AIR CONDITIONER
Wall mounted type
DESIGN & TECHNICAL MANUAL
INDOOR
OUTDOOR
ASHG07KPCA
ASHG09KPCA
ASHG12KPCA
AOHG07KPCA
AOHG09KPCA
AOHG12KPCA
DR_AS089EG_02
2019.02.25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GENERAL ASHG07KPCA and is the answer not in the manual?

Questions and answers

Related Manuals for Fuji General Limited GENERAL ASHG07KPCA

Summary of Contents for Fuji General Limited GENERAL ASHG07KPCA

  • Page 1 AIR CONDITIONER Wall mounted type DESIGN & TECHNICAL MANUAL INDOOR ASHG07KPCA ASHG09KPCA ASHG12KPCA OUTDOOR AOHG07KPCA AOHG09KPCA AOHG12KPCA DR_AS089EG_02 2019.02.25...
  • Page 2 Notices: • Product specifications and design are subject to change without notice for future improvement. • For further details, please check with our authorized dealer. Copyright © 2019 Fujitsu General Limited. All rights reserved.

  • Page 3: Table Of Contents

    CONTENTS Part 1. INDOOR UNIT................1 1. Specifications....................2 2. Dimensions....................4 2-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA.........4 3. Wiring diagrams ....................6 3-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA.........6 4. Capacity table....................7 4-1. Cooling capacity.......................7 4-2. Heating capacity ......................8 5. Fan performance ...................9 5-1. Air velocity distributions....................9 5-2.
  • Page 4 CONTENTS (continued) Part 2. OUTDOOR UNIT..............27 1. Specifications....................28 2. Dimensions....................29 2-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA........29 3. Installation space ..................30 3-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA........30 4. Refrigerant circuit ..................33 4-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA........33 5. Wiring diagrams ..................34 5-1.

  • Page 5: Part 1. Indoor Unit

    Part 1. INDOOR UNIT WALL MOUNTED TYPE: ASHG07KPCA ASHG09KPCA ASHG12KPCA...

  • Page 6: Specifications

    1. Specifications Wall mounted Type Inverter heat pump Model name ASHG07KPCA ASHG09KPCA ASHG12KPCA Power supply 230 V ~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V 2.00 2.50 3.40 Rated Btu/h 6,800 8,500 11,600 Cooling 0.9—2.8 0.9—3.0 0.9—3.7 Min.—Max.
  • Page 7 Specifications for Lot10 Model name ASHG07KPCA ASHG09KPCA ASHG12KPCA Cooling Energy efficiency class Heating (Average) Cooling 2.0 (35 °C) 2.5 (35 °C) 3.4 (35 °C) P design Heating (Average) 2.2 (-10 °C) 2.4 (-10 °C) 2.5 (-10 °C) SEER Cooling kWh/kWh SCOP Heating (Average) Annual energy consumption...

  • Page 8: Dimensions

    2. Dimensions 2-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA Unit: mm Outline of indoor unit for pipe inlet Ø65 for pipe inlet Ø65 - 4 - 2-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA 2. Dimensions...
  • Page 9 ¢ Installation space requirement Provide sufficient installation space for product safety. Unit: mm 30 or more 40 or more Wall hook bracket Outline of the indoor unit 107 or more 163 or more 1,500 or more The flare connection part should be installed outdoors.

  • Page 10: Wiring Diagrams

    3. Wiring diagrams 3-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA - 6 - 3-1. Models: ASHG07KPCA, ASHG09KPCA, and ASHG12KPCA 3. Wiring diagrams...

  • Page 11: Capacity Table

    4. Capacity table Capacity tables show each of following values calculated based on the outdoor temperature and the indoor temperature, under given Airflow Rate (AFR): For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP) For heating capacity: Total Capacity (TC) and Input Power (IP) 4-1.

  • Page 12: Heating Capacity

    4-2. Heating capacity NOTE: Values mentioned in the table are calculated based on the maximum capacity. ¢ Model: ASHG07KPCA Indoor temperature °CDB °CWB 1.84 0.88 1.83 0.90 1.79 0.92 1.75 0.94 1.70 0.96 2.14 0.93 2.09 0.95 2.04 0.97 1.98 0.99 1.93 1.01...

  • Page 13: Fan Performance

    5. Fan performance 5-1. Air velocity distributions ¢ Models: ASHG07KPCA and ASHG09KPCA Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Left &...
  • Page 14 ¢ Model: ASHG12KPCA Fan speed Operation mode Measuring conditions HIGH Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Center Unit: m/s Top view Vertical airflow direction louver: Up Horizontal airflow direction louver: Left & Right Unit: m/s Side view Vertical airflow direction louver: Up...

  • Page 15: Airflow

    5-2. Airflow ¢ Models: ASHG07KPCA and ASHG09KPCA  Cooling Fan speed Airflow HIGH QUIET  Heating Fan speed Airflow HIGH QUIET - 11 - 5-2. Airflow 5. Fan performance...
  • Page 16 ¢ Model: ASHG12KPCA  Cooling Fan speed Airflow HIGH QUIET  Heating Fan speed Airflow HIGH QUIET - 12 - 5-2. Airflow 5. Fan performance...

