Page 1
INSTALLATION MANUAL E-735AB & E-735AW Wire Colour Function Connect To Power +12/24 VDC (Power) Black Ground 12/24 VDC (Ground) Yellow Pattern Selection - 12/24 VDC (Power) Blue Synchronization Synchronization Wire from another Unit All lights must be set to the same Flash Pattern before synchronizing...
Page 2
MODE D’INSTALLATION E-735AB & E-735AW Couleur de fil Fonctions Se branche sur Rouge Puissance +12/24 VDC (Puissance) Noir Fil de garde 12/24 VDC (Fil de garde) Jaune Choix de configuration - 12/24 VDC (Fil de garde) Bleu Synchronisation Fil de synchronisation d’une autre unité...
