight.) ----End 2.4 Browse Video User can browse the real-time video in the web management system.
Page 21: Install Plugins
Bi-spectrum network camera User Manual Quick Configuration Figure 2-5. Figure 2-5 Configuring ActiveX control and plug-ins Step 3 Download and install the player control as prompted. ⚫ The login page is displayed when the control is loaded. 2.4.1 Install Plugins You will be prompted with a message “Click here to use short delay Plugin for Live Video”...
Page 22: Personnel Count
Bi-spectrum network camera Quick Configuration User Manual Figure 2-6 Download the plugin page Procedure Step 1 Click the message, download and install the plugin follow the prompts. Step 2 Reopen the browser after installation. Step 3 On live video page, you can operate these buttons as shown in live video. ⚫...
Page 23: Setting Local Network Parameters
Bi-spectrum network camera User Manual Quick Configuration Figure 2-7 Personnel count interface Click “Download” to download the query result. Choose the mode of showing result, such as line chart, histogram, list. Click “Query” to query the data of personnel count. User can download the result to local folder.
Page 24 Bi-spectrum network camera Quick Configuration User Manual Procedure Step 1 Choose Configuration > Device >Local Network. The Local Network page is displayed, as shown in Figure 2-8. Figure 2-8 Local Network Step 2 Set the parameters according to Table 2-2. Table 2-2 Local network parameters Parameter...
Page 25 Bi-spectrum network camera User Manual Quick Configuration Parameter Description Setting DHCP The device automatically [Setting method] obtains the IP address from the Click the option button. DHCP server. NOTE To query the current IP address of the device, you must query it on the platform based on the device name.
Page 26 Bi-spectrum network camera Quick Configuration User Manual Step 3 Click OK. ⚫ If the message "Apply success" is displayed, click OK. The system saves the settings. The message "Set network pram’s success, Please login system again" is displayed. Use the new IP address to log in to the web management system.
Page 27: Configuring Thermal
Bi-spectrum network camera User Manual Configuring Thermal Configuring Thermal 3.1 Temperature Parameters Temperature parameters include temperature unit, ambient type, ambient temperature, cavity temperature, correctional coefficient, area temperature display mode, area temperature type, measure mode, area alarm interval and so on. Operation Procedure Step 1 Choose Configuration >Thermal >Temperature Parameters.
Page 28 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-1 Temperature Parameters interface Step 2 Set the parameters according to Table 3-1. Table 3-1 Temperature parameters Parameter Description Setting Temperature Unit Celsius and Fahrenheit [Setting method] temperature units are available. Select a value from the drop-down list box.
Page 29 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Length units Meters and feet length units are [Setting method] available. Select a value from the drop-down list box. [Default value] Meters Cavity The cavity temperature of Temperature camera. Correction Correction coefficient is refer to [Setting method] Coefficient...
Page 30 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Font size There are there font size can be [Setting method] chosen, small/mid/big Enable or disable [Default value] Area Temperature There are three types of area [Setting method] Type temperature. Select a value from the drop-down list box.
Page 31 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Prevent Over Heat Open, if temperature of the [Setting method] testing area is too high, you can Select a value from the enable prevent over heat drop-down list box. function, the control cover will be lay down to keep the detector safe, there are two types, manual and auto.
Page 32 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-2 Advanced interface Table 3-2 Advance parameters Parameter Description Setting Dimming Mode There are auto and manual [Setting method] modes. It will show on Select a value from the temperature item. drop-down list box. [Default value] Auto Greater Prominent...
Page 33: Ambient Temperature
Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Raw Data Upload Interval of Uploading the raw [Setting method] Interval(F/S) data. Select a value from the drop-down list box. [Default value] This function is used for Mix Stream Mode [Default value] thermal and visible image to Close...
