- Page 1 SMART SG6P Sensor Gauge Installation Manual Revision 07 April 2022...
-
Page 2: Table Of Contents
Contents Section Page Contents Description Installation and Commissioning Problems Register the SmartGuard online Fitting template... -
Page 3: Description
Description The SmartGuard SG6P is a device for measuring the level of liquids such as heating oil, diesel, kerosene, gasoil, AdBlue and water, then relaying that information by GSM to a user and / or monitoring system. The level measurement is achieved using a unique flexible element that is set to length without tools. -
Page 4: Installation And Commissioning
Installation and Commissioning Note: It is important that you verify that there is a mobile signal at the point of installation before you install the sensor. The installation is carried out following the flowchart shown in Fig 1. Each step is clarified in the text below: Fig 1 Determine suitability... - Page 5 Using the SmartGuard at the tank press the button as in fig.6 and follow the light sequence as detailed below after fig.6. If connected to the network as described continue with installation. If not please contact Atlantis on 0330 9991100.
- Page 6 Fig4 *Fig shows the correct fitting of the probes and Fig 5 shows the correctly looped sensor / weight.
- Page 7 Once the probe has been fitted the button should be pressed again to send the current tank level to the servers. To do this press in the centre of the stylised mark as indicated in *fig 6 for at least one second. Fig 6 Press here The first time this hidden button is pushed, lights will indicate the device status.
-
Page 8: Problems
If the probe is too long it will enter any water that has collected at the bottom of the tank. This causes a degradation in accuracy. If you do encounter a problem during installation, please call Atlantis on 0330 9991100 quoting the serial number of the SmartGuard.
