Instruction Manual
KRUUSE ART-SP2 Piezo scaler
and micromotor
JØRGEN KRUUSE A/S
DK-5550 Langeskov.
Tlf:
Fax:
Cat. No 271390
Havretoften 4
+ 45 7214 1511
+ 45 7214 1400
www.kruuse.com
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ART-SP2 and is the answer not in the manual?

Questions and answers

Related Manuals for KRUUSE ART-SP2

Summary of Contents for KRUUSE ART-SP2

  • Page 1 Instruction Manual KRUUSE ART-SP2 Piezo scaler and micromotor Cat. No 271390 JØRGEN KRUUSE A/S Havretoften 4 DK-5550 Langeskov. Tlf: + 45 7214 1511 Fax: + 45 7214 1400 www.kruuse.com...
  • Page 2 Product specifications, as well as information presented in this manual, are subject to change without prior notice. PROPERTY OF BONART MEDICAL TECHNOLOGY INC. ALL RIGHTS RESERVED ART-SP2 is trademark of BONART MEDICAL TECHNOLOGY INC. Other brands and product names are trademarks or registered trademarks of their respective holders.
  • Page 3 WARNING: Calls attention to a potential danger that requires correct procedures or practices in order to prevent personal injury. SYMBOLS: “BF” symbol, indicates the ART-SP2 was manufactured according to the degree of protection against electric shock for this type BF equipment.
  • Page 4 A patient with pacemaker cannot be treated with the equipment. A shielded AC power cord must be used with this equipment. ART-SP2 should be powered from a separate wall outlet with grounding point. Attention! Avoid use of this machine around Pacemakers.
  • Page 5 Note before using: • The electric power used must be grounded. If this requirement is not met, it could cause damage to the Scaler and more importantly harm to the user. • The machine should be placed on a steady and stabled platform or table.
  • Page 6 The ART-SP2 is a very powerful apparatus. There are linear scales of power adjustment for removing prostheses and condensing gutta-percha. This allows very fine adjustment to suit each clinical situation. With a large range of Tips, the ART-SP2 is suitable for different kinds of work. ART-SP2 Operation Frepuency:29 KHz...

  • Page 7: Table Of Contents

    Contents Contents ........................1 I. Descriptions and Functionalities of Components...........2 Descriptions of Components..................2 Description of Control Panel .................4 II. Installation Guide ....................6 III. Preparation and Practice before the First Use............9 IV. Operation Procedures..................11 V. Maintenance ......................13 VI. Cleaning and Sterilization..................14 . Accessories ......................16 VIII.

  • Page 8: Descriptions And Functionalities Of Components

    I. Descriptions and Functionalities of Components Descriptions of Components Figure 1. ART-SP2 Outlook diagram 1. Main Unit It is the heart of the scaler. Functionally, the main unit generates the needed 29KHz-operation-signal and passes it on to the Handpiece, and thus induces power to vibrate the Insert inside the Handpiece accordingly.
  • Page 9 3. Footswitch The convenient footswitch helps doctors to easily turn on/off the scaler without interrupting the cleaning process at hand. 4. Water Tubing 5. AC Line Socket Seat 6. Micro-Motor This is a DC micro-motor. Micro-motor speed will be reacted from input voltage reacted.

  • Page 10: Description Of Control Panel

    Description of Control Panel The function of each button or knob on the control panel is listed detail below. Figure 2. ART-SP2 Front-panel 1. M OWER WITCH Indicating the main power switch. When pushed, the AC power is sent to the Main Unit, and the power indicator (LED) will be lit up.
  • Page 11 “Polishing” model. During this model, the micro-motor output power will increase. If pushed the button again, the operation model will back to “scaling” model. “BF” symbol, indicate that the ART-SP2 was according to the degree of protecting against electric shock for type BF equipment.

  • Page 12: Installation Guide

    II. Installation Guide 1. Unpacking When unpacking the box, check this unit for any damages. If damaged, please contact your dealer immediately. Enter the unit serial number on your warranty card mail it within 10 days after setting up the machine. 2.
  • Page 13 Scaler and connect the components as shown in the figure below. Note: When unpacking the box, check ART-SP2 for any damages. If damaged, please contact your dealer immediately. Enter the unit serial number on your warranty card mail it within 10 days after setting up the machine.
  • Page 14 1. Check ART-SP2 and make sure the both power and power indicator is off when the switch is off. 2. Put the scaler into a grounded outlet. 3. Choose the correct scalering Tip for desired procedure, and insert it into the handpiece.

  • Page 15: Preparation And Practice Before The First Use

    III. Preparation and Practice before the First Use To better utilize all the functions and maximize the performance of the Bonart Scaler, it is suggested that before treating patients, users/doctors should practice on models/aluminum plates to familiarize themselves with the system. Maneuver the head of the Tip to make gentle touch on an aluminum plate.
  • Page 16 C. Tangential Application (E3 TIP) Contact on the enamel with the rounded Ttip without pressure when movement.

  • Page 17: Operation Procedures

    IV. Operation Procedures When preparing to treat a patient: Step1: Push the POWER SWITCH to light the ON indicator (LED). Step2: Check the water. Step3: Select the needed Tip, make sure it is fully seated with the Handpiece. Step4: Set the POWER KNOB to the suitable level for the insert. Step5: Hold the Handpiece with the Tip end pointing up over a suitable drain.
  • Page 18 5. Water and Temperature The WATER KNOB control the volume and temperature of water flowing from the Handpiece by turning the WATER KNOB clockwise or counterwise until the desired rate of flow is obtained. When preparing to execute “Polishing” model: 1.

  • Page 19: Maintenance

    V. Maintenance The Bonart unit does not need special maintenance routines but it does need to be regularly and thoroughly cleaned and sterilized (as described in next section). Daily start-up When starting the unit at the beginning of the day: *Open the water supply shut-off valve.

  • Page 20: Cleaning And Sterilization

    VI. Cleaning and Sterilization In this section we describe the procedures to clean and sterilize the scaler. It is important to follow these procedures before using the machine, otherwise, patients and/or doctors may have the possibility of getting infection. It is mandatory that doctors wear sterilized gloves during these procedures at all time to avoid any possibilities of incomplete sterilization and/or infection.
  • Page 21 Warning: High room temperature conditions, improper dilutions, or excessive immersion time in a chemical sterilant can result in damage to the plastic and elastomeric materials of the Tips. Caution: The use of a dry heat oven, incompatible chemical vapor type sterilizers or quaternary ammonium compounds must be avoided as damage can result to the plastic and elastomeric materials.

  • Page 22: Accessories

    . Accessories (1) Footswitch x1 (2)AC Power Line x1 (3) Three-way switch x1 (4)PU Tube x1 (5) TORQUE WRENCH SET BOX x1 (6)Piezo Handpiece x1 (7)E5 E2 E3 TIP (8) E-type Micro-motor (Optional) Note: The above standard outfit is subject to change depending upon country and area.

  • Page 23: Specifications

    VIII. Specifications BONART ART-SP2 unit is designed and manufactured to meet the most demanding environment. It’s specification are listed below: 1. Standard list Emission: EN55011 Class B EN60555-2 Class A EN60555-3 Immunity: IEC 1000-4-2 IEC 1000-4-4 IEC 1000-4-5 IEC 801-3...