Page 34: Temperature Area
Bi-spectrum network camera Configuring Thermal User Manual 3.3 Temperature Area Operation Procedure Step 1 Choose Configuration >Thermal >Temperature Area. The Temperature Area page is displayed, as shown in Figure 3-4. Figure 3-4 Temperature area and alarm configuration Step 2 Set the parameters according to Table 3-4. Issue V1.0（2021-10-25）...
Page 35 Bi-spectrum network camera User Manual Configuring Thermal Table 3-4 Temperature area and alarm configuration Parameter Description Setting Channel Channel 1 is visible light [Setting method] channel. Select a value from the Channel 2 is thermal channel. drop-down list box. [Default value] Measure Mode Set at temperature parameter interface.
Page 36 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Maximum Alarm At section alarm type, the [Setting method] Value device would not alarm when Enter a value manually. the temperature is higher than [Default value] maximum alarm value. 60.00 Duration (1-10S) Choose temperature rise alarm, set the duration, the temperature...
Page 37 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Group ID The ID can be chosen into one [Setting method] of six groups, or no group. The Select a value from the group will be alarm following drop-down list box. as the next rules: A=The highest temperature of groups (the highest temperature...
Page 38 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-5 Temperature Area Setting Interface 3. Click Apply, the message “Apply success” is displayed, the temperature area is set successfully. NOTE ID 0 is the full screen, the area cannot be changed. : the lowest temperature of the full screen.
Page 39: Shield Area
Bi-spectrum network camera User Manual Configuring Thermal Step 4 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 3.4 Shield Area Shield area is meaning that the camera will do not detect the temperature of that area. The shield areas can be set up to four areas.
Page 40: Thermal Mapping
Bi-spectrum network camera Configuring Thermal User Manual ----End 3.5 Thermal Mapping Thermal mapping is used to map accurately the location of detecting area to the visual channel. The mapping has three points, user can choose the right locations to map, the three points should not be too close.
Page 41: Schedule Linkage
Bi-spectrum network camera User Manual Configuring Thermal Table 3-5 Parameter of thermal mapping Parameter Description Setting Horizontal shift(%) Adjust horizontal position of area [Setting method] which is on visual image. Input value Vertical shift(%) Adjust vertical position of area which is [Setting method] on visual image.
Page 42 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-8 Schedule Linkage Step 2 Tick the output channel. Enable alarm record, SMTP, FTP upload, audio alarm, and flashlight alarm. The audio alarm file will be set at Alarm > Sound Alarm Output interface, as shown in Figure 3-9.
Page 43 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-9 Sound alarm output User can set the audio file manually. Click to upload the audio file(the type should be WAV), as shown in Figure 3-10. Figure 3-10 Upload audio file Step 3 Set schedule linkage. Method 1：Click left mouse button to select any time point within 0:00-24:00 from Monday to Sunday as shown in Figure 3-8.
Page 44: Bad Point Check
Bi-spectrum network camera Configuring Thermal User Manual Method 2：Hold down the left mouse button, drag and release mouse to select the alarm time within 0:00-24:00 from Monday to Sunday. When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected.
Page 45 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-11 Bad Point Check Step 2 Click the white point at image, click Reset to recover the bad point, as shown in Figure 3- Issue V1.0（2021-10-25）...
Page 46: Led Control Param
Bi-spectrum network camera Configuring Thermal User Manual Figure 3-12 Recover bad point Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 3.8 LED Control Param Set the display mode and brightness of LED, as shown in Figure 3-13. Issue V1.0（2021-10-25）...
Page 47: Digital Tube
Bi-spectrum network camera User Manual Configuring Thermal Figure 3-13 LED control param Table 3-6 LED control param Parameter Description Setting Display Mode There are four modes can be chosen. [Setting method] Open: the LED is always lighting. Select from drop-down list.
Page 48 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-14 Digital tube Table 3-7 Digital tube Parameter Description Setting Enable Enable it, the digital tube will show [Default value] the temperature of detecting. Enable Relate Area ID It is relativity to the Area ID of [Setting method] Parameter Configure, choose one Select from drop-down...
