- Page 1 KRUUSE-SP2 Scaler /Polisher Combo Unit Instruction Manual Jørgen Kruuse A/S DK Havretoften 4 DK-5550 Langeskov COPYRIGHT© 2014 Jørgen Kruuse A/S DK...
-
Page 2: Copyrights
Jørgen Kruuse A/S DK owns all rights to this publication. This publication shall be used solely as a reference for operation, maintenance, and repair on Jørgen Kruuse equipment. No part of this document may be reproduced or distributed in any form for any other purpose. -
Page 3: Operator Safety
Operator Safety Please read this manual before operating unit. The KRUUSE-SP2 Scaler/Polisher Combo Unit should be operated, maintained and repaired by qualified and properly trained personnel. NOTE, CAUTION, AND WARNING STATEMENTS NOTE： Provides tips and advice CAUTION： Provides correct operating or maintenance procedures WARNING：... -
Page 4: Warnings
Patients with pacemakers should avoid treatment with the KRUUSE-SP2. Studies have shown that electronic appliances including razors, hair dryers, microwave ovens, TV receptors, and other medical equipment, such as the KRUUSE-SP2, may interfere with the performance of pacemakers. For more information on this subject, please refer to the following articles: ... - Page 5 Please Read Before Operating: Make sure the device is connected to a grounded outlet. Failure to meet this requirement may severely damage the user and device. Place the device on a flat and stable surface. Placing the device on a tilted or unstable surface may degrade performance or damage the device.
-
Page 6: Preface
The KRUUSE-SP2 Piezoelectric Ultrasonic Scaler generates ultrasonic waves in the hand piece to vibrate the tip, which allows the KRUUSE-SP2 to remove calculus and tartar easily. These ultrasonic waves are created by 4 ceramic piezoelectric plates subjected to high frequency alternating currents. -
Page 7: Table Of Contents
Table of Contents ……………………………... Copyrights Operator Safety ..………………………. Warnings ..…………………………. ……..………………………. Preface Contents ..……………………………. Section I. Indications for Use ..……………………………. …………………….. Section II. Contraindications and Warnings Section III. Precautions .…………………………….. ……………………………... Section IV. Infection Control …..…………………………………………. Section V. Installation Section VI. General Description and Information of Parts……………. ………………………………. -
Page 8: Section I. Indications For Use
Do not use the KRUUSE-SP2 for amalgam restorative dental procedures. Do not use the KRUUSE-SP2 if the patient or operator is wearing a pacemaker. Do not immerse the KRUUSE-SP2 in water or liquid. If the KRUUSE-SP2 has water damage, return the machine to Bonart for servicing. - Page 9 BONART piezo tips are made of stainless steel. Avoid direct contact with teeth to prevent damage to the enamel. We strongly advise practicing on models and aluminum plates prior to operating on a live subject with the KRUUSE-SP2. Avoid direct contact of piezo tips with the subject’s lips, cheeks, and tongue.
-
Page 10: Section Iv. Infection Control
(According to ISO 13683:Sterilization of health Care products) NOTE: Prior to cleaning and sterilizing your KRUUSE-SP2 unit, always remember to turn off the device by using the power switch and to disconnect the power plug from the outlet. - 9 -... - Page 11 Autoclave the hand piece. WARNING: Do not immerse the hand piece cable in sterilizing fluid. The KRUUSE-SP2 can be severely damaged if sterilization fluid gets inside the unit.
- Page 12 Seal the straight hand piece inside a sterilization pouch. If you are autoclaving more than 1 tip, place each straight hand piece in an individual bag. You may also use the tip holder that comes with the KRUUSE-SP2 in place of the sterilization pouch. Autoclave the straight hand piece .
-
Page 13: Section V. Installation
SECTION V: INSTALLATION General Information If the installation of your KRUUSE-SP2 system is performed by non-Bonart dealer personnel, check to see that the requirements below are followed. Water Line Requirements Incoming water supply line pressure to the Scaler must be 25 psi (172 kPa minimum) to 60 psi (414Kpa maximum). - Page 14 Unpacking the Unit Carefully unpack your KRUUSE-SP2 unit and verify that all components and accessories are included: (Figure 1) All components and accessories Item Quantity Item Quantity (1) Main Unit (2) Foot Control / Foot Switch (3) AC Power Cord Set.
- Page 15 Inspect all connections for leaks. To remove the water line from the KRUUSE-SP2 scaler, turn off the water supply or disconnect the water supply line from the water tube. Then loosen the screw on the water tube from the receptacle of the unit and gently pull the water tube off.
- Page 16 of the cable to the matching receptacle on the back end of the hand piece. Do not twist or turn. To detach, pull the cable from the hand piece in a straight motion. Do not twist, turn, or yank the hand piece from the cable.
- Page 17 B) Match the groove at the base of the prophy head with the top of the straight hand piece and connect them together. (Figure 5) C) Close the lock by turning the locking ring counter-clockwise. The prophy head should now be locked onto the straight hand piece and should not fall off during operation.
-
Page 18: Section Vi. General Description And Information Of Parts
KRUUSE-SP2. 3. Power button (ON/OFF) The power button is used to turn the KRUUSE-SP2 main unit on and off. When the power is on, the LED indicator should be lit. When turned off, the LED power indicator should not be lit. - Page 19 The water hose input connector is the contact point for the water tube and the main water supply line. Use either a male or female quick connect to connect the water tube to the water supply. The KRUUSE-SP2 comes with a male quick connect attached to the water tube. 10. Power cord socket The power cord socket is where you connect the power cord to the main unit.
-
Page 20: Section Vii. Techniques
Section VII: Techniques Performing Ultrasonic Scaling Procedures 1. Use purified or distilled water to prevent infection when patients experience tissue laceration during treatment 2. Keep the power cord tidy to avoid tripping and other accidents. 3. Position the footswitch in an easily accessible spot for the user. Keep the footswitch cord tidy to avoid tripping and other accidents. - Page 21 Applications of the TIP A. Tangential application (BS1 TIP) Do not apply the BS1 tip directly to the tooth. Doing so may damage the enamel. Control the hand piece with a slow and steady motion. B. Frontal application (BS2 TIP) Apply the BS2 tip directly against the tartar, but not directly against the tooth.
-
Page 22: Section Viii. System Maintenance
Check tips regularly for wear and tear and replace as necessary. Main Unit Maintenance The housing of the KRUUSE-SP2 as well as the hand piece cord, should be cleaned and disinfected (using alcohol or soap and warm water) on a daily basis. -
Page 23: Section Ix. Troubleshooting
The pressure from the water Check water pressure of the water pressure. supply source may be too supply source is between 25 and 60 low. PSI. Technical Support and Repairs For technical support and assistance, please contact your local KRUUSE’s representatives. - 22 -... -
Page 24: Section X. Specifications
Section X: Specifications The KRUUSE-SP2 scaler is designed and manufactured to meet the most demanding environment. It’s specifications are listed below. Classification Protection against electric shock：Class I Degree of protection against electric shock：Type BF Mode of operation：Continuous ...
