RBC-12-NG & RBC-24-NG
Page 3 of 4
the brake light switch. If this is not an option for your vehicle, then any point that receives a straight DC voltage should
be applicable. For example- top rear tail light, brake light relay or the wire connecting to the stop lights on the trailer plug.
lights directly. Please use the alternatives listed above.
the negative battery terminal.
Connecting to the existing wiring may damage the vehicles wiring and cause trailer brake failure.
1) Refrain from using the vehicle chassis as a conduit for the earth return for the brake coils. Facilitate a separate
ground wire. (See point 3 below)
Page 3 of 4
Installation & Operating Instructions
Please read these instructions before use
A brake control unit that is not properly grounded may operate intermittently or not at all.
Unit 2, 110 Station Road, Seven Hills ,NSW, 2147, Australia
More information https://www.caravansplus.com.au
Negative Battery
Brake
Positive Battery
Fuse : 12V 20A / 24V 15A
Brake Switch
RBCNG-R2