Page 49: Visible Sensor Configuration
Bi-spectrum network camera User Manual Visible Sensor Configuration Visible Sensor Configuration 4.1 Accessing the Sensor Interface Procedure Step 1 On the web, move the cursor to the real-time video page and right-click on the page. A shortcut menu is displayed, as shown in Figure 4-1 Figure 4-1 Sensor setting interface Or at “Configuration >...
Page 50: Mode
Bi-spectrum network camera Visible Sensor Configuration User Manual Figure 4-2 Sensor setting Step 2 Choose Sensor Configure and the Sensor Setting dialog box appears. ⚫ All sensor configure can be modified at debug mode. Click in the lower left corner of Sensor Setting, and choose Debug Mode. ----End 4.2 Mode Step 1 Click...
Page 51: Image Adjust
Bi-spectrum network camera User Manual Visible Sensor Configuration Figure 4-3 Mode Step 2 Choose the switch mode from the drop-down list. Step 3 Time mode: Set the Start Time, set the End Time. Step 4 Click Save, the message "Save succeed" is displayed, the system saves the settings. ----End 4.3 Image Adjust Figure 4-4 shows the Image Adjust tab page.
Page 52 Bi-spectrum network camera Visible Sensor Configuration User Manual Figure 4-4 Image Table 4-1 describes the parameters on the Image Adjust tab page. Table 4-1 Parameters of Image Parameter Description Configuration Method Brightness It indicates the total brightness of an image. As [Setting method] the value increases, the image becomes Drag the slider.
Page 53: Scene
Bi-spectrum network camera User Manual Visible Sensor Configuration Saturation It indicates the color saturation of an image. As [Setting method] the value increases, the image becomes more Drag the slider. colorful. [Default value] Contrast It indicates the measurement of different [Setting method] brightness levels between the brightest white Drag the slider.
Page 54: Exposure
Bi-spectrum network camera Visible Sensor Configuration User Manual Table 4-2 Parameters of scene Parameter Description Configuration Method Scene Indoor or outdoor. [Setting method] Select a value from the drop-down list. [Default value] Indoor Mirror It is used to select the pixel location of [Setting method] an image.
Page 55 Bi-spectrum network camera User Manual Visible Sensor Configuration Figure 4-6 Exposure Table 4-3 describes the parameters on the Exposure setting tab page. Table 4-3 Parameters of exposure setting Parameter Description Configuration Method Exposure Mode The exposure modes include: [Setting method] Select a value from ⚫...
Page 56 Bi-spectrum network camera Visible Sensor Configuration User Manual Meter area Choose the area to meter, there are whole, [Setting method] center spot, and center area. Select a value from the drop-down list. [Default value] Whole Max Shutter It is valid in mode.
Page 57 Bi-spectrum network camera User Manual Visible Sensor Configuration Figure 4-7 Table 4-4 describes the parameters on the WB tab page. Issue V1.0（2021-10-25）...
Page 58: Daynight
Bi-spectrum network camera Visible Sensor Configuration User Manual Table 4-4 Parameters of WB Parameter Description Configuration Method Mode It is used to display the real color of a [Setting method] monitoring scenario when the color temperature Select a value changes. from the drop- down list.
Page 59 Bi-spectrum network camera User Manual Visible Sensor Configuration Table 4-5 describes the parameters on the Special Function tab page. Table 4-5 Parameters of day night Parameter Description Configuration Method DayNight It can be set to Auto, Day Mode, Night Mode [Setting method] Mode and Timing.
Page 60: Noise Reduction
Bi-spectrum network camera Visible Sensor Configuration User Manual Trans (D to Day transit to night. [Setting method] Drag the slider. [Default value] Trans (N to Night transit to day. [Setting method] Drag the slider. [Default value] Delay [Setting method] Drag the slider. [Default value] ----End 4.8 Noise Reduction...