  • Page 17: Operation Noise (Sound Pressure)

    6. Operation noise (sound pressure) 6-1. Noise level curve ¢ Models: ASHG07KPCA and ASHG09KPCA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 HIGH NC-50 NC-50 HIGH NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 QUIET NC-20 NC-20 QUIET NC-15...

  • Page 18: Sound Level Check Point

    6-2. Sound level check point Microphone Microphone NOTE: Detailed shape of the actual indoor unit might be slightly different from the one illustrated above. - 14 - 6-2. Sound level check point 6. Operation noise (sound pressure)

  • Page 19: Safety Devices

    7. Safety devices Model Type of Protection form protection ASHG07KPCA ASHG09KPCA ASHG12KPCA Circuit Current fuse (PCB*) 250 V, 3.15 A protection More than 170 °C Activate Fan motor stop Fan motor Thermistor protection protection 145 °C or less Reset Fan motor restart *PCB: Printed Circuit Board - 15 - 7.

  • Page 20: Remote Controller

    8. Remote controller 8-1. Wireless remote controller ¢ Overview a FAN button b SET button c SWING button d START/STOP button e RESET button f TIMER CANCEL/W-LAN ON/OFF button g ON TIMER/W-LAN SET button h OFF TIMER button i SLEEP TIMER button j TEST RUN button •...
  • Page 21 ¢ Specifications  Controller Unit: mm Top view Front view Side view Rear view Size (H × W × D) 139 × 56 × 18 Weight 70 (without batteries) - 17 - 8-1. Wireless remote controller 8. Remote controller...

  • Page 22: Function Settings

    9. Function settings To adjust the functions of this product according to the installation environment, various types of function settings are available. NOTE: Incorrect settings can cause a product malfunction. 9-1. Function settings by using remote controller Some function settings can be changed on the remote controller. After confirming the setting proce- dure and the content of each function setting, select appropriate functions for your installation envi- ronment.
  • Page 23 STEP 2: Selecting the function number and setting value 1. Press the SET TEMP. ( ) buttons to select the function num- Function number ber. To switch between the left and right digits, press the MODE button. 2. Press the FAN button to proceed the setting value. To return the function number selection, press the FAN button again.
  • Page 24 ¢ Contents of function setting Each function setting listed in this section is adjustable in accordance with the installation environ- ment. NOTE: Setting will not be changed if invalid numbers or setting values are selected.  Function setting list Function no. Functions Filter sign 30/31...
  • Page 25 3) Auto restart Enables or disables automatic restart after a power interruption. Function number Setting value Setting description Factory setting Enable ♦ Disable NOTE: Auto restart is an emergency function such as for power outage etc. Do not attempt to use this function in normal operation.
  • Page 26 8) Indoor unit fan control for energy saving for cooling Enables or disables the power-saving function by controlling the indoor unit fan rotation when the outdoor unit is stopped during cooling operation. Function number Setting value Setting description Factory setting Disable Enable ♦...

  • Page 27: Custom Code Setting For Wireless Remote Controller

    9-2. Custom code setting for wireless remote controller ¢ Custom code setting To interconnect the air conditioner and the wireless remote controller, assignment of the custom code for the wireless remote controller is required. NOTE: Air conditioner cannot receive a custom code if the air conditioner has not been set for the custom code.

  • Page 28: Accessories

    10. Accessories Part name Exterior Q’ty Part name Exterior Q’ty Operating manual Battery Operating manual Cloth tape (CD-ROM) Installation manual Tapping screw Wall hook bracket Remote controller - 24 - 10. Accessories...

  • Page 29: Optional Parts

    11. Optional parts 11-1. Others Exterior Part name Model name Summary Remote Wall or pillar mountable, and holds the UTZ-RXLA controller holder wireless remote controller. Remotely manage an air conditioning Wireless LAN UTY-TFSXF2 system using mobile devices such as adapter smartphones and tablets.
  • Page 30 - 26 - 11-1. Others 11. Optional parts...

  • Page 31: Part 2. Outdoor Unit

    Part 2. OUTDOOR UNIT SINGLE TYPE: AOHG07KPCA AOHG09KPCA AOHG12KPCA...

  • Page 32: Specifications

    1. Specifications Type Inverter heat pump Model name AOHG07KPCA AOHG09KPCA AOHG12KPCA Power supply 230 V ~ 50 Hz Power supply intake Outdoor unit Available voltage range 198—264 V Starting current Cooling 1,650 1,650 1,700 Airflow rate Heating 1,450 1,450 1,470 Type ×...

  • Page 33: Dimensions

    2. Dimensions 2-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA Unit: mm 4-M10 hole Pitch of bolts for installation Top view Side view Front view Side view Airflow Drain port Ø42 Bottom view Side view (Valve part) - 29 - 2-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA 2.

