M A D E L
• The fire dampers
FMC-EIS-120
between two sectors of fire and ensure the same fire
resistance that the structural elements of
compartmentalisation, which limits the risk of spreading
of fire by interior of the building.
• FMC-EIS-120 fire dampers are according with the
following standards:
European Test Standard, EN 1366-2
(Fire resistance tests for service installations –
Part 2: Fire dampers)
European Classification Standard, EN 13501-3
(Fire classification of construction products and building
Part 3: Classification using data from fire resistance tests on
products and elements used in building service installations:
fire resisting ducts and fire dampers)
European Standard for CE Marking, EN 15650
(Ventilation for buildings. Fire dampers)
European Test Standard, EN 60529:1991
(Degrees of protection provided by enclosures (IP Code))
European Test Standard EN 1751
(Ventilation for buildings –
Air terminal devices –
Aerodynamic testing of dampers and valves)
International Test Standard ISO 10294-4
(Fire resistance tests – Fire dampers for air distribution systems
Part 4: Test of thermal release mechanism)
1
â
FMC-EIS-120 fire dampers EIS-120
work as a separator
elements –
• The casing is made of galvanised steel, and joined by
welding.
• The housing is made from galvanized steel. It has a
symmetrical design that allows wall mounting regardless
of air flow.
• The blade is made of ceramic material resistant to high
temperatures and abrasion.
• These dampers meet the conditions required for the
symbol (S) to cold smoke seal. In case of fire, smoke
poisoning is the leading cause of death.
• The airtightness to the passage of cold smoke is
achieved through a joint between the perimeter of the
housing and the blade. This design, together with the low
thickness of the blade, allow to minimize the pressure
loss..
• For high temperatures, the damper is equipped with an
expanding intumescent seal, forming a paste that prevents
the passage of hot air and smoke from one side of the
damper to another.
• A rubber sealing ring at both ends of the casing ensures
an airtightness between the damper and the ducts.
• The operating devices of the dampers is automatic
shooting by means of a thermal fuse calibrated at 72 °C to
activate the closure when reaches that temperature. Reset
is manual except for motorized dampers.
EN 15650:2010
09/15