Page 61 Bi-spectrum network camera User Manual Visible Sensor Configuration Figure 4-9 Noise Reduction Table 4-6 describes the parameters on the Special Function tab page. Table 4-6 Parameters of noise reduction Parameter Description Configuration Method 2D NR Auto /manual, default value is auto. [Setting method] By comparing and screening the images of the Drag the slider...
Page 62: Enhance Image
Bi-spectrum network camera Visible Sensor Configuration User Manual ----End 4.9 Enhance Image Figure 4-10 shows the enhance image Setting tab page. Figure 4-10 Enhance image Table 4-7 describes the parameters on the enhance image setting tab page. Issue V1.0（2021-10-25）...
Page 63 Bi-spectrum network camera User Manual Visible Sensor Configuration Table 4-7 Parameters of enhance image Parameter Description Configuration Method It is intended to provide clear image [Setting method] performance in strong backlight areas such as Drag the slider. exterior light coming through a window or [Default value] glass door.
Page 64: Thermal Sensor Configuration
Bi-spectrum network camera Thermal Sensor Configuration User Manual Thermal Sensor Configuration 5.1 Accessing the Sensor Interface Operation Procedure Step 1 On the Internet Explorer interface or the client software interface, choose channel 2 select and right-click the surveillance image to the set, as shown in Figure 5-1. Figure 5-1 Sensor configuration Or at “Configuration >...
Page 65: Mode
Bi-spectrum network camera User Manual Thermal Sensor Configuration Figure 5-2 Thermal channel sensor setting Step 2 Choose Sensor. The Sensor Configuration dialog box is displayed, as shown in Figure 5-3. ----End 5.2 Mode Figure 5-3 shows the Mode interface. Issue V1.0（2021-10-25）...
Page 66: Images
Bi-spectrum network camera Thermal Sensor Configuration User Manual Figure 5-3 Mode interface Operation Procedure Step 1 Click in the lower left corner of Sensor Setting, and choose Debug Mode. Step 2 Choose switch mode from the drop-down list Step 3 Time mode: Set the Start Time, set the End Time. Step 4 Click Save, the message "...
Page 67 Bi-spectrum network camera User Manual Thermal Sensor Configuration Figure 5-4 Image setting interface Step 1 Click in the lower left corner of Sensor Setting, and choose Debug Mode. Step 2 Drag the slider to adjust parameter of image. Step 3 Click Save, the message "Save succeed" is displayed, the system saves the settings. ⚫...
Page 68: Scene
Bi-spectrum network camera Thermal Sensor Configuration User Manual 5.4 Scene Figure 5-5 shows the Scene setting interface. Figure 5-5 Scene setting interface Step 1 Click in the lower left corner of Sensor Setting, and choose scene Step 2 Choose mirror mode from drop-list. Step 3 Click Save, the message "Save succeed"...
Page 69: Set Pseudocolor
Bi-spectrum network camera User Manual Thermal Sensor Configuration 5.5 Set Pseudocolor Figure 5-6 shows the Set pseudocolor setting interface. Figure 5-6 Set pseudocolor setting interface Step 1 Click in the lower left corner of Sensor Setting, and choose set pseudo color Step 2 Choose polarity/LUT mode from drop-list.
Page 70: Ffc Control
Bi-spectrum network camera Thermal Sensor Configuration User Manual ⚫ The temperatures of the temperature fields detected by the thermal imaging camera are separately mapped to values ranging from 0 to 255 by the algorithm. In the black/white display mode, this range is converted to the gray scale tones. For example, 0 indicates completely black, and 255 indicates completely white.
Page 71 Bi-spectrum network camera User Manual Thermal Sensor Configuration Figure 5-7 FFC control interface Table 5-1 lists the parameters on the FFC control interface. Table 5-1 Parameters on the FFC control interface Parameter Description Setting The internal of the thermal imaging camera may comprise the mechanical action correction mechanism that can periodically improve the image quality.