  • Page 34: Installation Space

    3. Installation space 3-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA ¢ Space requirement Provide sufficient installation space for product safety. CAUTION Keep the space shown in the installation examples. If the installation is not performed accordingly, it could cause a short circuit and result in a lack of operating performance.
  • Page 35  Multiple outdoor unit installation • Provide at least 250 mm of space between the outdoor units if multiple units are installed. • When routing the piping from the side of an outdoor unit, provide space for piping. • No more than 3 units must be installed side by side. When 3 units or more are arranged in a line, provide the space as shown in the following ex- ample “When an obstruction in the upper space:”.
  • Page 36  Outdoor units installation in multi-row Unit: mm Single parallel unit arrangement Multiple parallel unit arrangement 100 or more 200 or more 1,000 or more 2,000 or more 200 or more 400 or more 500 or more 1,000 or more 200 or more 250 or more 1,000 or more...

  • Page 37: Refrigerant Circuit

    4. Refrigerant circuit 4-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA Heat exchanger 3-way (INDOOR) valve 2-way Muffler valve 4-way valve Strainer Expansion valve Heat exchanger Strainer (OUTDOOR) Cooling Heating : Thermistor (Discharge temperature) : Thermistor (Outdoor temperature) : Thermistor (Heat exchanger out temperature) : Thermistor (Room temperature) : Thermistor (Pipe temperature) - 33 -...

  • Page 38: Wiring Diagrams

    5. Wiring diagrams 5-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA - 34 - 5-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA 5. Wiring diagrams...

  • Page 39: Capacity Compensation Rate For Pipe Length And Height Difference

    6. Capacity compensation rate for pipe length and height difference Height difference H Indoor unit is higher than outdoor unit Indoor unit is lower than outdoor unit Outdoor unit Indoor unit Outdoor unit Indoor unit Connection pipe Connection pipe 6-1. Models: AOHG07KPCA and AOHG09KPCA NOTE: Values mentioned in the table are calculated based on the maximum capacity.

  • Page 40: Model: Aohg12Kpca

    6-2. Model: AOHG12KPCA NOTE: Values mentioned in the table are calculated based on the maximum capacity. Pipe length (m) COOLING — — — 0.858 0.868 — — 0.929 0.872 0.882 Indoor unit is higher than outdoor unit *1 — 0.960 0.933 0.876 0.885...

  • Page 41: Additional Charge Calculation

    7. Additional charge calculation 7-1. Models: AOHG07KPCA and AOHG09KPCA Refrigerant type Refrigerant amount ¢ Refrigerant charge Total pipe length 15 or less 20 (Max.) 20 g/m Additional charge 7-2. Model: AOHG12KPCA Refrigerant type Refrigerant amount ¢ Refrigerant charge Total pipe length 15 or less 20 (Max.) 20 g/m...

  • Page 42: Airflow

    8. Airflow 8-1. Model: AOHG07KPCA  Cooling Airflow 1,650  Heating Airflow 1,450 8-2. Model: AOHG09KPCA  Cooling Airflow 1,650  Heating Airflow 1,450 - 38 - 8-1. Model: AOHG07KPCA 8. Airflow...

  • Page 43: Model: Aohg12Kpca

    8-3. Model: AOHG12KPCA  Cooling Airflow 1,700 1,001  Heating Airflow 1,470 - 39 - 8-3. Model: AOHG12KPCA 8. Airflow...

  • Page 44: Operation Noise (Sound Pressure)

    9. Operation noise (sound pressure) 9-1. Noise level curve ¢ Model: AOHG07KPCA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 1,000 2,000 4,000 8,000 1,000...

  • Page 45: Sound Level Check Point

    ¢ Model: AOHG12KPCA  Cooling  Heating NC-65 NC-65 NC-60 NC-60 NC-55 NC-55 NC-50 NC-50 NC-45 NC-45 NC-40 NC-40 NC-35 NC-35 NC-30 NC-30 NC-25 NC-25 NC-20 NC-20 NC-15 NC-15 2,000 4,000 8,000 2,000 4,000 8,000 1,000 1,000 Octave band center frequency, Hz Octave band center frequency, Hz 9-2.

  • Page 46: Electrical Characteristics

    10. Electrical characteristics Model name AOHG07KPCA AOHG09KPCA AOHG12KPCA Voltage 230 ~ Power supply Frequency Max operating current *1 Starting current Circuit breaker current Power cable Cross- Wiring sectional spec. *2 area Connection cable *3 Limited wiring length *1: Maximum operating current is the total current of the indoor unit and the outdoor unit. *2: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005.

  • Page 47: Safety Devices

    11. Safety devices Model Type of Protection form protection AOHG07KPCA AOHG09KPCA AOHG12KPCA 250 V, 20 A Circuit protection Current fuse (Main PCB) 250 V, 5 A 85—122 °C Activate Fan motor stop Fan motor Thermistor protection protection 77—114 °C Reset Fan motor restart 110 °C Activate...

  • Page 48: Accessories

    12. Accessories 12-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA Part name Exterior Q’ty Part name Exterior Q’ty Drain pipe - 44 - 12-1. Models: AOHG07KPCA, AOHG09KPCA, and AOHG12KPCA 12. Accessories...
