IMPORTANT SAFETY INSTRUCTIONS

WARNING: To reduce the risk of electric shock, do not remove the front or back covers.
No user-serviceable parts inside. Refer servicing to qualified service personnel only.
The lightning flash with arrow-head
within a triangle is intended to inform
the user that parts inside the product
are a risk of electric shock.
WARNINGS & PRECAUTIONS
!
To prevent damage which may result in fire or shock hazard, do not expose this product to rain or
moisture.
!
To prevent electric shock, do not remove cover. No user serviceable parts are inside. Refer servicing to
qualified service personnel only.
Keep display away from excessive dust, high temperatures, moisture or direct sunlight.
!
!
Use in a well-ventilated area and do not cover ventilation openings.
!
Unauthorized modification this equipment or usage of an unshielded connecting cable may cause
excessive interference.
!
When the display is not in use for a long period of time, disconnect it from the electric outlet.
If the picture displayed is in any way abnormal, turn off the unit and disconnect it from the electric
!
outlet. Verify your signal wire connections and reconnect the display to the electric outlet.
!
Disconnect from the electric outlet before cleaning. Do not use liquid or aerosol cleaners. Use only a
slightly damp cloth for cleaning.
!
Do not place this product on an unstable cart, stand or table. The product may fall, causing serious
damage.
!
Do not place the unit on a bed, sofa, rug, or other similar surfaces. Never place the unit near or over a
radiator or heat source. Do not install unit in an enclosed area unless proper ventilation is provided.
!
The unit should be operated from the type of power source indicated on the label. If the type of available
power is unknown, consult your dealer or local power company.
!
The unit is equipped with a 3-pin grounded plug. The plug will only fit into a grounded power outlet. This
is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician. Do not
alter the plug; this will defeat the safety feature.
!
Do not rest objects on the power cord & avoid placing power cord near high traffic areas.
!
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
!
Disconnect the unit from the main supply and refer servicing to qualified service personnel under the
following conditions:
Power cord or plug is damaged or frayed.
Liquid has been spilled into the product.
Unit has been exposed to water or moisture.
Unit does not operate normally when the operating instructions are followed. Adjust only those
controls that are covered by the operating instructions, improper adjustment of other controls may
result in damage which often requires extensive work by a qualified technician to restore the unit to
normal operation.
Unit has been dropped or the cabinet has been damaged.
Unit exhibits a distinct change in performance, indicating a need for service.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within a triangle
is intended to tell the user that important
operating and servicing instructions are
explained.
1

Advertisement

Table of Contents
loading

Summary of Contents for Maxent MX-42VM7

  • Page 1: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of electric shock, do not remove the front or back covers. No user-serviceable parts inside. Refer servicing to qualified service personnel only. The lightning flash with arrow-head within a triangle is intended to inform the user that parts inside the product are a risk of electric shock.
  • Page 2: Table Of Contents

    PASSCODE Setting ... 28 Signal Frequency Information Display ... 29 ADVANCED CALIBRATION ... 30 ADJUSTING PICTURE For TV / AV / Component Video(480i signal)... 34 For Component Video(480p, 720p and 1080i signal) ... 35 For RGB / DVI ... 37 TROUBLESHOOTING ... 38 SPECIFICATIONS ...
  • Page 3: Fcc Statement

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at the user’s own expense.
  • Page 4: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cautions When Using the Plasma Display Do not bring your hands, face or objects close to the ventilation holes of the plasma display. Top of plasma display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.
  • Page 5: Product Features

    ! ! ! ! ! TV Tuner Option An optional television tuner module turns this display into a standard TV receiver. ! ! ! ! ! Picture-in-Picture (PIP) Watch two programs simultaneously using the display’s picture-in-picture with four selectable...
  • Page 6: Package Contents

    Plasma Display Power Cable Optional Accessories The following accessories are available and may be purchased from your local sales representative: Add-On TV Tuner Module Wall Mount Composite Video Cable (RCA) S-Video Cable (Mini-Din) Component Video Cable (RCA to RCA) Audio Cable (RCA Cable)
  • Page 7: Understanding Your Display

    Volume Adjustment +/- Buttons Use these buttons to adjust volume up and down. These keys also serve as adjustment keys when On Screen Display is engaged. Video Connectors (without TV Tuner) Video Connectors (with TV Tuner) RGB / Computer Related Connectors...
  • Page 8: Full Function Remote Control

    Push this button to turn on the display from Standby mode. Push it again to turn off to Standby mode. Number Keypad* Use number keypad to select the TV channel you want to watch. QuickView* Use QuickView key to recall the last channel watched.
  • Page 9: Connecting The Display

    Connecting a DVD Player Using Component Video Input 1.Connect the green-colored (labeled as “Y”) jack from the DVD to the green-colored “Y1” jack of the display. 2.Connect the red-colored (labed as “P from the DVD to the red-colored “P the display. 3.Connect the blue-colored (labed as “P jack from the DVD to the blue-colored “P jack of the display.
  • Page 10: Connecting A Hdtv Decoder Set-Top Box

    CONNECTING THE DISPLAY Connecting a HDTV Decoder Set-Top Box Using Component Video Input 1.Connect the green (labeled as “Y”) jack from the HDTV Set-top box to the green “Y1” jack of the display. 2.Connect the red (labed as “P the HDTV Set-top box to the red “P the display.
  • Page 11: Connecting A Vcr

    If there is a threaded-screw type of connector (called the RF connector), then you have a TV tuner. If you do not see this type of connector, then you do not have a TV tuner installed. 2.Connect the RF cable from the antenna or cable socket to the RF connector labeled as “ANT”...
  • Page 12: External Audio Connections

    CONNECTING THE DISPLAY External Audio Connections Connecting External Amplified Speakers 1.This display can be connected to an external set of amplified speakers using the AUDIO OUT jacks located on the back of the display. In addition, this display is equipped with a small 3.5 mm phono style plug for remote turn-on applications that will automatically send a remote turn-on/off signal to the external amplified speakers.
  • Page 13: Connecting A Pc

    Connecting a PC Using RGB or DVI Video Input 1.For most PC’s, connect the 15-pin D-Sub RGB connector from the back of the PC to the RGB-IN Connector located on the back of the display. If you have a PC that is equipped with a DVI (Digital Visual Interface), you may connect the PC DVI connector from the back of the PC to the DVI-In Connector located on the back of the display.
  • Page 14: Rs-232 Remote Control Connections

    H-Size 01-64H H-Position 01-64H Color 01-64H Tint 01-64H Sharpness 01-64H Input Select 00-07 00=TV, 01=AV1, 02=AV2, 03=AV3, 04=Component 1, 05=Component 2, 06=RGB, 07=DVI Recall 00=Initiate recall Mute On/Off 00-01 00=Off 01=On PanelKey Lock96 00-01 00=Off 01=On Basic Format for Command Parameters In order to transmit data from the computer to the display, the data must be sent in 1-byte-hex format.