Page 72 Bi-spectrum network camera Thermal Sensor Configuration User Manual Parameter Description Setting operations can prevent the grainy and image degradation problems. The FFC is especially important when the temperature of the camera changes. For example, after the camera is powered on or the ambient temperature is changed, you should immediately perform the FFC.
Page 73: Noise Reduction
Bi-spectrum network camera User Manual Thermal Sensor Configuration Parameter Description Setting adjust Background Click the icon and camera perform the action. Manually adjust ----End 5.7 Noise Reduction Figure 5-8 shows the Noise reduction interface. Figure 5-8 Noise reduction interface Table 5-2 lists the Noise reduction parameters. Table 5-2 Parameters on the Noise reduction interface Parameter...
Page 74 Bi-spectrum network camera Thermal Sensor Configuration User Manual Parameter Description Setting noise. Select from the drop-down list box. [Default value] Close [How to set] Select from the drop-down list box. Decrease the image 3DNR noise. [Default value] Close ----End Issue V1.0（2021-10-25）...
Page 75: Intelligent Analysis
Bi-spectrum network camera User Manual Intelligent Analysis Intelligent Analysis There are many kinds of intelligent analysis, such as Perimeter, Single Virtual Fence, Double Virtual Fences, Multi Loiter, Converse, Personnel Count, Enter Area, Leave Area. The parameters of these analysis alarm are roughly similar, so we will describe someone in detail as a reference.
Page 76 Bi-spectrum network camera Intelligent Analysis User Manual Figure 6-1 Perimeter Setting Interface Step 2 Set all parameters for perimeter. Table 6-1 describes the specific parameters. Table 6-1 Perimeter Parameter Description Parameter Description Setting Channel Channel 1: visible light. Choose one channel to set. Channel 2: thermal.
Page 77 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Limit Target Effective alarms are set based on target [How to set] Type type, with options of Person or Car, Click to enable Limit Target person, car. When the device is used Type.
Page 78 Bi-spectrum network camera Intelligent Analysis User Manual Parameter Description Setting FTP Upload Enable the button to enable File [How to set] Transfer Protocol. Click to enable FTP Upload. [Default value] Step 3 Set a deployment area. Move the cursor to the drawing interface and click to generate a point, move the cursor to draw a line, and then click to generate another point.
Page 79: Single Virtual Fence
Bi-spectrum network camera User Manual Intelligent Analysis Figure 6-2 Deployment Time Setting Interface ----End 6.2 Single Virtual Fence Description A single virtual fence is a line that is set at a concerned position within the monitored field of view and specifies the forbidden travel direction; An alarm is generated when the targets of specified types (such as person or car) cross this line.
Page 80 Bi-spectrum network camera Intelligent Analysis User Manual Figure 6-3 Single Virtual Fence Setting Interface Step 2 Set all parameters for the single virtual fence. Table 6-2 describes the specific parameters. Table 6-2 Parameters of single Virtual Fence Parameter Description Setting Channel Channel 1: visible.
Page 81 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Limit Target Type Effective alarms are set based [How to set] on target type, with options of Click to enable Limit Person or Car, person, car. Target Type. When the device is used [Default value] indoors, because of small space and large targets, alarms are...
Page 82 Bi-spectrum network camera Intelligent Analysis User Manual Parameter Description Setting Alarm Record If you install SD card, enable [How to set] this function, the device will Click to enable Alarm record the alarm video. Record. [Default value] SMTP Enable the button to enable [How to set] SMTP sever.
Page 83: Personnel Count
Bi-spectrum network camera User Manual Intelligent Analysis 6.3 Personnel Count Description User can draw line to count the personnel at the special area. Procedure Step 1 Select Intelligent Analysis > Personnel Count to access the Personnel Count setting interface, as shown in Figure 6-4. Figure 6-4 Personnel count Issue V1.0（2021-10-25）...
Page 84 Bi-spectrum network camera Intelligent Analysis User Manual Step 2 Set all parameters for illegal parking. Table 6-3 describes the specific parameters. Table 6-3 Description of Parameters for Personnel Count Parameter Description Setting Channel Choose the channel [How to set] Choose from drop- down list.
