- Page 1 Scandi - 6+6 Drawer Chest Assembly Instructions - 1020401 Please keep for future reference Dimensions Width 123.3 cm Depth 39.7 cm Height 104.3 cm Assembly Instructions - Please keep for future reference Issue 1 - 23-01-2013 350218-01-MDF...
- Page 2 ! Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause pages 2 and 3. damage.
- Page 3 Components - Panels Components - Panels Please check you have all the parts listed below Please check you have all the panels listed below Plinth, back (123,3 cm x 39,7 cm) Plinth, front (117,9 cm x 6 cm) (119,1 cm x 9,6 cm) Back (94,4 cm x 39,6 cm) Divider...
- Page 4 Components - Fittings Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ø7.8 x 40mm Wooden dowel x ø6 x 30mm Wooden dowel x 48 ø4 x 60mm Screw x ø3 x 35mm Screw x...
- Page 5 Assembly Instructions Step 1 Fix the drawer sides to the drawer backs as shown, using screws Step 2 Knock the dowels into the holes indicated on the drawer sides using a smal hammer. Step 3 Slide the drawer bottoms into the drawer sides Step 4 Screw the bolts...
- Page 6 Assembly Instructions Step 5 Push the drawer fronts onto the drawer sides shown. Push cams into the holes indicated. Arrow pointing towards the front. Turn the cams to the right to fix the fronts. Step 6 Important! Make sure the angle between the drawer fronts 90°...
- Page 7 Assembly Instructions Step 8 Knock the dowels into the holes indicated on the divider using a small hammer. Step 9 Slide the top of the drawer runners backwards. Fix the front end of the drawer runners the divider using screws into the holes indicated.
- Page 8 Assembly Instructions Step 11 Cb Ke Knock the dowels into the holes indicated on the sides Screw the bolts into the holes indicated on the sides Fix the angles to the sides using screws . Place the angles as shown. See details.
- Page 9 Assembly Instructions Step 14 Screw the bolts into the holes indicated on the top Step 15 Place the divider onto the top Its important that the divider is placed exactly as shown. Note the holes indicated. Tighten using cams into the holes indicated. Push cams into the holes indicated.
- Page 10 Assembly Instructions Step 17 Place the sides onto the back plinths Push cams into the holes indicated on the back plinths Arrow pointing towards the sides Turn the cams to the right to fix the sides Step 18 Press the top onto the sides Push...
- Page 11 Assembly Instructions Step 19 Turn around the chest. Place the front plinth as shown. Fix the front plinth the sides using screws into the angles Fix the foot onto the back plinth using screw Step 20 Place the backs into the rabbets in the sides and the and into the...
- Page 12 Assembly Instructions Step 21 Warning! The chest of drawers is heavy. Lift with care. Its recommended that the Wall strap and instruction chest is fixed to the wall. Use the fittings . Follow the instructions included with the fittings. Step 22 Pull out the drawer runners.
