In-line Refractometer （Economical）
Model : CZ15/CZ53
Thank you for purchasing an in-line refractometer. This instruction manual is designed to guide you to understand
the functions and characteristics of the sensor. Before using the instrument, please read this manual carefully to
ensure safe and correct use. Please keep this manual for future reference
Instruction manual
ZHYQ Sensor&Control Page 1 of 11
Advertisement
Related Manuals for ZHYQ CZ15
Summary of Contents for ZHYQ CZ15
- Page 1 Thank you for purchasing an in-line refractometer. This instruction manual is designed to guide you to understand the functions and characteristics of the sensor. Before using the instrument, please read this manual carefully to ensure safe and correct use. Please keep this manual for future reference ZHYQ Sensor&Control Page 1 of 11...
- Page 2 The Refractive Index of a substance varies with temperature. Thus, when using a refractometer to measure the Refractive Index of a liquid, the measurement value will vary with the sample temperature. The CZ15/CZ53 always detects the prism temperature. The value of the measurement is automatically corrected for temperature by a built-in processor, so that the displayed value is equal to the value measured at 20℃...
- Page 3 , and intuitively guide production personnel to operate. ZHYQ Sensor&Control Page 3 of 11...
- Page 4 Prism: sapphire, Prism stage: ,SS316L (can be customized) Max Pressure: 1MPa Environment Temperature: 10-60℃ Protection grade: IP65 Instrument Size: 230mm*170mm*65mm Process connection 1/2NPT, other size supply free adaptor Recorder output cable 2M ,3M ,5M,10M optional Temperature sensor Thin film platinum sensor ZHYQ Sensor&Control Page 4 of 11...
- Page 5 In-line Refractometer Model : CZ15/CZ53 Dimension ZHYQ Sensor&Control Page 5 of 11...
- Page 6 ◆ The power can be turned on only after the product is installed; ◆ Immediately turn off the power (DC24V) if the unit begins to overheat, smoke or emit an abnormal smell. Mounting diagram : ZHYQ Sensor&Control Page 6 of 11...
- Page 7 Mounting procedure: ① Install the CZ15/CZ53 so that the prism surface is at a right angle to the ground. ② Attach the flow pipe to the CZ15/CZ53 with O-ring (accessory) inserted between them, and fasten them together with the clamp band (accessory).
- Page 8 Cleaning the prism with an abrasive material could cause scratches on the prism which could lead to erroneous measurements. After cleaning is complete, re-attach the CZ15/CZ53 unit to the sample inlet unit, piping or tank. The procedure is described on the instruction manual.
- Page 9 The packaged transmitter can be stored for more than 12 months with temperature ranging from -40℃~60℃, and relative humidity less than 90% Live plug-in and pull-out should be strictly prohibited under live working condition, otherwise, it will damage the concentration and infrared transmitter easily. ZHYQ Sensor&Control Page 9 of 11...
- Page 10 In-line Refractometer Model : CZ15/CZ53 Plug wiring definition: Pin 1: VCC: Red Pin 2: GND , Yellow 5-pins plug for output Pin 3: Iout , Blue (4-20MA) Pin 4: K1, White Pin 5: DGND: Black Pin 1: VCC: Red Pin 2: GND , Yellow...
- Page 11 Accuracy Other requirement connection connection CZ15/53 Example: CZ15-15%-4-20mA-1/2NPT-5pins -0.5% Shanghai Zhaohui Pressure Apparatus Co., Ltd. 5-6F No.8 Building No.115 ,Lane 1276 Nanle Road Songjiang District Shanghai 201600 China Tel:+86-21-51691919 67755189 Fax:+86-21-67755185 E-mail: info@zhyqsensor.com www.zhyqsensor.com ZHYQ Sensor&Control Page 11 of 11...