Page 85 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Area Type Draw a line on live video screen. [How to set] The label of A and B indicate out and in. Choose from drop- down list. [Default value] Line Set Correction Enable, set the count correction value, it [How to set]...
Page 86 Bi-spectrum network camera Intelligent Analysis User Manual Parameter Description Setting SMTP Enable the button to enable SMTP sever. [How to set] The parameters of SMTP can be set at Click to enable SMTP. Configuration > Network Service > [Default value] SMTP interface.
Page 87 Bi-spectrum network camera User Manual Intelligent Analysis Method 2：Hold down the left mouse button, drag and release mouse to select the alarm time within 0:00-24:00 from Sunday to Saturday. When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected.
Page 88: Advanced Intelligent Analysis
Bi-spectrum network camera Advanced Intelligent Analysis User Manual Advanced Intelligent Analysis At advanced intelligent analysis interface, user can set the parameters of spark detection, smoke flame detection, fire spot detection. Enable the linkage actions, the alarm information can be send to user by the linkage. The advanced intelligent analysis can be used for detecting the smoking, if someone smoke in the indoor where is forbidden smoking.
Page 89 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-1 Spark intelligent analysis Interface Step 2 Set all parameters for perimeter. Table 7-1 describes the specific parameters. Table 7-1 Spark detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm.
Page 90 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Parameter Description Setting Alarm Record If you install SD card, enable this [How to set] function, the device will record the Click to enable Alarm alarm video. Record. [Default value] SMTP Enable the button to enable SMTP [How to set] serve.
Page 91: Smoke Flame Detection
Bi-spectrum network camera User Manual Advanced Intelligent Analysis ⚫ When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected. Deleting deployment time: Click again or inverse selection to delete the selected deployment time.
Page 92 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Figure 7-3 Smoke Flame Detection Interface Step 2 Set all parameters for perimeter. Table 7-2 describes the specific parameters. Table 7-2 Smoke Flame detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm.
Page 93 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Parameter Description Setting Alarm Record If you install SD card, enable this [How to set] function, the device will record the Click to enable Alarm alarm video. Record. [Default value] SMTP Enable the button to enable SMTP [How to set] serve.
Page 94: Fire Spot Detection
Bi-spectrum network camera Advanced Intelligent Analysis User Manual ⚫ When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected. Deleting deployment time: Click again or inverse selection to delete the selected deployment time.
Page 95 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-5 Fire Smoke Detection Interface Step 2 Set all parameters for perimeter. Table 7-3 describes the specific parameters. Table 7-3 Smoke Flame detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm.
Page 96 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Parameter Description Setting Alarm Record If you install SD card, enable this [How to set] function, the device will record the Click to enable Alarm alarm video. Record. [Default value] SMTP Enable the button to enable SMTP [How to set] serve.
Page 97 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-6 Set deployment area ⚫ A drawn line cannot cross another one, or the line drawing fails. ⚫ Any shape with 32 sides at most can be drawn. ⚫ The quantity of deployment areas is not limited yet and will be described in future when a limit is applied.
Page 98 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Figure 7-7 Deployment Time Setting Interface ---End Issue V1.0（2021-10-25）...
Page 99: Ai Multiobject
Bi-spectrum network camera User Manual AI Multiobject AI Multiobject Step 1 At “ Configuration > AI Multiobject ” interface, user can enable full-body detection, vehicle detection to detect the person and vehicle, as shown in Figure 8-1. Figure 8-1 AI Multi-object Step 2 Set the parameters of AI multi-object following as the Table 8-1 .
Page 100 Bi-spectrum network camera AI Multiobject User Manual Table 8-1 AI multi-object parameters Parameter Description How to set Full body The camera will snap the whole body when detection someone appear in live video. The detection frame Enable is blue. Vehicle The camera will snap the licence when the vehicle detection appear in live video.
