Battery Maintainer Model No. PL2112
No. 141-112-000
Failure to follow instructions may cause
damage or explosion, always shield eyes.
Read entire instruction manual before use.
This product can expose you to chemicals, including
Vinyl-Chloride, Styrene and Acrylonitrile, which are
known to the State of California to cause cancer.
Manual
WARNING
WARNING
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Pro-Logix PL2112
Summary of Contents for Pro-Logix PL2112
- Page 1 Manual Battery Maintainer Model No. PL2112 No. 141-112-000 WARNING Failure to follow instructions may cause damage or explosion, always shield eyes. Read entire instruction manual before use. WARNING This product can expose you to chemicals, including Vinyl-Chloride, Styrene and Acrylonitrile, which are...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS - READ THESE FIRST WARNING Read these instructions completely before using the Battery Charger and save them for future reference. Before using the Battery Charger to charge a battery, read these instructions and the instruction manual/safety information provided by the car, truck, boat or equipment manufacturer. Following all manufacturers’...
-
Page 3: Personal Precautions
7. To prevent electric shock - Dispose of battery charger contains important safety and operating instructions if cord becomes defective. for Model No. PL2112. 8. Do not operate charger if it has received a sharp blow, 2. Do not expose charger to rain or snow. -
Page 4: Locating The Charger
PREPARATION PREPARING TO CHARGE BATTERY: 1. If it is necessary to remove battery from vehicle to 4. Add distilled water in each cell until battery acid charge, always remove grounded terminal from battery reaches level specified by battery manufacturer. This first. - Page 5 CHARGING A BATTERY THAT IS INSTALLED IN A VEHICLE CAUTION: A MARINE (BOAT) BATTERY MUST BE REMOVED AND CHARGED ON SHORE. TO CHARGE IT ON BOARD REQUIRES EQUIPMENT SPECIALLY DESIGNED FOR MARINE USE. CAUTION: A SPARK NEAR BATTERY MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK OF A SPARK NEAR BATTERY: 1.
- Page 6 OPERATING INSTRUCTIONS BATTERY CHARGING SETTINGS Note: The charger is designed to protect against faults and shorts (see Battery Charger Features). If the Upon making a proper battery connection (see Section battery to be charged has an open circuit voltage of F or G as applicable), plug AC power cord into an AC less than 1V, the charger will indicate a fault.
-
Page 7: Additional Features
CHARGING LED will flash. This indicates the charge time will be extended while the charger attempts to recondition the battery. PRO-LOGIX PHASES 5-7: IDEAL BATTERY MAINTENANCE A key feature of this charger is how it manages a battery that remains on the charger after a complete charge has been achieved, such as during the storage of a seasonal use vehicle. - Page 8 OVER-VOLTAGE PROTECTION Guards against charging errors where the charger is programmed to charge in a different voltage than the detected voltage of the battery. When this safeguard is engaged, the ERROR LED will slowly flash (2.0s-ON/2.0s-OFF). To reset the charger, disconnect from AC outlet, reset the vehicle connections and reconnect to the AC outlet. CHOOSING THE BATTERY TYPE For Conventional and Maintenance Free flooded (wet) batteries, the ideal Battery Type selection is “STD”.
