IRON DOG 06
User guide

Advertisement

Table of Contents
loading

Related Manuals for Brunner IRON DOG 06

Summary of Contents for Brunner IRON DOG 06

  • Page 1 IRON DOG 06 User guide...
  • Page 2 Welcome to the IRON DOG family. Eggenfelden, August 2007 Ulrich Brunner The name >>EISERNER HUND<< - >>IRON DOG<< - is a registered and protected mark. Individual models are registered as design patents. User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 3: Table Of Contents

    Basic principles....................... 13 Firewood and heating power..................14 Seasoning of firewood.................... 15 Amount of fuel......................16 Operation........................17 Heating with the Iron Dog..................19 Ashes.........................20 Cleaning and maintenance..................20 Hint..........................22 Error search......................23 Attention........................24 © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 4: My Iron Dog

    Nearly all components of the IRON DOG are made of solid cast iron. Ash boxes, screws and bolts are made of stainless steel. A special, temperature-firm color coating protects the surface. All components of this cast iron stove are manufactured and assembled in Germany with great care User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 5: Technical Data

    TECHNICAL DATA Illustr.1: Dimensions © 2013 Brunner GmbH User guide IRON DOG 06...
  • Page 6 Illustr.2: Components User guide IRON DOG 06 © 2013 Brunner GmbH...
  • Page 7 CG Soot door front K011114 CG Oven door K011068 CG Soot door K011083 CG right side fire chamber K011112 CG Steal corpus K011021 CG exhaust gas stub K008096 Firing door air control K011084 © 2013 Brunner GmbH User guide IRON DOG 06...
  • Page 8 CG Window firedoor K011097 14.4 BG Scheibe Feuerungstür K011133 14.5 Inner window fire door K011058 14.6 CG Doorhandle K007018 14.7 Cylindric screws M8 x 16 14.8 Set screw M8 x 30 User guide IRON DOG 06 © 2013 Brunner GmbH...
  • Page 9 4 Start-up valve push rod 5 Air control push rod 6 Oven 7 Fire door 8 Stow compartment (Grill grate / Control levers) 9 Soot door 10 Grill grate 11 Grill grate levers © 2013 Brunner GmbH User guide IRON DOG 06...
  • Page 10 Illustr.5: Components Iron Dog 06 Two control levers are given with the Iron Dog 06. They are used for operation of the stove top covers as well as for the grill grate. During combustion the pivoting stove top cover must always be closed. Fire risk! Illustr.6: Minimal distances...
  • Page 11 Fire chamber depth Reccommended log lenght 25 - 33 Total weight cast iron Minimal distances to side wall to rear wall (with radiation sheet) to rear wall (without radiation sheet) Homologations EN 12815 © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 12: Safety Guidelines

    There is the danger of a flue gas poisoning. The fire chamber of the IRON DOG is also to be kept closed when the stove is not heated. User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 13: Basic Principles

    – flame and flue gases must visibly take off). In case of too little draught first light kindling and add burning wood when the draught has been created. © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 14: Firewood And Heating Power

    500 kg x 2.0 kWh/kg = 1000 kWh 500 kg dried wood Water content 30% 500 kg x 3.3 kWh/kg = 1650 kWh 500 kg dry wood Water content 15% 500 kg x 4.1 kWh/kg = 2050 kWh User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 15: Seasoning Of Firewood

    Firewood should be stored under a roof or in a ventilated building (shed). Do not store freshly cut wood in the cellar or in a closed area. It can’t dry there. Our best 3 tips for heating with wood to become an experience. 1) dry wood © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 16: Amount Of Fuel

    To large amounts of fuel or unsuitable fuel can lead to excessive heating and thus to damage. Filling weight Log lenght Log size 1,5 kg - 3,0 kg 25 cm - 33 cm 20 cm - 30 cm User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 17: Operation

    Before initial operation Before initial operation please grease the stove top and covers, the grill grate and the oven with edible oil and heat up the Iron Dog 06. Firing door Note that the firing door is opened in a clockwise direction. (See picture;...
  • Page 18 It can simply be pulled out and with the help of the two levers it can be pushed through the firing door and slid above the glow in the firing chamber. User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 19: Heating With The Iron Dog

    When the wood has burned down (glow phase) new wood can be added. Bring the push rod in its “Start- up” position for about 5 minutes. Then bring it back in its “nominal heat output” position. © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 20: Ashes

    Subsequently wipe with a dry cleansing tissue. Do not use scrubbing tools or aggressive cleaning agents! The Iron Dog should be examined by your specialized enterprise regularly. User guide IRON DOG 06 © 2013 Brunner GmbH...
  • Page 21 If the soot door should not loosen after opening the two levers (13) on the side, it can be loosened with the help of the two forcing screws (14). Don’t forget to screw back the forcing screws so that the soot door can be put on and closed again. © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 22: Hint

    The IRON DOG should be examined by your specialized enterprise regularly. Non conform use of the equipment leads to expiring of the guarantee! The intended use of the equipment is guaranteed when the guidelines of the User Guide are observed. User guide IRON DOG 06 © 2013 Brunner GmbH...

  • Page 23: Error Search

    Check whether other stoves or fireplaces The chimney draught can be worsened by are connected to the chimney. other connected fireplaces. © 2013 Brunner GmbH User guide IRON DOG 06...

  • Page 24: Attention

    IRON DOG - Partner: Purchase date: Ulrich Brunner GmbH Zellhuber Ring 17-18 D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 Fax: +49 (0) 8721/771-100 Email: info@brunner.de For updated documentation, visit: www.brunner.de User guide IRON DOG 06 © 2013 Brunner GmbH...