Page 101: Alarm Setting
Bi-spectrum network camera User Manual Alarm Setting Alarm Setting 9.1 Alarm Output Procedure Step 1 Select Configuration > Alarm > Alarm Output to access the Alarm Output setting interface, as shown in Figure 9-1. Figure 9-1 Alarm output interface Step 2 Set alarm output of channel, name, enable valid signal and alarm time choose alarm output mode.
Page 102: Disk Alarm
Bi-spectrum network camera Alarm Setting User Manual 9.2 Disk Alarm Procedure Step 1 Select Configuration > Alarm > Disk Alarm to access the disk alarm setting interface, as shown in Figure 9-2. Figure 9-2 Disk alarm interface Step 2 Enable the disk full alarm, when the disk is full it will alarm. Step 3 Set alarm interval and tick output channel.
Page 103: I/O Alarm Linkage
Bi-spectrum network camera User Manual Alarm Setting Figure 9-3 Network alarm interface Step 2 Choose network card ID and enable exceptional alarm to set alarm interval. Tick output channel. Step 3 Click Apply to save the settings, click refresh will return last settings. ---End 9.4 I/O Alarm Linkage Procedure...
Page 104 Bi-spectrum network camera Alarm Setting User Manual Figure 9-4 I/O alarm linkage interface Step 2 Choose alarm input and trigger mode, set name, enable other linkages such as alarm input, PTZ linkage, Alarm Record SMTP and FTP upload. Step 3 Set alarm schedule, choose the duration of linkage. Step 4 Click Apply to save the settings, click refresh will return last settings.
Page 105: Motion Alarm
Bi-spectrum network camera User Manual Alarm Setting 9.5 Motion Alarm Procedure Step 1 Select Configuration > Alarm >Motion Alarm to access the Motion Alarm setting interface, as shown in Figure 9-5. Figure 9-5 Motion alarm interface Step 2 Choose channel and enable the motion alarm, set alarm interval and sensitivity, enable other linkages such as SMTP, FTP upload and motion detect stream.
Page 106: Push Message
Bi-spectrum network camera Alarm Setting User Manual 9.6 Push Message Procedure Step 1 Select Configuration > Alarm >Push Message to access the Push Message setting interface, as shown in Figure 9-6. Figure 9-6 Push message interface Step 2 Enable the push message, you will receive the message when the alarm happened. Step 3 Click Apply to save the settings, click Refresh will return last settings.
Page 107 Bi-spectrum network camera User Manual Alarm Setting Figure 9-7 Sound alarm output interface Step 2 Click to upload the audio file, browse the file, and the formate should be wav. There are 12 default files, you can listen and test the files. Step 3 Set alarm schedule, choose the duration of linkage.
Page 108: Audio Abnormal Output
Bi-spectrum network camera Alarm Setting User Manual Figure 9-8 Upload audio file Step 4 Click Apply to save the settings, click Refresh will return last settings. ----End 9.8 Audio Abnormal Output Procedure Step 1 Select Configuration > alarm >Audio Abnormal Output to access the Sound Alarm Output setting interface, as shown in Figure 9-7.
Page 109 Bi-spectrum network camera User Manual Alarm Setting Figure 9-9 Audio abnormal output interface Step 2 Enable the audio abnormal detection, enable sudden rise, sudden drop, when happen the condition of enable, it will alarm. Step 3 Tick the output channel, enable alarm record, SMTP, FTP upload. Step 4 Set alarm schedule, choose the duration of linkage.
Page 110: Other Web Configurations
Bi-spectrum network camera Other Web Configurations User Manual Other Web Configurations 10.1 Device Information You can view the information about device, as shown in Figure 10-1. Figure 10-1 Device information interface ---End 10.2 Stream 10.2.1 Base Stream Step 1 Choose Configuration >Stream >Base Stream, as shown in Figure 10-2. Issue V1.0（2021-10-25）...
