Owner's Manual
MX-26X3
1.
26" 16:9 WXGA LCD Display
2.
16.77 Million Colors
3.
High Contrast Ratio (800:1)
4.
High Brightness (500 cd/m2)
5.
Multi-scanning PC Monitor Support Up to 1280 x 1024
6.
170 Degrees Viewing Angle
7.
RS-232 Control Port
8.
Built-In Speaker: 10W + 10W
Specification
Display
Screen Size
Aspect Ratio
Pixel Resolution
Pixel Pitch
Contrast Ratio
Brightness
Displayable Colors
Viewing Angle
Response Time
Signals
Synchronization (Auto Detect)
Horizontal Frequency
Vertical Frequency
Video System
RGB Resolution
RGB/DVI
DVI Input (with HDCP)
RGB Input
RGB Output
Audio Input
Audio
Integrated Speaker Output
Video Capability
NTSC Tuner Input
Composite Video Input
S-Video Input
Component Video Input
Audio Input
Audio Output
External Subwoofer Output
Control Port
RS-232
General
Power Supply
Power Consumption
Dimensions
Weight
Optional Accessory
Wall Mount Bracket
Design and specifications are subject to change without notice.
480i, 480p, 720p, 1080i SDTV/EDTV/HDTV, NTSC
RCA-pin x 2 Sets (Y/CB/CR, Y/PB/PR auto detect)
W/Stand
870.6mm x482.7mm x225.6mm/34.27"x 19.00"x 8.88"
WO/Stand
870.6mm x416.8mm x107.4mm/34.27"x 16.40"x 4.23"
W/Stand
WO/Stand
Horizontal Mount with 4 Selectable Inclination Angles
MX-26X3
575.77 mm x 323.71 mm (26" Diagonal)
16 : 9
1366 (H) x 768 (V)
0.4215 mm (H) x 0.4215 mm (V)
800 : 1
500 cd/m²
16.77 Million Colors
170˚
12 msec
15KHz / 31~69 KHz
60 Hz
Up to 1280 x 1024 (SXGA)
DVI-D 24 pin x 1
D-Sub 15-pin x 1
D-Sub 15-pin x 1
RCA-pin (L/R) x 2 Sets
10W x 2
RF 181CH x 1
RCA-pin x 2
Mini DIN 4-pin x 2
RCA-pin (L/R) x 4 Sets
RCA-pin (L/R) x 1 Set
RCA-pin Type x 1
D-Sub 9-pin x 1
100V~240V/50~60Hz
180W +/- 10%
28.20 lbs
22.04 lbs
