In-line Refractometer
(Intrinsically safe type)
Model : GND15 (B)
Description
The Intrinsically safe In-line Refractometer GND15(B) it designed to detects the Refractive Index of a sample and
outputs the Brix(%) value on the display , can also transmit measured data to external devices via 4 to 20mA or
RS485 . GND15(B) series has the function of automatic temperature compensation according to the temperature
of the tested medium , when the tested medium temperature changes , the Brix value ( soluble solids ) after
temperature compensation is displays and the output changes accordingly.
Thank you for purchasing our Intrinsically safe In-line Refractometer. This instruction manual is designed to guide
you to understand the functions and characteristics of the sensor. Before using the instrument, please read this
manual carefully to ensure safe and correct use. Please keep this manual for future reference
ZHYQ Sensor&Control Page 1 of 6
Advertisement
Table of Contents
Related Manuals for ZHYQ GND15
Summary of Contents for ZHYQ GND15
- Page 1 Model : GND15 (B) Description The Intrinsically safe In-line Refractometer GND15(B) it designed to detects the Refractive Index of a sample and outputs the Brix(%) value on the display , can also transmit measured data to external devices via 4 to 20mA or RS485 .
- Page 2 Inline real-time monitoring and control of liquid substance concentration in various industries Applications The GND15(B) intrinsically safe concentration meter is mainly used for the preparation and detection of the weight percentage concentration of the cooling and cooling emulsion in the machining industry and the M-10 and MDT emulsions commonly used in mines.
- Page 3 Our standard is 3” tri-clamp Power: 12-24V DC Wetted parts material: Prism: sapphire, Prism stage: SS304 , SS316L (can be customized) Environment Temperature: 0-40℃ Protection grade: IP67 Electrical connection Directly cable Cable length 2M ,3M ,5M,10M are optional ZHYQ Sensor&Control Page 3 of 6...
- Page 4 Brown electronic wire: calibration wire Transmission wires should not be passed through conduits or open conduits with other power wires, nor should they be passed near high-power equipment. Operation and using Product connect with the user’s equipment ZHYQ Sensor&Control Page 4 of 6...
- Page 5 After the concentration meter has been running for 5 years, an insulation resistance test should be performed, and the insulation resistance should be above 500MΩ. Concentration value vs. Refractive Index graph ZHYQ Sensor&Control Page 5 of 6...
- Page 6 Model Output Accuracy Other requirement connection connection GND15 (B) Example: GND15(B)-15%-4-20mA-3” tri-clamp- Directly cable -0.5%FS Shanghai Zhaohui Pressure Apparatus Co., Ltd. 5-6F No.8 Building No.115 ,Lane 1276 Nanle Road Songjiang District Shanghai 201600 China Tel:+86-21-51691919 67755189 Fax:+86-21-67755185 E-mail: info@zhyqsensor.com www.zhyqsensor.com...
