Z45FK, Z46FK, Z47FK, Z60FK Coupling Relays
Application
These coupling relays are used to control plant components in the DDC
system. They serve as switching coupling components between the DDC
switching outputs and the device inputs; they can be used to control valve
actuators, pumps, burners or fans, for example.
These coupling relays are fitted with spring terminals which make it
possible to connect wires quickly and easily. It is not necessary to use a
tool to connect solid wires and litz wires with conductor end sleeves; an
ordinary screwdriver is sufficient to connect litz wires without conductor
end sleeves.
Connected wires can be quickly disconnected again with a screwdriver.
Terminal slots provided for the A1 and A2 connections enable the simple
and quick connection of up to 10 analog encoders or coupling relays
through connecting bridges (Z43).
Content
Important Information on Product Safety ...............................................................................................................2
Item........................................................................................................................................................................3
Technical data .....................................................................................................................................................3
Accessories (not included in delivery) .................................................................................................................3
Dimensions ..........................................................................................................................................................4
Connection...........................................................................................................................................................4
Mounting and Installation.......................................................................................................................................5
Cable connection .................................................................................................................................................6
Connection example with input-output modules ....................................................................................................8
Kieback&Peter GmbH & Co. KG
Tempelhofer Weg 50, 12347 Berlin/Germany
Telefon: +49 30 60095-0, Telefax: +49 30 60095-164
www.kieback-peter.de, info@kieback-peter.com
Product Description
Z45FK, Z46FK, Z47FK, Z60FK
2.90-20.060-01-EN | 2022-10-05
L
Page
Advertisement
Table of Contents
Related Manuals for Kieback&Peter Z45FK
Summary of Contents for Kieback&Peter Z45FK
- Page 1 Product Description Z45FK, Z46FK, Z47FK, Z60FK Z45FK, Z46FK, Z47FK, Z60FK Coupling Relays Application These coupling relays are used to control plant components in the DDC system. They serve as switching coupling components between the DDC switching outputs and the device inputs; they can be used to control valve actuators, pumps, burners or fans, for example.
- Page 2 Important Information on Product Safety Safety instructions This document contains information on installing and commissioning the product “Z45FK, Z46FK, Z47FK, Z60FK”. Each person who carries out work on this product must have read and understood this document. If you have any questions that are not resolved by this document, you can obtain further information from the supplier or manufacturer.
- Page 3 Z45FK/Z47FK/Z60FK AC/DC 24 V ±10%, 13 mA Z46FK AC/DC 24 V ±10%, 20 mA Output contact Z45FK/Z47FK/Z60FK 1 changeover switch, max. AC 250 V, 6 A, 1500 VA Z46FK 2 changeover switches, each with max. AC 230 V, 0.25 A, 60 VA...
- Page 4 Product Description Z45FK, Z46FK, Z47FK, Z60FK Dimensions ZxxFK Connection Z45FK Z46FK 250 V AC 230 V AC 0,25 A 60 VA 1500 VA Z47FK Z60FK 250 V AC 250 V AC 1500 VA 1500 VA AUTO AUTO 2.90-20.060-01-EN | 2022-10-05...
- Page 5 Product Description Z45FK, Z46FK, Z47FK, Z60FK Mounting and Installation WARNING Contact with live parts of electrical domestic installation can cause death due to electric shock. Mounting/removal may only be carried out when power is switched off. Comply with VDE guidelines and local wiring regulations when mounting/removing.
- Page 6 Product Description Z45FK, Z46FK, Z47FK, Z60FK Cable connection ■ Disconnect unit from power supply. ■ Strip the insulation from 10 mm of the wire. Cross-sectional area of connection: Solid wire 0.08 .. 2.5 mm² Litz wire without conductor end sleeve 0.08 .. 2.5 mm² Litz wire with conductor end sleeve 0.5 ..
- Page 7 Product Description Z45FK, Z46FK, Z47FK, Z60FK Z43 connecting bridge The Z43 connecting bridge (not included in the delivery) can be used to connect up to 10 analog encoders or coupling relays (max. 2 A total current). Z43 connecting bridge Use a side-cutting pliers to cut off the required number of contacts at the corresponding notch that indicates the proper place to make the cut.
- Page 8 Product Description Z45FK, Z46FK, Z47FK, Z60FK Connection example with input-output modules CAUTION Previously, the binary outputs of the GND were switched in our devices. The implemented new device concept provides that the +24V DC are switched at the output terminals.
