Agilight LB-FRN-RGBW65-2-A Quick Start Manual

RGBW FLEXRAYZ NEON
FlexRayz Neon from AgiLight offers a versatile approach to border
tube that eliminates light gaps. A side-bending LED neon that
provides an excellent solution for linear façade lighting in curved or
straight runs, RGBW FlexRayz lets you tune your light to any of 16
million custom colors. Rated IP67 for use in damp and wet locations.
FlexRayz products are designed to bend; use Aluminum Mounting
Channel for straight run applications.

Applications:

• Borders and edges in signs and facades
• Neon replacements
• Cove and Accent lighting

Features:

• Available in pre-assembled 2 ft (0.61 m) or 8 ft (2.44 m) lengths or
sold in full reels of 16.4 ft (5 m)
• Full reels can be cut and finished with an end cap; new power
feeds cannot be introduced in the field
• 5.5 W/ft (18.04 W/m), 24 V DC
• RGB+6500K (4000K, 5000K upon request)
• 3.28 in. (83.3 mm) cut lengths

ORDERING GUIDE

Part Number
LB-FRN-RGBW65-2-A
LB-FRN-RGBW65-8-A
LB-FRN-RGBW65-16-A
LB-FRN-RGBW50-2-A*
LB-FRN-RGBW50-8-A*
LB-FRN-RGBW50-16-A*
LB-FRN-RGBW40-2-A*
LB-FRN-RGBW40-8-A*
LB-FRN-RGBW40-16-A*
* Special order only

SPECIFICATIONS

Input Voltage 24 V DC
Power Consumption 5.5 W/ft (18.04 W/m)
RGB+6500K (special orders for
Color
RGB+5000K and RGB+4000K)
Cuttable Length 3.28 in. (83.3 mm)
Max. Length
16.4 ft (5 m)
2 ft (0.61 m)
Available Lengths 8 ft (2.44 m)
16.4 ft (5 m)
Min. Bending Diameter 2 in. (50 mm)
Ingress Protection IP67
Impact Protection Rating IK08
L70 Lifetime @ 60° C
50,000 Hours
Warranty 5 Year Limited Warranty
AgiLight | Innovative Signage Lighting
Length Color
2 ft / 0.61 m
8 ft / 2.44 m RGB+6500K
16 ft 4 in. / 5 m
2 ft / 0.61 m
8 ft / 2.44 m RGB+5000K
16 ft 4 in. / 5 m
2 ft / 0.61 m
8 ft / 2.44 m RGB+4000K
16 ft 4 in. / 5 m
LUMINOUS INTENSITY DISTRIBUTION
Average Beam Angle (50%): 182.2°
RGBW FLEXRAYZ NEON
• 110x250° beam angle
• Use Aluminum Mounting Channel for straight runs
• Use S-type Track or Aluminum Mounting Clips for curves
Saltwater, solvent, and flame resistant
• IP67 ; IK08 impact protection
• Consistent brightness with constant current design
• Minimum bend diameter of 2 in. (50 mm)
All LEDs On Red
55 lm/ft 7 lm/ft
(180.4 lm/m) (23 lm/m)
55 lm/ft 7 lm/ft
(180.4 lm/m) (23 lm/m)
55 lm/ft 7 lm/ft
(180.4 lm/m) (23 lm/m)
Unit: cd
C0/180, 247.8°
C90/270, 116.5°
AgiLight is a quality division of GENLED Brands™ | www.AgiLight.com
LB-FRN-RGBW65-A
RoHS LM-80
Lumens
Green Blue
19 lm/ft 3 lm/ft
(62.3 lm/m) (9.8 lm/m)
19 lm/ft 3 lm/ft
(62.3 lm/m) (9.8 lm/m)
19 lm/ft 3 lm/ft
(62.3 lm/m) (9.8 lm/m)
RGBW
Color Changing
IP67
White
25 lm/ft
(82 lm/m)
25 lm/ft
(82 lm/m)
25 lm/ft
(82 lm/m)
REV.21DEC2022
| Page 1
