Features and Benefits
•
Conforms to USB Specification, Rev. 2.0
•
Compliant with CompactFlash memory
card specifications
•
Hot-swapping feature allows you to
connect/disconnect the reader/writer
without first shutting down your system
•
Works with various capacities (up to 1
GB) of Type I/II CompactFlash memory
cards from SanDisk, Lexar, Kodak, other
brands and IBM Microdrive
•
Low power consumption, the reader/
writer draws power from the system. No
power adapter required!
Important: This reader only achieves USB 2.0
speed when connected to a working USB 2.0
port. If it's connected to a USB 1.1 port, it will
operate at USB 1.1 speed.
04-0272C
USB 2.0 CF Reader/Writer
Quick Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG US2274
Summary of Contents for SIIG US2274
- Page 1 USB 2.0 CF Reader/Writer Quick Installation Guide Features and Benefits • Conforms to USB Specification, Rev. 2.0 • Compliant with CompactFlash memory card specifications • Hot-swapping feature allows you to connect/disconnect the reader/writer without first shutting down your system • Works with various capacities (up to 1 GB) of Type I/II CompactFlash memory cards from SanDisk, Lexar, Kodak, other...
- Page 2 Layout Activity/Access Type A connector Memory Card Slot Figure 1. Layout Figure 2. USB cable...
- Page 3 System Requirements • PC or MAC computer with one available USB 2.0 or 1.1 port • Windows 98SE/ME/2000/XP/Server 2003 • MAC OS 9.x or later Package Contents • (1) USB 2.0 CF Reader/Writer • (1) USB cable • (1) Driver CD •...
- Page 4 Direct Connection Connect the reader/writer by inserting the Type A connector directly into your system's USB port. Connect Using the Included USB Cable Connect the USB cable to your system's USB port. This USB cable has two different connectors. Only one connector fits your system's USB port.
- Page 5 At the Add New Hardware Wizard, click Cancel. Restart the computer if this doesn't appear and start the software installation again. Insert the Driver CD. Autorun should start, if not, click Start, then Run. Click Browse, choose your CD-ROM drive, double click Autorun.exe, and click OK.
- Page 6 Mac OS Mac OS operating systems have built-in driver for your reader. Simply connect the reader and the driver will install automatically. A drive icon will show up on the desktop when a memory card is properly inserted into the reader/writer. Inserting Memory Cards CompactFlash memory cards and IBM Microdrives are keyed for proper and easy...
- Page 7 The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below.
- Page 8 PRODUCT COMPLIANCE SIIG, Inc. 6078 Stewart Ave. Fremont, CA 94538-3152 USB 2.0 CF Reader/Writer is a trademark of SIIG, Inc. All other names used in this publication are for identification only and may be trademarks of their respective companies. July, 2004...