Page 111: Svc Stream
Bi-spectrum network camera User Manual Other Web Configurations Figure 10-2 Base stream interface Step 2 Choose channel, stream ID, video encode type, video encode level, audio encode type, resolution, frame rate, frame interval, bit rate type and bit rate from all drop list. Step 3 Set name of base stream, enable smart encode.
Page 112: Roi
Bi-spectrum network camera Other Web Configurations User Manual Figure 10-3 SVC stream interface Step 2 Choose SVC stream ID, elementary stream ID and P frame rate from drop list. Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 10.2.3 ROI Step 1 Choose Configuration >...
Page 113: Snapshot
Bi-spectrum network camera User Manual Other Web Configurations Figure 10-4 ROI interface Step 2 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 10.2.4 Snapshot Step 1 Choose Configuration >Stream >Snapshot, as shown in Figure 10-5. Figure 10-5 Snapshot interface Step 2 Choose snapshot resolution and snapshot quality from drop list.
Page 114: Device
Bi-spectrum network camera Other Web Configurations User Manual 10.3 Device You can set local network, device port, data and time, camera, OSD, microphone, CVBS, system, voice denoise and software licenses, as shown in Figure 10-6. Figure 10-6 Device interface ---End 10.4 External Device Choose Configuration >External Device, enable PTZ, set parameters as shown in Figure 10-7.
Page 115: Privacy Masking
Bi-spectrum network camera User Manual Other Web Configurations Figure 10-7 External device interface ---End 10.5 Privacy Masking Choose Configuration > Privacy masking. You can set privacy masking if some area need keep secret, drag mouse to select the area to cover, double click will delete the setting, as shown in Figure 10-8.
Page 116: Network Service
Bi-spectrum network camera Other Web Configurations User Manual 10.6 Network Service Choose Configuration > Network Service. You can set 802.1x, DDNS, PPPoE, Port mapping, SMTP, IP filter, CGI alarm service center, SNMP and QOS 10.7 Privacy Manager Add user account, manage the users’ permission. As shown in Figure 10-9. Figure 10-9 Privacy manager interface 10.8 Protocol...
Page 117: Device Log
Bi-spectrum network camera User Manual Other Web Configurations Figure 10-10 Protocol interface 10.9 Device Log Choose configuration > device log. You can view operation log and alarm log, or collect all log information, as shown in Figure 10-11. Figure 10-11 Device log interface 10.10 Maintenance Choose configuration >...
Page 118: Local Config
Bi-spectrum network camera Other Web Configurations User Manual Figure 10-12 Maintenance interface 10.11 Local Config Choose configuration > local config. You can choose the snapshot picture format, change the save path of snapshot and local record, as shown in Figure 10-13. Figure 10-13 Local config interface Issue V1.0（2021-10-25）...
Page 119: Qos
Bi-spectrum network camera User Manual Other Web Configurations 10.12 QOS Description If the device is connected to a router or switch with a QOS function, and the priority rule of the corresponding mark is configured on the network device, the network device will preferentially pass the data packet of the corresponding mark.
Page 120 Bi-spectrum network camera Other Web Configurations User Manual Figure 10-14 QOS page Step 2 Input the value range from 0 to 63( audio/video dscp, alarm dscp and command dscp). Step 3 Click Apply. The message "Apply success!" is displayed, and the system saves the settings. ----End Issue V1.0（2021-10-25）...
Page 121: A Troubleshooting
Bi-spectrum network camera User Manual A Troubleshooting Troubleshooting Common Trouble Possible Cause Solution Unable to access Network is not Connect the network cable of the camera to the the web connected. PC to check whether the network cable is in good contact.
Page 122 Bi-spectrum network camera A Troubleshooting User Manual Common Trouble Possible Cause Solution The upgrade package Perform the correct upgrade package again. is incorrect. 1. Make sure ‘thermal mapping’ and ‘thermal calibration is configured The temperature correctly’ by checking if face square in thermal image is covering the is too high.
