Uni-bond E-333A Manual

Flash Patterns
#1 - Rotating
#2 - Quad
#3 - Quint
Surface Mount Model: E-333A, E-333W & E-333R
Surface Mount: 3 Holes @ 4
Wire Colour Function
Red Power
Black Ground
Yellow Pattern Selection
Suggested Switch Connection
Battery Positive
Power
Ground
Pattern Selection
Magnetic Mount Model: E-333AM & E-333BM
This Light comes with a Cigarette Power Adaptor with the following Sequence;
1. Press button once for Rotating Flash
2. Press button again for Quad Flash
3. Press button again for Quint Flash
4. Press button again to turn OFF
This unit may not be factory-set to Flash Pattern #1
Note: Cutting wires voids the warranty
INSTALLATION MANUAL
/ " centres • Light should be fused with 5 Amp Fuse (
3
4
Operation:
(switches sold separately)
Switch #1
ST100
(ON/OFF)
Visit us at www.unibondlighting.com
For 9V to 30V DC Applications
This unit may not be factory-set to Flash Pattern #1
Switch # Lamp Function
Switch 1 Power
Switch 2 Pattern Selection
From Vehicle Ground
Jumper Wires
E-333 Series
ATM05 sold separately
Switch #2
ST108
(OFF-Momentary ON)
Last Updated: 03/14/2022
)
