IsoLux IsoLED PLUS + Operation Manual page 8

Table A1: Li-Ion rechargeable Battery care
Battery care
Best way to
charge
Charge
methods
Discharge
How to prolong
battery
Storage
Disposal
Table A2: Estimates the number of discharge/charge cycles Li-ion can deliver at
various DoD levels before the battery capacity drops to 70 percent. DoD
constitutes a full charge followed by a discharge to the indicated state-of-charge
(SoC) level in the table.
Depth of discharge
100% DoD
80% DoD
60% DoD
40% DoD
20% DoD
10% DoD
Isolux's Battery system design provides the following Battery Life extension
advantages:
Maximum Battery voltage:
•
Depth of Discharge (DoD):
•
• Maximum Charge Current:
IsoLux llc,1045 Collier Center Way, Suites 6/7 Naples, Florida USA 34110 phone: 239 514 7475
Fax: 239 514 7476 email:
8
Partial and random charge is fine; does not need full charge; lower
voltage limit preferred; keep battery cool.
Constant voltage to 4.20V/cell; no trickle charge; battery can, no trickle
charge, battery can stay in charger
Rapid charge = 3h (recommended)
Fast charge = 1h
Prevent full cycles, apply some charge after a full discharge to keep the
protection circuit alive.
Keep cool. Operate in mid SoC of 30–80%. Prevent ultra-fast charging
and high loads (most Li-ion)
Store at 40% charge in cool place (40% SoC reads 3.75–3.80V/cell). Do
not go below 2.0V/cell.
Low toxicity. Can be disposed in low volume. Best to recycle.
Discharge cycles
~300 / 600
~400 / 900
~600 / 1,500
~1,000 / 3,000
~2,000 / 9,000
~6,000 / 15,000
4.2 V/cell (8.4 V for IsoLED Plus +)
4.2 v – 3 v = 1.2 v/cell = 29 % (For minimum
of 1000 cycles)
1.3 A = 1.3/3.5 = 0.37C Charge Rate
info@isoluxllc.com web:
Lithium-ion rechargeable Batteries
Table A2: Cycle life as a function
of
depth of discharge.* A partial
discharge reduces stress and
prolongs battery life, so does a
partial charge. Elevated
temperature and high currents also
affect cycle life.
Note: 100% DoD is a full cycle;
10% is very brief. Cycling in mid-
state-of-charge would have best
longevity.
